Razer Orochi Manuale utente
1 | razer
The Razer Orochi is the most advanced mobile gaming mouse available today. It is the
perfect companion to any laptop, delivering the competitive edge to your gaming
whether at home or on-the-go.
The Razer Orochi is designed to be compact and portable, and it is now outfitted with
the most precise sensor in a mobile mouse. Get twice the performance with the Razer
Orochi’s 6400dpi 4G laser sensor. With wired or wireless Bluetooth functionality, you
can experience the frenzy of fast gameplay or freedom of movement. The Razer
Orochi’s extended battery life, ensures double your gaming time from its predecessor.
2 | For gamers. by gamers.™
TABLE OF CONTENTS
1. PACKAGE CONTENTS / SYSTEM REQUIREMENTS................................................ 3
2. REGISTRATION / TECHNICAL SUPPORT............................................................... 3
3. TECHNICAL SPECIFICATIONS............................................................................... 4
4. DEVICE LAYOUT.................................................................................................. 5
5. SETTING UP YOUR RAZER OROCHI...................................................................... 6
6. INSTALLING YOUR RAZER OROCHI.................................................................... 10
7. CONFIGURING YOUR RAZER OROCHI ............................................................... 11
8. SAFETY AND MAINTENANCE ............................................................................ 27
9. LEGALESE ......................................................................................................... 30
3 | razer
1. PACKAGE CONTENTS / SYSTEM REQUIREMENTS
PACKAGE CONTENTS
xRazer Orochi 2013
x2x AA Batteries
xUSB Cable
xTravel Pouch
xQuick Start Guide
SYSTEM REQUIREMENTS
xBluetooth® enabled PC / Mac with USB Port
xWindows® 8 / Windows® 7 / Windows Vista® / Mac OS X (10.6-10.7)
xInternet connection
x100MB of free hard disk space
2. REGISTRATION / TECHNICAL SUPPORT
REGISTRATION
xPlease visit www.razerzone.com/registration for online product registration.
TECHNICAL SUPPORT
What you’ll get:
x2 years limited manufacturer’s warranty.
xFree online technical support at www.razersupport.com.
4 | For gamers. by gamers.™
3. TECHNICAL SPECIFICATIONS
x6400dpi 4G laser sensor
xGaming-optimized Bluetooth 3.0 wireless connectivity
xSynapse 2.0 enabled
xAmbidextrous form factor
xPowered by 2x AA batteries
x30 hours battery life for continuous use
xPower on/off switch
xLED on scroll wheel
xAdditional low battery indicator
xApproximate Size:
Length: 99 mm / 3.90”
Width: 67 mm / 2.64”
Height: 35 mm / 1.38”
xApproximate Weight: 68 g / 0.15 lbs
5|razer
4. DEVICE LAYOUT
A. Left Mouse Button
B. Right Mouse Button
C. Scroll Wheel
D. Battery / Pairing Indicator
E. Mouse Button 5
F. Mouse Button 4
G. Sensitivity Stage Up
H. Sensitivity Stage Down
I. Razer Precision 4G Laser Sensor
J. Power On / Off Switch
K. Ultraslick Mouse Feet
L. USB Cable
6 | For gamers. by gamers.™
5. SETTING UP YOUR RAZER OROCHI
WIRELESS MODE
1. Remove the top cover of the Razer Orochi.
2. Insert the batteries into the Razer Orochi following the directions indicated.
3. Reattach the top cover onto the Razer Orochi. Please ensure it is secured.
7|razer
4. Switch on the Razer Orochi.
5. Please ensure that Bluetooth is activated on your computer. “Add a Bluetooth
device” by following the instructions for your operating system. Activate the
pairing process by depressing all four side buttons together on the Razer Orochi
for five seconds. The indicator lights on the top of the Razer Orochi will blink in
green to indicate the pairing process.
6. When the pairing process is completed, the indicator light will stop blinking. Your
Razer Orochi is then ready for use in wireless mode.
8 | For gamers. by gamers.™
WIRED MODE
1. Connect the micro-USB end of the cable to the Razer Orochi.
2. Plug the mouse into the USB port of your computer. The Razer Orochi is then
ready for use as a high performance wired gaming mouse.
9 | razer
BATTERY / PAIRING INDICATOR BEHAVIOR
The Razer Orochi has a battery indicator on its top cover, which displays the status of
battery life. While in pairing mode, the indicator will be blinking in green.
Note: For safety, use only alkaline batteries and do not mix old batteries with new ones.
BATTERY INDICATOR BEHAVIOR
31% to 100% Battery
Green lit LED
11% to 30% Battery
Red lit LED
Below 10% Battery
Red blinking LED
Bluetooth pairing mode Green blinking LED
10 | For gamers. by gamers.™
6. INSTALLING YOUR RAZER OROCHI
Note: You may skip Steps 2-4 if you already have a Razer Synapse 2.0 installed and an existing account.
Step 1: Plug the Razer Orochi into the USB port of your computer.
Step 2: Download the Razer Synapse 2.0 installer from www.razersupport.com.
Step 3: Run the installer and follow the on-screen instructions.
Step 4: Register for a Razer Synapse 2.0 account and confirm your new account.
Step 5: Open Razer Synapse 2.0 and login to your account.
Step 6: Wait until the software automatically downloads and installs.
