Cat. No. 17-6024
OWNER’S MANUAL
Please read before using this equipment.
Tone/Vibration
Pager
17-6024.fm Page 1 Friday, August 6, 1999 11:00 AM
2
FEATURES
Your RadioShack Tone/Vibration Pager works with your
4-Watt Wireless Paging System (Cat. No. 17-6023) to
keep you accessible in any environment where you need
to be able to receive important messages.
When the pager gets a signal from the system’s transmit-
ter, it beeps or vibrates, depending on the setting you se-
lected, and shows the message code on its display. The
silent paging mode allows you to stay accessible without
disturbing others around you. Add this pager to your ex-
isting system if you have more than one person you need
to page.
Non-Volatile Memory — stores system and pager codes
(not messages) for over one year, even with weak or
dead batteries.
Message Memory — stores the last eight message
codes in the pager and lets you review them with the
touch of a button before the pager is switched off.
Digital Display — shows 10 different message codes
(0–9) received from the paging system’s transmitter.
Battery Sentinel — shows when the pager’s battery lev-
el is low. ©1999 Tandy Corporation.
All Rights Reserved.
RadioShack is a registered trademark used by Tandy Corporation.
17-6024.fm Page 2 Friday, August 6, 1999 11:00 AM
3
PREPARATION
INSTALLING BATTERIES
The pager is powered by two AAA batteries (not sup-
plied). We recommend RadioShack alkaline batteries.
You can also use rechargeable nickel-cadmium or nickel-
metal hydride batteries, also available at your local Ra-
dioShack store.
Note: Using rechargeable batteries might reduce range.
When batteries are low, bappears on the pager’s display
when you press //OFF
, and the pager beeps every 15
seconds.
To install or replace the pager’s batteries:
1. Slide the LOCK switches on both sides toward the
front of the pager, then slide off the battery compart-
ment cover in the direction of the arrow.
2. Set the switch inside the compartment to ALKALINE
(for alkaline batteries) or RECHARGEABLE (for
rechargeable nickel-cadmium or nickel-metal hydride
batteries).
Caution: Do not use alkaline batteries with the
switch set to RECHARGEABLE. Doing so could dam-
age the batteries and the pager.
17-6024.fm Page 3 Friday, August 6, 1999 11:00 AM
4
3. Insert two fresh AAA batteries, as indicated by the
polarity symbols (+ and –) marked inside the com-
partment.
4. Replace the cover and slide LOCK on both sides
toward the back of the pager.
Note: The pager retains pager codes in memory without
power for up to 1 year.
Recharging Batteries in the Pager
A battery charger (Cat. No. 17-6025) specially designed
for use with the 17-6024 pager is available at your local
RadioShack store. It can hold and charge up to six 17-
6024 pagers. Follow these steps to recharge batteries:
1. Place the pager with nickel-cadmium or nickel-metal
hydride batteries installed in one of the charger’s
slots.
2. Slide the charger’s switch to Ni-Cd (for nickel-
cadmium batteries) or Ni-MH (for nickel-metal
hydride batteries).
3. Charge the batteries for 14–16 hours. The charging
indicator lights green when charging is completed.
17-6024.fm Page 4 Friday, August 6, 1999 11:00 AM
5
USING THE BELT CLIP
Use the belt clip on the back of the pager to clip the pager
on your belt for hands-free carrying when you are on the
go.
17-6024.fm Page 5 Friday, August 6, 1999 11:00 AM
6
OPERATION
STORING THE PAGER CODE
Before you use the pager, you
must set the codes which identi-
fy the pager and paging system.
1. Slide //OFF
on the
pager to OFF.
2. Hold down //OFF
and
slide it to (audible) or
(silent), then continue hold-
ing it down until Lappears in
the display area on top of
the pager.
3. Make sure the transmitter is
on. Enter a 3-digit pager
code (0 0 0 – 9 9 9) then 0.
4. Press PAGE on the transmitter. The pager’s code and
0appear on the display, then the transmitter sends
the pager and system codes to the pager.
L flashes and the pager beeps four times (and
vibrates twice if //OFF
is set to ). Then 8flashes
and the pager beeps once. The pager flashes the
code you sent (0) and beeps 12 times. You can press
the pager’s switch to stop it from flashing. Otherwise,
the code flashes 12 times.
Display Area
17-6024.fm Page 6 Friday, August 6, 1999 11:00 AM
7
If you want the pager to have a new pager code,
enter the new 3-digit pager code and 0, then press
PAGE.
After you press PAGE, the transmitter flashes the 4-
digit code seven times and transmits the pager and
system codes to the pager. After the codes are trans-
mitted, the digits remain on the display until you:
• Turn off the transmitter.
• Press CANCEL. - - - - appears.
• Send a message to the pager. The 4-digit code
flashes.
5. Once the pager code is stored, turn the pager off,
then on again before attempting to transmit a mes-
sage code.
Repeat Steps 1–5 to store or replace a code for each
pager used.
Notes:
• If the pager does not successfully store the pager
code, repeat the steps.
• You must reset all the pager’s codes when you store
a new system code in your transmitter.
17-6024.fm Page 7 Friday, August 6, 1999 11:00 AM
8
SETTING THE PAGER’S MODE
Slide //OFF
to for audible alerts, or for silent
alerts. When the pager receives a message code, the
code flashes on its display. With //OFF
set to , the
pager sounds three series of four beeps for individual
and group paging, or 12 continuous beeps for all-paging.
With //OFF
set to , the pager vibrates for about 3.5
seconds.
Press //OFF
to stop an alert during or just after the
alert. If you do not stop the alert and the pager is set to
alert audibly, the pager beeps every minute to remind
you there is a new page.
Note: If the pager receives the same code twice within 30
seconds, it ignores the second message code.
REVIEWING STORED MESSAGE
CODES
The pager can store up to eight message codes. Repeat-
edly press //OFF
to view the stored message codes
from the latest to the oldest. -appears to indicate the
end of the stored message codes.
17-6024.fm Page 8 Friday, August 6, 1999 11:00 AM
9
Notes:
• When the memory is full and a new message is
received, the oldest message code is deleted from
memory.
• If a new message code is identical to the last mes-
sage received, it will not be stored.
• All stored message codes are erased when you set
//OFF
to OFF.
• You can use the label on the front of the pager to
record the message codes. Use a pointed object
(such as a straightened paper clip) to carefully lift the
protective cover, use a pencil to write the message
for each code on the label, then replace the cover.
17-6024.fm Page 9 Friday, August 6, 1999 11:00 AM
10
CARE AND MAINTENANCE
To enjoy your RadioShack Tone/Vibration Pager for a
long time:
• Keep the pager dry. If it gets wet, wipe it dry immedi-
ately.
• Use and store the pager only in normal temperature
environments.
• Handle the pager gently and carefully. Don’t drop it.
• Keep the pager away from dust and dirt.
• Wipe the pager with a damp cloth occasionally to
keep it looking new.
Modifying or tampering with the pager’s internal compo-
nents can cause a malfunction and invalidate its warranty
and void your FCC authorization to operate it. If your pag-
er is not performing as it should, take it to your local Ra-
dioShack store for assistance.
