Razer RZ04-024901 Manuale utente
DTD:13/11/2019
Wireless Headset Model:
RZ04-024901
F OR G A ME R S . BY G A M E RS .™
1
WHAT’S INSIDE
▪Wireless Headset model:RZ04-024901
A. Adjustable padded leatherette
headband
B. Rotatable circumaural ear cup
design
C. Plush memory foam ear cushions
D. ANC/Ambient button
E. Status indicator
F. Power button
G. 3.5mm audio socket
H. USB-C port
I. Mic diaphragm
J. Volume up button
K. Center button
L. Volume down button
▪Premium Carry Case
▪3.5mm audio cable
▪USB-C charging cable
▪USB-A to USB-C adapter
▪Airline headphone adapter
F OR G A ME R S . BY G A M E RS .™
2
WHAT’S NEEDED
PRODUCT REQUIREMENTS
▪[Wireless mode] Devices with Bluetooth connectivity
▪[Wired mode] Devices with a 3.5mm headphone socket
MOBILE APP REQUIREMENTS
▪iOS or Android device with Bluetooth connectivity
▪Internet connection
▪50 MB of free storage space for iOS
▪10 MB of free storage space for Android
F OR G A ME R S . B Y G A M ER S .™
3
LET’S GET YOU COVERED
You’ve got a great device in your hands complete with a 2-year limited warranty coverage.
Now maximize its potential and score exclusive Razer benefits by registering at
razerid.razer.com
Your product’s serial
number can be found
here.
F OR G A ME R S . B Y G A M ER S .™
4
GETTING STARTED
CHARGING YOUR HEADSET
Connect your Razer Opus directly to any USB-C port using the charging cable or to any USB-
A port using the adapter. For best results, please fully charge your headset before using it for
the first time. A depleted battery will fully charge in about 4 hours.
F OR G A ME R S . B Y G A M ER S .™
5
While charging, your Razer Opus will continuously show its battery level on the status
indicator, as shown here:
WIRELESS MODE
While powered off, press and hold the power button until the status indicator starts blinking
blue. A pairing mode tone will notify you that your Razer Opus is searching for compatible
Bluetooth devices. Follow your device’s instructions to pair it with your Razer Opus. Once the
headset is paired, the status indicator will change to static blue.
WIRED MODE
Connect your Razer Opus to any 3.5mm audio socket using the provided 3.5mm audio cable.
You can also use the airline headphone adapter along with the 3.5mm audio cable for in-flight
audio jacks. As long as your headset is powered on, you can still use ANC and Ambient
Awareness in wired mode.
STATUS
INDICATOR
DESCRIPTI
ON
Charging
Fully charged
Pairing
Paired
F OR G A ME R S . B Y G A M ER S .™
6
USING YOUR RAZER OPUS
POWER ON/OFF
Press and hold the power button until the status indicator turns green to power on. Press and
hold the power button again until the status indicator turns red to power off. Two distinct tones
will help notify you that your Razer Opus is powered on or off.
BATTERY LEVEL
While unplugged, your Razer Opus will briefly show its battery level on the status indicator
when you power on the headset. While in use, there will be a tone notification when the
battery needs recharging, as shown here:
F OR G A ME R S . B Y G A M ER S .™
7
STATUS
INDICATOR
TONE
NOTIFICATIO
N
DESCRIPTIO
N
None
Battery
sufficiently
charged
Once
Battery low
Every 5
minutes
Battery
critically low
F OR G A ME R S . B Y G A M ER S .™
8
HEADSET CONTROLS
The following controls are available when connected to your device via Bluetooth. These
controls operate based on your device’s current activity.
Note: Some features listed here may not be applicable to certain devices.
VOLUME UP BUTTON
Single press
Increase audio volume
Press and hold
Continuously increase audio volume
VOLUME DOWN BUTTON
Single press
Decrease audio volume
Press and hold
Continuously decrease audio volume
CENTER BUTTON
Single press
Play/pause
Accept incoming call or end current
call
Put call on-hold and accept incoming
call
End call and swap to on-hold call
Press and hold
Launch voice command
Reject incoming call
Swap calls
Double press
Skip track
Triple press
Rewind track
F OR G A ME R S . B Y G A M ER S .™
9
ACTIVE NOISE CANCELLATION (ANC)
Active Noise Cancellation helps eliminate background noise. While powered on, press the
ANC/Ambient button to enable or disable ANC. Two distinct tones will notify you that the ANC
is either enabled or disabled. Active noise cancellation will work for both wired and wireless
connection.
`
AMBIENT AWARENESS
Ambient awareness allows you to hear your surroundings without needing to remove your
headset. While connected via Bluetooth, press and hold the ANC/Ambient button to activate
ambient awareness. To deactivate this function, simply remove your finger from the button.
