Raven SmarTrax Manuale utente
Case IH 4300 SmarTrax Supplement
& Installation Manual
P/N 016-0190-072 Rev B 09/15
Copyright 2008, 2015
DISCLAIMER
While every effort has been made to ensure the accuracy of this document, Raven
Industries assumes no responsibility for omissions and errors. Neither is any liability
assumed for damages resulting from the use of information contained herein.
Raven Industries shall not be held responsible or liable for the effects of atmospheric
conditions and sunspot activity on the performance of our products.
Raven Industries cannot guarantee the accuracy, integrity, continuity, or availability of
the GPS signal from the US Department of Defense/NAVSTAR GPS satellites, the
OmniSTAR correction service or the WAAS correction service.
Raven Industries accepts no responsibility for the use of the signal for other than the
stated purpose. Raven Industries shall not be responsible or liable for incidental or
consequential damages or a loss of anticipated benefits or profits, work stoppage or
loss or impairment of data arising out of the use or inability to use the Smartrax or any
of its components.
Manual # 016-0190-072
1
CHAPTER
I
NTRODUCTION
Congratulations on your purchase of the Raven SmarTrax system! This
system is designed to provide cutting-edge, hands-free steering of your
machine via GPS coordinates.
CaseIH 4300 SmarTrax Supplement & Installation Manual
2
Basic Kit
Contents
Below you will see the kit contents that you should have received with this
SmarTrax kit.
CaseIH 4300 SmarTrax Kit Contents
Quantity Item Description Part Number
1 Sensor, Yaw 063-0172-684
1 Cable, Hydraulic Solenoid/Override 115-0171-466
1 Weldment, Bracket, Universal Hydraulic Mounting 116-0159-527
1 Kit, Hyd., SmarTrax, CIH 4300 Floater, ‘97 & Earlier 117-0194-072
1 Valve, Flow Control, 1/4” NPTF, w/Fittings 334-0001-053
1 Valve, Hyd., MM, Dual Counterbalance, w/FTGS 334-0003-026
1 Switch, Press., Micro, HD, 15-100 BAR ADJ., w/
Fitting 422-0000-073
4 Bolt, 5/10-18 x 7/8” Hex 311-0052-104
2 Bolt, Machine, 5/16-18 UNC x 3” LONG 311-0052-113
2 Nut, Hex, 5/16-18 UNC 312-1001-034
4 Nut, 3/8-16 312-1001-037
6 Washer, 5/16 Lock, Split 313-1000-022
2 Washer, .312 I.D. x .734 O.D. 313-2300-011
4 Washer, Flat, 3/8” 313-2300-013
1 Valve, Hyd., Open Center, PWM 334-0003-064
1 Manual, Installation 016-0190-072
1 Manual, Installation, SmarTrax 016-9001-012
1 Label, Warning, Do Not Step 041-0159-688
1 Label, Warning, Tampering 041-0159-689
1 FTG., Adapter, Swivel Run Tee, -8 JIC M/M/F 333-0012-039
1 FTG., Elbow, 45° Swivel, -8 JIC M/F 333-0012-040
5 FTG., Elbow, 90° Swivel, -6 JIC M/F 333-0012-042
4 FTG., Adapter, Swivel Run Tee, -6 JIC M/M/F 333-0012-043
1 FTG., Elbow, 90° Swivel, -8 JIC M/F 333-0012-064
2 FTG., Adapter, STR., -6 JIC (F) To -8 JIC (M) 333-0012-118
2 Hose, Hyd., -8 JIC (F) to -6 JIC (F), 24” 214-1000-171
1 Hose, Hyd., -8 JIC (F) to -8 JIC (F), 18” 214-1000-250
1 Hose, Hyd., -8 JIC (F) 90° to -6 JIC (F), 18” 214-1000-428
3 Hose, Hyd., -6 JIC (F) 90° to -6 JIC (F), 12” 214-1000-429
Manual # 016-0190-072
3
CHAPTER
S
AFETY
Hydraulic
Safety
Precautions
When disconnecting the hydraulic hoses or when purging is required, be
aware that the hydraulic oil within the machine system may be extremely
hot and under high pressure. Caution must be exercised. Any work carried
out on the hydraulic system must be performed in accordance with the
machine manufacturer’s approved maintenance instructions. Raven
Industries recommends that appropriate protective equipment be worn
when working on the hydraulic system.
Objects or materials that are able to bypass the machine’s hydraulic
filtration system will adversely reduce performance and possibly damage
the hydraulic valves.
Electrical Safety
Precautions
Do not reverse the power leads. Doing so will cause severe damage to the
equipment. Always check to make sure that the power leads are connected
to the right polarity as marked. Ensure that the power cable is the last cable
to be connected.
Important: Hydraulics are under pressure. Never attempt
to open or work on a hydraulic system with the equipment
running. Care should always be taken when first opening
a system that was previously pressurized.
CaseIH 4300 SmarTrax Supplement & Installation Manual
4
Contacting
Raven
Industries
We welcome your feedback about this manual. If you have any comments
or suggestions for improvement, please let us know by contacting our
Customer Support Center by any of the following methods:
•Via phone: 1-800-243-5435
•Via mail:
Raven Industries
Flow Control Division
205 E. 6th St.
Sioux Falls, SD 57104
•Via email: [email protected]
Manual # 016-0190-072
5
CHAPTER
M
OUNTING
THE
U
NIVERSAL
B
RACKET
AND
H
YDRAULIC
V
ALVE
1. Position the hydraulic valve on the universal bracket, over the top of
the proper hole pattern. Secure the valve to the bracket using the
supplied bolts and washers.
2. Mount the smaller counterbalance valve to the bracket. Two mounting
holes and clearance holes/slots will have to be drilled to mount the
valves as shown. The valve can be moved up on the bracket to allow
the fittings to hang over the edge of the valve.
CaseIH 4300 SmarTrax Supplement & Installation Manual
6
3. Position the bracket on the front of the cab, under the hood.
4. Drill holes to fit the mounting bracket pattern and attach the universal
mounting bracket to the machine using the supplied 3/8” hex bolts.
Manual # 016-0190-072
7
CHAPTER
H
YDRAULICS
Mounting the
Counterbalance
Valve, Pressure
Switch, and
Needle Valve
1. Connect the pressure switch with the tee fitting to the brake port of the
counterbalance valve.
2. Attach the needle valve to the open port of the tee of the pressure
switch.
CaseIH 4300 SmarTrax Supplement & Installation Manual
8
3. Locate and label the ports on the steering orbital as shown below.
