Randell 41048A Manuale utente

1055 Mendell Davis Drive, Jackson, MS 39272

888-994-7636, uniﬁedbrands.net

Information contained in this document is known to be current and accurate at the time

of printing/creation. Uniﬁed Brands recommends referencing our product line websites,

uniﬁedbrands.net, for the most updated product information and speciﬁcations.

Display Merchandiser Ambient Wall-Mount models 41000A

model 41036A 41048A 41060A

model 41048A shown

Standard Features:

• Insulated glass doors are self-closing

• Wall mounting bracket provided

• Foamed in place “CFC free” urethane insulation

• Stainless steel exterior ﬁnish

• Angled display mirror perfectly displays foods served at

room temperature

• Shelving

• Stainless steel interior ﬂoor

• Fluorescent illumination

• Cordset for 120V, plug-in installation

Description:

Ambient, wall mount display case with insulated, self-closing

doors, (2) display shelves, angled display mirror, and ﬂuorescent

illumination. Foamed in place, “CFC free” insulation and cordset

for 115V operation. Wall mounting bracket included.

Specifications:

CABINET EXTERIOR: Cabinet body is constructed of all metal.

The top, front, and sides are stainless steel. Bottom to be

corrosion resistant steel. Self-closing insulated glass sliding

doors. Wall mounting bracket provided. Unit totally prewired and

to be supplied with 8' cordset (NEMA 5-15P) for 115V plug-in

operation.

CABINET INTERIOR: Unit interior to be ABS thermoplastic at ends

only with molded shelf supports, stainless interior bottom, angled

display mirror, and two powder coated display shelves. Interior

top to be stainless steel with ﬂuorescent lighting ﬁxture. Unit

insulated with CFC free, foamed in place urethane insulation.

DOORS: Insulated sliding glass doors on front, to be self-closing

with rubber wiper between doors to minimize air loss. Doors are

easily removable for cleaning.

Randell Display Merchandiser, Page 3

PP SPEC0072 Rev. B

Revised 07/08

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, uniﬁedbrands.net

Information contained in this document is known to be current and accurate at the time

of printing/creation. Uniﬁed Brands recommends referencing our product line websites,

uniﬁedbrands.net, for the most updated product information and speciﬁcations.

Models 41000A

Storage Shelves

Model L D H Style Cu. Ft. Sq. Ft. Volt Amp. NEMA Ship Wt.

41036A 36" 22 1/2" 20" Wall Mount 4 4 115/60/1 2 5-15P 185

41048A 48" 22 1/2" 20" Wall Mount 5.6 5.5 115/60/1 2 5-15P 225

41060A 60" 22 1/2" 20" Wall Mount 6.9 7 115/60/1 2 5-15P 310

Display Case Door Opening Sizes - Interior Depths

Unit Clearances Through Door Interior Depth Behind

Length Lt. to Rt. Top to Bottom Sliding Glass Doors

36" 12 3/4" 15 3/8" 12 3/4"

48" 18 3/4" 15 3/8" 12 3/4"

60" 24 3/4" 15 3/8" 12 3/4"

MODEL # 41036A

AFF =ABOVE FIXED FLOOR

8' LONG CORD SET

(NEMA 5-15P)

JJUNCTION BOX

LEGEND FOR

2.0 Amps

120V/60Hz/1Ph

MODEL # 41036

36"

18"

MODEL # 41048

48"

24"

MODEL # 41060

60"

30"

Drawings are to be viewed in the same order as the chart
