Raymarine LifeTag System Manuale utente

LifeTag System

Operating Guide

Document reference: 81275-1

Date: April 2006

81275_1.book Page 1 Thursday, April 6, 2006 2:35 PM

Draft copy 06/04/06

Raymarine and SeaTalk are trademarks of Raymarine plc

Important Information

WARNING:LifeTag System

The Raymarine LifeTag system is only an aid to crew safety, and must not be

relied upon as the vessel's main crew safety system. It is the responsibility of the

Captain and all crew members to ensure that all safety instructions and

procedures are in place and obeyed in accordance with local requirements.

Failure to operate this system in accordance with the operating instructions may

result in unreliable or reduced system performance.

WARNING:Lithium Batteries

The LifeTag System Tags use non-rechargeable lithium batteries. Do not attempt

to recharge these batteries. Do not incinerate these batteries. Ensure that these

batteries are replaced with a battery of the same type and check local

regulations when disposing of spent batteries. Incorrectly fitting batteries or

using the wrong battery types may result in un-reliable or reduced system

performance.

General Care & Safety

The operation of some medical electronic devices, such as hearing aids and pacemakers, may be

affected if a LifeTag or LifeTag Base Station is used next to them. Observe the makers

recommendations for such devices.

RF Energy

The LifeTag and Lifetag Base Station are low-power radio transceivers. When on, they

intermittently transmit RF energy (radio waves). The LifeTag and LifeTag Base Station are designed

to comply with the limits for RF energy exposure for the general population set by national

authorities and international health agencies, for example BS EN 50371:2002.

Intended Use

The LifeTag and LifeTag Base Station are intended as an aid to safety on leisure vessels and

small workboats.

Waste Electrical and Electronic (WEEE) Directive

The WEEE Directive requires the recycling of waste electrical and electronic equipment.

Whilst the WEEE Directive does not apply to some of Raymarine's products, we support its policy

and ask you to be aware of how to dispose of this product.

The crossed out wheelie bin symbol, illustrated above, and found on our products signifies that this

product should not be disposed of in general waste or landfill.

Please contact your local dealer, national distributor or Raymarine Technical Services for

information on product disposal.

81275_1.book Page 2 Thursday, April 6, 2006 2:35 PM

Draft copy 06/04/06

LifeTag System Operating Guide

The LifeTag system

All Tags communicating

with Base Station

No alarm

Signal lost from any

Tag

Alarm sounds

Signal lost

a Tag is submerged

The LifeTag system will sound an alarm if . . .

D8883-1

a Tag button is held

down for 3 to 5 sec

then released

a Tag is out of range

(typically 30 ft) of

the Base Unit

SeaTalk alarms

If a LifeTag alarm occurs, a SeaTalk alarm will also be initiated if your LifeTag

Base Station is connected to SeaTalk. For details of how SeaTalk alarms are

indicated, refer to the handbooks for your other SeaTalk products .

81275_1.book Page 1 Thursday, April 6, 2006 2:35 PM

Draft copy 06/04/06

2 LifeTag System Operating Guide

If a Tag is not active,

press and release the

pushbutton to activate

the Tag.

2. Ensure Tags are Active

1. Apply power to Base Station

Base Station

Getting started

Before issuing Tags to crew members, check each Tag to

ensure the LED indicator briefly flashes GREEN once every

10 seconds. This indicates that the Tag is ACTIVE.

If the indicator shows any other indication, check below to determine what to do.

12 V dc

Check that the Alarm 'chirps'

briefly, as power is applied

D884-1

3. Issue Tags to crew

What to do if an alarm occurs

How to carry Tags

What will initiate an alarm

How to know if a Tag is active

How to know when a battery needs changing

Issue Tags to your crew members, then instruct them how to use the LifeTag system.

Color Action Meaning

Searching for Base Station. Wait for a few seconds. If

normal operation does not start, check that the Base

Station is switched on.

Normal operation. The Tag is ready for use.

Continuous half-second flashes

every second

Two flashes once every 10 seconds

Continuous alternating flashes

Brief flash once every 10 seconds

GREEN

GREEN & RED

RED

Low battery. Replace the battery as described in this guide.

Tag LED indications

D8985-1

Alarm indication. Carry out the Man Overboard procedure.

Continuous brief flashesRED Tag is de-registered.

81275_1.book Page 2 Thursday, April 6, 2006 2:35 PM

Draft copy 06/04/06

LifeTag System Operating Guide 3

either or or

in pocket on strap provided on belt

Wearing your Tag

D8890-1

Use extension

if necessary

Using the strap

Ensure each crew member carries an active Tag at all times

when on board.

81275_1.book Page 3 Thursday, April 6, 2006 2:35 PM

Draft copy 06/04/06

4 LifeTag System Operating Guide

What happens when an alarm occurs?

When an alarm is initiated

To cancel a LifeTag alarm

01234

seconds

Repeat every 1 s

until alarm

canceled

The Alarm buzzer sounds

The indicator flashes RED continuously, half-second flashes

every second

On active Tags

Optional 12 V output

Other SeaTalk products

Note: This will NOT cancel alarms on associated SeaTalk

products. Refer to relevant product handbooks for details of

how to cancel these alarms.

Hold in a Tag button for 5 seconds

D8986-1

If the LifeTag Base Station is connected to a Seatalk system which includes a SeaTalk chartplotter and GPS,

and a LifeTag alarm occurs, a MOB marker will be displayed on the chartplotter at the location of the MOB

event. In addition, the chartplotter and compatible Seatalk instruments (such as ST60+ and ST290 Graphic

instruments) will display a MOB 999 Waypoint Name, and range / bearing or latitiude/longitude to the MOB

location,plus elapsed time since the MOB event.

This occurs only with compatible products on SeaTalk systems. It does NOT occur on other products

connected via NMEA0183.

When an alarm condition exists, the Base Station optional, switched output provides 12 V as a switching

voltage, for external equipment.

The Alarm 'chirps' briefly, every 10 seconds

If the Base Station detects that a Tag battery voltage is low:

Tag low battery warning

If this occurs, all users should check their Tags for a

low battery voltage indication (2 RED flashes every

10 seconds). If necessary, replace the battery. D8987-1

81275_1.book Page 4 Thursday, April 6, 2006 2:35 PM

Draft copy 06/04/06

LifeTag System Operating Guide 5

Replacing battery

Discard spent battery in

accordance with local

regulations

Do NOT use a sharp

object to open a Tag

Replace the Tag back

and snap shut

CR2 3V

Open the Tag Remove spent

battery

D8284-1

Ensure correct

polarity

Important!

CR2 3V

1. 2.

Do NOT open a Tag in

wet or dirty conditions

Taking care not to disturb other internal

components, insert NEW, lithium,

non-rechargeable CR2 3V battery.

Looking after your LifeTag system

D8920-1

Never open a Tag unless you want to remove or replace the battery.

Periodically clean the Base Station and Tags, use a clean damp cloth. Do NOT use chemical or

abrasive cleaning agents.

Periocially clean the strap by washing it in fresh water and combing the velcro sections to

remove dirt, fluff etc.

If you are planning not to use the LifeTag system for an extended period (e.g. over winter),

remove the batteries from the Tags, to increase battery life.

Store all components in a dry location, out of direct sunlight , when not in use.

81275_1.book Page 5 Thursday, April 6, 2006 2:35 PM

Draft copy 06/04/06

6 LifeTag System Operating Guide

Raymarine UK Ltd,

Quay Point, Northarbour Road

Portsmouth, Hampshire PO6 3TD,

United Kingdom.

Tel: +44 (0) 23 9269 3611

Fax: +44 (0) 23 9269 4642

www.raymarine.com

Raymarine Inc,

21 Manchester Street, Merrimack,

New Hampshire 03054,

USA.

Tel: +1 603.881.5200

Fax: +1 603.864.4756

www.raymarine.com

Troubleshooting

D8921--1

Base Station indicator lit but buzzer

does not sound

Cannot register Tag

Buzzer connection faulty Ensure buzzer is connected to correct

terminals on Base Station

Base Station indicator does not

light and buzzer does not sound

Base Station not

powered up

Check Seatalk cable is correctly connected

and apply power to SeaTalk

Check that the SeaTalk system is

operating correctly

Alarm sounds when there is no

alarm condition

Tag out of range Perform site survey as described in

LifeTag System Installation &

Commissioning Guide. If unsatisfactory,

redeploy system components to improve

signal coverage

Check that buzzer ‘chirps’ when power

is first switched on

Tag not powered up

Tag battery discharged Replace battery

Ensure Tag battery is correctly installed

All users to check for low Tag battery

and replace as necessary

Tag not powered up

Tag battery discharged Replace battery

Ensure Tag battery is correctly installed

Fault Possible cause Action

Buzzer 'chirps' briefly every 10 s Tag battery low

General information

D9145--1

Approvals

FCC Information

The LifeTag and LifeTag Base Station comply with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) these devices may not cause harmful interference and (2) these devices must accept

interference received, including interference that may cause undesired operation.

Changes or modifications to these devices not expressly approved in writing by Raymarine could violate

compliance with FCC rules and void the user's authority to operate the equipment.

Declaration of Conformity

Raymarine UK Ltd. hereby declares that the LifeTag and LifeTag Base Stationare in compliance with the essential

requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.

The original Declarations of Conformity may be viewed on the relevant product pages at www.raymarine.com.

EU R&TTE Directive 1995/5/EC

USA FCC Part 15 FCC ID: PJ5-LTB (LifeTag Base Station) PJ5-LTT (LifeTag)

Industry Canada RSP100 ID IC4069B-LTB (LifeTag Base Station) IC4069B-LLT (LifeTag)
