Rainforest Automation EAGLE-200 Manuale utente

A new way to see your energy

Quick Start GUIDE

NEED HELP WITH YOUR EAGLE-200?

For a full user manual, FAQs, and to contact support:

rainforestautomation.com/eagle200_support

LED LIGHT INDICATOR KEY

LED lights on the front of the device give you a quick way to check the

status of the EAGLE-200.

V1.04

WHAT’S IN THE BOX:

•EAGLE-200 ENERGY GATEWAY

•AC POWER ADAPTER

•ETHERNET CABLE

YOU WILL NEED:

•A BROADBAND INTERNET CONNECTION VIA

ETHERNET OR WIFI

•A COMPUTER OR DEVICE WITH A WEB BROWSER

rainforestautomation.com

POWER ETHERNET WIFI CLOUD METER

Power is on. IP address

obtained. WiFi network

is active Connected to

the Cloud Meter network

is active

Model: RFA –Z114 –Z2 –001 Control Gateway

Rainforest Automation, Inc.

Assembled in

New Hampshire U.S.A.

Contains FCC IDs:

YCXRFA –W900

2AC2E –68M04

This device complies with Part 15 of

the FCC Rules. Operation is subject

to the following two conditions (1)

This device may not cause harmful

interference, and (2) this device

must accept any interference

received, including interference

that may cause undesired

operation.

Cloud ID: 123456

MAC: d8d5 b900 0000 0000

IN: e80f 63cd a532 0a3d

EAGLE-200 INFORMATION LABEL

Located on the underside of the EAGLE-200 is the Information Label that

identifies each individual device. You will need the three numbers

indicated below to register the device. Please make a note of them:

Cloud ID (6 characters)

Install Code (16 characters)

MAC Address (16 characters)

GET DIRECT ACCESS TO YOUR REAL-TIME

ENERGY INFORMATION IN

THREE EASY STEPS:

STEP 1: REGISTER WITH YOUR UTILITY

(BC Hydro customers are pre-registered and can skip this step)

You will need to provide the MAC Address and Install Code from the

Information Label on the bottom of your EAGLE-200. It may take

some time for your utility to enable your meter to connect to your

device. It is important to wait until this is complete before

proceeding to the next step.

STEP 2: PLUG IN YOUR EAGLE-200

Connect the Ethernet cable to your router (to use WiFi instead, see

the EAGLE-200 User Manual on our website), and plug in the power

adapter. Use only the included adapter to power your EAGLE-

200. If another adapter is used, it may cause permanent damage

to your EAGLE-200.

It should take about two minutes for your EAGLE-200 to boot up.

EAGLE-200 router

power

STEP 3: CONNECT TO THE CLOUD

Create your Cloud Account and connect to your EAGLE-200 to start

viewing your energy data.

WEB BROWSER MOBILE APP

portal.rainforestcloud.com EnergyVUE

•Log in to your account from the app.

•Click on “Settings”.

•Click “Add an EAGLE”.

•Click “scan EAGLE barcode” and

scan the label of your EAGLE-200.

SEE THE FULL EAGLE-200 USER MANUAL:

rainforestautomation.com/eagle200_support

CONNECTING TO THE CLOUD

Use your Web Browser to go to portal.rainforestcloud.com

•Click on “Register”.

•Fill in the “Account Registration” form and click “Register”.

•Check your email to find the message from Rainforest Automation

with the subject line “EAGLE Cloud Account Activation”. Click the

“ACTIVATE MY ACCOUNT” link in the email.

•Check your email for a second message from Rainforest Automation.

The subject line will be,”EAGLE Cloud Password Reset”. Click the

“RESET PASSWORD FOR MY ACCOUNT” link in the email.

•Enter your password and click “Change Password”.

Download the EnergyVUE app from the App Store

or Google Play

You are all set!

If you can’t use the EnergyVUE app, you can add your EAGLE-200 to

your account by logging in at portal.rainforestcloud.com
