iii
T a b l e o f C o n t e n t s
C h a p t e r 0 1 Startup 1
0.1 Packing List .............................................................. 1
0.2 Specifications ........................................................... 2
0.3 Component Location ................................................. 3
C h a p t e r 1 Introduction 4
1.1 Features .................................................................... 4
1.2 Specifications ........................................................... 5
1.3 VGA Interface ............................................................ 7
1.4 DiskOnChip 2000 Flash Disk..................................... 8
C h a p t e r 2 Installation 9
2.1 Jumper Settings ........................................................ 9
2.2 Connectors...............................................................11
2.3 DiskOnChip/EPROM/Flash ROM Disk.......................12
2.4 Watchdog Timer .......................................................14
C h a p t e r 3 SVGA Setup 22
3.1 Introduction..............................................................22
3.1.1 Chipset ................................................................22
3.1.2 Display Memory ...................................................22
3.2 Flat Panel BIOS and Wiring......................................22
Appendix A Pin Assignments 31
IDE Interface Connector................................................... 31
VGA/Flat Panel Connectors ............................................. 32
Flat Panel Connector Pin Assignment .............................. 33
Floppy Disk Connector...................................................... 34
Parallel Port Interface ....................................................... 35
Serial Port Interface........................................................... 36
Keyboard and PS/2 Mouse Connector ............................ 37
16-bit General Purpose I/O............................................... 37
PC/104 Connectors ........................................................... 38
Warranty 40
