RCA 8 Apollo RCT6573W23 Manuale utente

RCT6573W23

8 Apollo

User Manual

It's important to read these instructions prior to using your new

product for the ﬁrst time.

EN - 1

Safety Precautions

Equipment tested for

compliance as a

complete unit

FCC Information

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this

device must accept any interference received, including

interference that may cause undesired operation.

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part

15 of FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference

by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and

receiver.

•Connect the equipment into an outlet on a circuit different

RCT6573W23

EN - 2

CAN ICES-3(B) / NMB-3(B)

This device complies with Industry Canada license-exempt

RSS standard(s). Operation is subject to the following two

conditions: (1) this device may not cause interference,

and (2) this device must accept any interference, including

interference that may cause undesired operation of the

device.

Le présent apparei l est conforme aux CNR d’Industrie

Canada applicables aux appareils radio exempts de licence.

L’exploitation est autorisée aux deux conditions suivantes: (1)

l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur

de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le

fonctionnement.

This EUT is in compliance with SAR for general population/

uncontrolled exposure limits in IC RSS-102 and had been

tested in accordance with the measurement methods and

procedures specified in IEEE 1528.

Caution:

Use of controls or adjustments or performance of procedures

other than those specified may result in hazardous radiation

exposure.

from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician

for help.

Warning: Changes or modifications not expressly approved

by the party responsible for compliance (MLB International

Inc., P.O. Box 1535, Buffalo, NY 14226, Tel: 516-236-4556)

could void the user’s authority to operate the equipment.

EN - 3

Warning:

The AC adapter is used as disconnect device and it should

remain readily operable during intended use.

In order to disconnect the mains plug from mains

completely, the AC adapter should be disconnected from

the mains socket outlet completely.

Service Information

This product should be serviced only by those specially

trained in appropriate servicing techniques. For instructions

on how to obtain service, refer to the warranty included in this

guide.

Some of the following information may not apply to your

particular product; however, as with any electronic product,

precautions should be observed during handling and use.

•Read these instructions.

•Keep these instructions.

•Heed all warnings.

•Follow all instructions.

•Do not use this apparatus near water.

•Clean only with dry cloth.

•

Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

•Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including

ampliﬁers) that produce heat.

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ AND

SAVE THIS FOR FUTURE REFERENCE

EN - 4

ADDITIONAL SAFETY INFORMATION

•The AC adapter and apparatus shall not be exposed to

dripping or splashing and no objects filled with liquids,

such as vases, shall be placed on the apparatus.

•Always leave sufficient space around the product for

ventilation. Do not place product in or on a bed, rug, in

a bookcase or cabinet that may prevent air flow through

vent openings.

•Do not place lighted candles, cigarettes, cigars, etc. on

the product.

•Care should be taken so that objects do not fall into the

product.

•Do not attempt to disassemble the cabinet. This product

does not contain customer serviceable components.

•To prevent the risk of fire or electric shock, do not

expose this apparatus to rain or moisture.

•Do not play your headset at high volume. Hearing

experts warn against extended high-volume play.

•Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the

point where they exit from the apparatus.

•Only use attachments / accessories specified by the

manufacturer.

•Unplug this apparatus during lightning storms or when

unused for long periods of time.

•Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug

is damaged, liquid has been spilled or objects have fallen

into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been

dropped.

EN - 5

Safety Precautions .....................................................1

Important Safety Instructions ................................... 4

Startup ..................................................................... 6

Overview of Controls ........................................................ 6

Buttons .......................................................................... 6

Accessories ................................................................... 8

Navigating the Home Screen .......................................... 9

Connections ............................................................. 13

Battery Management and Charging ............................... 13

Micro-USB .....................................................................14

Headphone ..................................................................... 15

Micro SD .......................................................................15

Wi-Fi ...............................................................................16

Basic Operation ....................................................... 17

First Time Operation ............................................................... 17

Basic Operation ...................................................................18

Google NowTM ........................................................................ 19

Voice Search & Voice Actions ................................................ 19

Google PlayTM ........................................................................ 20

Settings ............................................................................... 21

GoogleTM ................................................................................22

Preinstalled Apps ..................................................... 23

Additional Information ............................................ 24

Trouble Shooting .................................................................. 24

Specifications .......................................................................25

Limited Warranty ..................................................... 26

Contents

EN - 6

Front Camera

Overview of Controls

Startup

Power button

Micro-USB port

Reset

Microphone

Headphone jack

EN - 7

Item Description

Power button Press to enter standby/wake up mode,

press and hold to switch On/Off the unit.

Headphone jack Headphone connection for personal

listening.

Speaker

VOLUME +/-

button

Micro SD

card slot

Rear camera

EN - 8

Microphone For voice input.

Micro-USB port Connect to a PC or USB storage device;

Or use to charge the battery.

Reset Reset the tablet.

VOLUME+/- button Press to increase/decrease the volume.

Micro SD card slot

Accepts micro SD card (up to 32G).

Accessory

The following accessory is included.

AC Adapter ......................................................................... x1

Buttons

Power Button

Power the Tablet On

Press and hold the Power button until the RCA logo appears.

Power the Tablet Off

Press and hold the Power button until a message box

appears and tap "Power off", then tap "OK" and the tablet will

be powered off.

Sleep Mode

Brieﬂy press the Power button to put the tablet in sleep mode.

If you don’t operate for some time, the tablet will enter sleep

mode automatically.

Tip: You can go to Settings -> DEVICE -> Display -> Sleep

to set the screen timeout.

Wake the Tablet from Sleep Mode

Press the Power button to wake the tablet from sleep mode.

Vol +/- Button

Press the Vol +/- button to increase or decrease the volume.

Tip: You can go to Settings -> DEVICE -> Sound -> Volumes

to adjust volume settings for Music, Video, Games & other

media, Notiﬁcations and Alarms.

EN - 9

Navigating the Home Screen

App Icons

Status Bar

Google

SearchTM

Speakers

Notification Bar

Recent Apps

HomeBack

All Apps

Notiﬁcation & Status Bar

Some indicators that inform you about the status of your tablet

are shown at the top of the screen.

Notiﬁcation Shade

Notifications may come from the system, a game, an

application such as E-mail, or the music player.

Setting
