Arranging ceramic logs - Visio 70 RD & T

It is very important that you follow this when positioning ceramic “logs” and the

 emberslayerinthereplace.Failuretocarrythisoutcorrectlywillcausethereplace

 tonotburnoptimallyandsoottooccur.

OPSTILLINGSAFSTANDE

ARRANGING CERAMIC ”LOGS” - VISIO 70 RD & T

2

OPSTILLINGSAFSTANDE – OVN MED DREJEFOD

IMPORTANT INFORMATION: CERAMIC “LOGS” AND THE EMBERS LAYER

NB!

The measurements on the following photos are taken from the edge of the base plate.See

photobelow.

cmcm

Important information: Ceramic “logs” and the embers layer

When arranging ceramic “logs” and the embers layer in the combustion chamber, it is important

that they do not cover the pilot ame and its thermocouple, and ember material must not be

placed under the pilot guard.Boththermocouplesmustbekeptfreeoftheemberslayer.

Donotcovertheholesinthemainburner(shownbytheredcircles).

  Pilotame  Secondthermocoupleforthemainburner

NB!

Please note that there should be a small intermediary space between the “logs” that lie on

theburnersandbetweenthesurroundinglogs,sothereisspacefortheamesinbetween

them.Ifthereisnotspacefortheames,thereplacewillnotburnoptimallyandsootmay

form.

3

OPSTILLINGSAFSTANDE – OVN MED DREJEFOD

1. Startbysecuringtwoburnersinthereplace’sbaseplate.

123456

Visio 70 RD & T

Youwillndtheseceramiclogsinthepackage:

Procedure:

ARRANGING CERAMIC ”LOGS” AND EMBERS

Note the small bump

on the right side

Note the placement

ofthepilotame!Start

from the opposite side,

as shown in the picture

NB! Fornatural gas and city gas please position the

secondary burners as described in the installation manual

onpage28.

ForLPG gas the secondary burners are delivered with two

rowsofholes,andcanbeplacedasbothrightandleftburner.

4

ARRANGING CERAMIC ”LOGS” AND EMBERS

2. Nowstartfromtheoppositesideofthepilotame-seephoto1onpreviouspage.

Positionlogno.6asshowninthepicture.

3. 

Positionlogno.5asshowninthepicture.Nowtheremaininglogsmustbepositionedfrom

theoppositeside-gotothesamesideasthepilotame.

6

5

3 cm3 cm 7 cm7 cm 6 cm6 cm

2 cm2 cm

3 cm3 cm

5

ARRANGING CERAMIC ”LOGS” AND EMBERS

4. Fromtheoppositesidelogno.4ispositionedasshowninthepicture.

5. Thenpositionlogno.3restingonlogno.4asshowninthepicture.

4

3

12 cm12 cm

7 cm7 cm

1 cm1 cm

7 cm7 cm

11 cm11 cm

6

ARRANGING CERAMIC ”LOGS” AND EMBERS

6. Nowtheglassstonesshouldbespreadoutinthegasreplace.Meassureout5dlofglass

stonesinameassuringcup.

7. Spreadouttheglassstones(5dlintotal)oneachsideofthegasreplace-overtheLED

lights.Itisimportantthattheglassstonesarespreadoutinathinlayerthatcoverstheholes

inthebottomofthereplace.

7

ARRANGING CERAMIC ”LOGS” AND EMBERS

8. Nowmeassureout2,5lofembers(amixofthegreyandblackchips).

9. Spreadtheembers

acrossboththeglassstonesandthebaseplatewiththeholes.

Placethelamentsonthepilotarea.

NB! Itisextremelyimportantthat

you do not cover the pilot area and

the holes there(seepage2).

8

ARRANGING CERAMIC ”LOGS” AND EMBERS

10. 

Positionlogno.1(withtherecess)overtherightburner.

11. 

Positionlogno.2(withtherecess)overtheleftburner.

1

2

9

13. Afterpositioningthelastlogsinthereplace,itisimportantthatthesecondaryburnersare

adjustedtowardseachother.Seedrawingbelow(thereplaceisseenfromthetop).

ARRANGING CERAMIC ”LOGS” AND EMBERS

12. Ensurethatlogsinthecombustionchamberdonottouchlogno.1andlogno.2.There

shouldbespacebetweenthem.

16. Mounttheglassesagain.

ScantheQRcodetoseeavideoofhowtomounttheglass.
