Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM PST.
1
WARNING
Do not use non-Razor products with your Razor electric
product. This item has been built to certain Razor design
specifications. Certain aftermarket parts may not be
compatible and will void your warranty.
As with all consumer electronics, use of compatible
batteries and chargers is strongly recommended. Failure
to do so may pose a fire hazard.
Examine the battery, charger and their connectors for
excessive wear or damage each time you charge the
battery. If damage or excessive wear is detected, do not
use the charger or the product until you have replaced
the worn or damaged part.
Battery connectors may contain lead and lead
compounds. Wash your hands after handling.
Tools Required: (Not included)
A. 5 mm Allen wrench
B. 10 mm wrench
CAUTION: To avoid potential shock or other injury, turn power switch OFF and disconnect charger
before removing or installing the batteries. Failure to follow these steps in the correct order may cause
irreparable damage.
Step 1
Figure 1a Figure 1b
Using a 5 mm Allen wrench, loosen the four (4) hex
bolts that attach the seat to the frame (Figure 1a)
and remove seat. Remove the two (2) hex bolts on
the Drift Bar cover (Figure 1b) and remove.
Step 2
Figure 2a Figure 2b
Using a 5 mm Allen wrench and a 10 mm wrench,
loosen the two (2) hex bolts on the side of the
battery cover (Figure 2a) and the two (2) locknuts,
located underneath the unit (Figure 2b).
CRAZY CART
BATTERY INSTALLATION INSTRUCTIONS
W25143499003
Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM PST.
2
Step 7
Step 3 Step 4
Figure 4
Using a 5 mm Allen wrench, loosen the two (2)
hex bolts on both sides of the battery bracket and
remove.
Step 5
Figure 5
Locate the white plastic connector on the battery
that attaches to the control module and disconnect
by depressing the tab on the connector.
Step 6
Figure 6
Using both hands, carefully remove the batteries.
Reverse steps 1 through 6 to install replacement batteries.
ATTENTION: Charge battery 12 hours before initial use.
Figure 3
Remove the battery cover by lifting up the right side
first then slide off. Be careful not to pull any of the
wires that are attached to the cover.
Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM PST.
3
Battery Care
Battery Disposal
Battery Care:
Charge a new battery for at least 12 hours before initial
use. Never charge the battery longer than 24 hours.
Overheating or undercharging the battery may shorten
battery life and decrease product run time.
After the first charge, recharge the battery for at least 12
hours after each use. Charge the battery after each use,
regardless of how long the product was used.
Do not allow the battery to run down completely before
charging.
Charge the battery at least once per month, even if the
product has not been used.
Charge the battery before storing the product. Leaving
the battery in a discharged condition can result in a
battery that will no longer take a charge.
Do not store in freezing or below freezing temperatures.
Charger:
The charger supplied with the scooter should be
regularly examined for damage to the cord, plug,
enclosure and other parts and in the event of such
damage, the scooter must not be charged until the
charger has been repaired or replaced.
Your Razor product uses sealed lead-acid batteries which must be recycled or disposed of in an environmentally
sound manner. Do not dispose of a lead-acid battery in a fire. The battery may explode or leak. Do not dispose of a
lead-acid battery in your regular household trash. The incineration, land filling or mixing of sealed lead acid batteries
with household trash is prohibited by law in most areas. Return exhausted batteries to a federal or state approved
lead-acid battery recycler or a local seller of automotive batteries. If you live in Florida or Minnesota, it is prohibited by
law to throw away lead-acid batteries in the municipal waste stream.
CONTAINS SEALED LEAD-ACID BATTERY. BATTERY MUST BE RECYCLED.
WARNING: If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic
bag. Refer to the disposal instructions below. If acid comes into contact with skin or eyes, flush with cool water for at
least 15 minutes and contact a physician.
