RADWAG AS R2 PLUS Guida utente
Start up Guide
Analytical balances:
• AS R2 PLUS
Precision balances:
• PS R1
• PS R1.M
• PS R2
• PS R2.M
• PS R2.H
• PS R2.M.H
Analytical
and Precision Balances
IMMB-03-02-11-21-EN
To view a complete User Manual go to the website or scan QR code:
radwag.com/en/manuals/198
1. CONTENT
AS R2 PLUS (d=0,01mg)
AS R2 PLUS (d=0,1mg)
Balance
×1
Balance
×1
Weighing pan
×1
Weighing pan
×1
Draft shield
×1
Draft shield
×1
Centring ring
×1
Bottom insert
×1
Bottom insert
×1
Power adapter*
×1
Power adapter*
×1
Models: PS R1 (d=1mg) |PS R2 (d=1mg)
Balance
×1
Weighing pan
×1
Draft shield
×1
Grounding foot
×1
Foot
×3
Power adapter*
×1
Power adapter*
×1
Models: PS R1.M |PS R2.M
Balance
×1
Weighing pan
×1
Draft shield
×1
*The plug type may vary by country.
fabric dust
cover
×1
Power adapter*
×1
Power adapter*
×1
Models: PS R2.H
Models: PS R2.M.H
Balance
×1
Balance
×1
Weighing pan
×1
Weighing pan
×1
Draft shield
×1
Draft shield
×1
*The plug type may vary by country.
2. UNPACKING
1 2 3
Keep the packaging should a
warranty claim or service be required.
TOP
3. RECOMMENDATIONS AND WARNINGS
+40 °C
+104°F
+10 °C
+50 °F
Operate the device in a room where the temperature ranges between 10–40 °C
(50–104 °F) and where the relative humidity is below 80%.
Place the balance on a solid surface to ensure stability. To obtain stable and
repeatable weighing results, an anti-vibration table is recommended.
Place the balance away from heat
sources. Avoid exposing the balance
to the sunlight.
Avoid air drafts and air movements
at the workstation.
Avoid exposing the balance to amag-
netic field. Do not weigh magnetic
substances.
Make sure that the balance is placed
on an even surface.
Do not place the balance in a hazard-
ous area. Do not weigh explosive
materials.
Do not place the balance on an
unstable ground exposed to shocks
and vibrations.
4. ACTIVITIES TO BE DONE PRIOR TO OPERATION
Keep the transport
lock should a warranty
claim or service be
required.
Keep the transport
lock should a warranty
claim or service be
required.
4.1. Transport lock removal
4.2. Grounding spring check
Models: AS R2 Series
Models: AS R2 Series
Models: PS R2 series | PS R1 series
Models: PS R2 series | PS R1 series
1 2
1 2
Check whether the grounding
spring takes its intended
location.
Make sure that the grounding
spring juts slightly out of the
hole.
Check whether the grounding
spring takes its intended
location.
Make sure that the grounding
spring juts slightly out of the
hole.
1
1
2
2
3
3
Install the
grounding foot
in a freely
selected opening.
Models: AS R2 (d=0,1 mg)
Models: PS R1 (d=0,01 mg) |PS R2 (d=0,01 mg)
5. COMPONENTS ASSEMBLY
1 2 3 4
Models: AS R2 (d=0,01 mg)
1
1
1
2
2
2
Models: PS R1.M |PS R2.M
Models: PS R2.H
Models: PS R2.M.H
6. PREPARING FOR WORK
6.1. Temperature stabilization
6.2. Leveling
Prior to switching the device on, let it
reach room temperature (estimated
stabilisation time: 1-8 hours).
Connect the power adapter
to DC connector.
Connect the power
adapter to the mains.
USB 1 USB 2
1 2 3
6.3. Switch the balance on
To switch the device on, press ON / OFF key.
Your balance is ready to use!
To level the balance, turn its
feet and keep turning the feet
until an air bubble takes the
central position.
7. PANEL AND SCREEN
7.1. Panel keys
7.2. Home screen
Select working
mode Switching ON/OFF
Start adjustment Databases
Enter setup Working mode
functions
Taring Zeroing
PRINT/ENTER
Unit selection / ESC
Navigation keys
Measurement result
Stable indication
pictogram
Pictogram of active
working mode
Messages
and information
Zeroing pictogram
