Raymarine ST1000+ Manuale utente

Distributed by

Any reference to Raytheon or

RTN in this manual should be

interpreted as Raymarine.

The names Raytheon and RTN

are owned by the

Raytheon Company.

ST1000+ and ST2000+ Quick Reference Guide

Auto mode

Track mode WindTrim mode

Autopilot displays

or or

1 sec

and and

and

and and

Basic operation

Entering Track mode (from Auto or Wind Vane mode)

Making course changesExtending/retracting the pushrod

Course

changes

to port

Course

changes to

starboard

Entering WindTrim mode

1˚

10˚

Switching lighting on/off

(from Standby mode only)

Switching AutoSeastate on/off

(from Auto/Track/WindTrim modes)

Displaying navigation data

(from Auto or Standby modes)

to accept new heading

to enter Track mode and

Wait 10 sec to return to previous mode.Press -1 and +10 together to exit. D3364-2

then

Returning to Standby (Disengaging the autopilot)Entering Auto mode (Engaging the autopilot)

Returning to previous locked heading

again to accept heading

Press to

switch between:

Press to

switch between:

OFF

Using AutoTack

AutoTack

to port

(100˚)

AutoTack to

starboard

(100˚)

Press standby or auto to exit WindTrim mode.

Press standby or

auto to exit.

Use any of these keys to

extend or retract the pushrod

86022_2.fm Page 1 Monday, July 9, 2001 12:10 PM

Document number: 86022-2 (use with handbook: 81130)

Date: June 2001

ST1000+ and ST2000+ Quick Reference Guide

Enter compass calibration

Turn boat in slow circles

Autopilot displays amount of deviation detected

Align the autopilot heading

Save changes

1 sec

D3363-2

Turn the boat in slow circles so:

•boat's speed stays below 2 knots

•each circle takes at least 3 minutes

To:

•save deviation correction

•save heading alignment

•return to STANDBY mode

To:

•quit compass calibration

without saving

Keep turning the boat until the display alternates between:

•autopilot heading

•deviation detected

Start turning boat

(see 2 below)

Autopilot headingAutopilot heading

Steering

compass

Known

heading

Adjust the autopilot heading to match the boat's steering compass

Compass calibration

11/2–2 circles

86022_2.fm Page 2 Monday, July 9, 2001 12:10 PM
