Rear view safety RVS-AC700 Manuale utente
1
TM
Warning
1. This is a high precision product. Do not let it fall or get crushed.
2. Do not expose to strong, magnetic objects and electrical motors.
Avoid strong radio waves. Strong magnetic fields may cause the product
to break down or cause damage to images and sounds.
3. Never leave the product exposed to high temperatures and direct
sunlight.
4. Please choose branded MicroSD cards. Neutral cards are not guaran
teed to work normally.
5. Do not place Micro SD cards near strong magnetic objects to avoid
data loss.
6. n case of overheating, smoke, or unpleasant smell in the process of
charging, unplug your device immediately to prevent fire hazard.
7. While it is charging, keep the product out of children’s reach. Power
line may cause children accidental suffocation or electric shock.
8. Keep the device in cool, dry and dustproof places.
Preface
This product is a highdefinition digital motion video recording
device tailored to market demand. t has a variety of industryleading
features including digital video recording, photo shooting, audio record
ing, video display and a detachable battery, which makes it perfect for
vehicle data recording, photoshooting, outdoor sports, home security,
deepwater probing, etc., allowing you to film anytime, anywhere. t has
a variety of patents.
Multipurpose
REAR V EW SAFETY
2
ntroduction
►A waterresistant casing that allows you to film fascinating water
sports; waterresistant up to 30 meters under water
►High definition screen that displays and replays fascinating videos
recorded
►Detachable battery that is easy to replace and prolongs your camera’s
service life
►Video recording while charging
►Video recording with battery
►12megapixel HD wideangle lens
►HDM HD output
►Web camera
►Supports storage cards up to 32GB maximum
►Multiple video recording formats: 1080P/720P
►Records in MOV format
►Multiple photo shooting modes: Single Shot, Burst Mode
►Video encryption enabled
3
Reverse With Confidence™
Product Features
REAR V EW SAFETY
4
Picture of Product
5
Reverse With Confidence™
Picture of Product
REAR V EW SAFETY
6
Accessories
Optional Accessories
7
Reverse With Confidence™
Picture of Product
1. Inserting Micro SD Card
Note: Please choose branded Micro SD card and format it on computer
before use. Neutral cards are not guaranteed to work normally.
2. Installing and Re oving Batteries
A. Press on battery cap to open it.
B. Correctly install battery into camera as indicated by +/ symbols
and direction of arrows marked on battery until it’s in place.
C. Battery Gauge: Please refer to diagram.
D. Remove Battery: Open cap to take battery out.
3. Charging
A. Charging can be done by either connecting AC700 to computer or
power adaptor.
B. AC700 can record video while charging (Switch into Vehicle
mounted Mode in “Menu”)
C. Charging of AC700 can be done even when it’s powered off.
4. Switching Ca era On and Off
A. Press and hold power switch for 3 to 5 seconds to turn it on/off.
B. Switch it on and off by turning display screen on and off.
5. Mode Switching
Switch between video recording/photo shooting/playback/menu by
pressing “Power OnOff” button,
6. How to record videos and configure recording settings
A. Video Recording
Switch to recording mode and there’ll be an icon in the upper left
of the screen. Press OK to start recording and the icon in the
upper left
REAR V EW SAFETY
8
Functions
corner will start to flash. Press “OK” again if you want to stop and the
icon will disappear.
B. Photo shooting & Settings
Switch the camera on and press “Mode” to select “Photo shooting
Mode”, there’ll be an icon in the upper left corner of display screen
and the camera is in photo shooting mode. Press “OK” to take photos.
Shooting Pattern: Single shot/Selftimer (2s/5s/10s)/Continous Shoot
ing
C. File Storage & Playing
After you are done recording, use a USB cable to export the videos
onto a computer to play. Alernatively you can take the Micro SD card
out and access the images data with a card reader.
9
Reverse With Confidence™
Operations
REAR V EW SAFETY
10
Specifications
Liquid Crystal Display (LCD) 1.5LTPS
Lens 170° A + HD wide-angle lens
Language Options English/German/French/Spanish/ talian/P
ortuguese/Chinese Traditional/Chinese
Simplified/Japanese/Russian
Resolution of Videos Recorded 1080P (1920*1080) 30FPS
720P (1280*720) 30FPS
VGA (848*480) 30FPS
QVGA (640*480) 30FPS
Video Format MOV
Compressed Format of Videos H.264
Resolution of Photos 12M/8M/5M
Storage MicroSD
Shooting Mode Single Shot/Selftimer (2s/5s/10s/Conti
nous Shooting)
Frequency of Optical Source 50Hz/60Hz
USB nterface USB2.0
Power Source nterface 5V2A
Battery Capacity 900MAH
Power Dissipation [email protected]
Recording Time 60 FPS/ About 50minutes, 30FPS/ About
70 minutes
Charging Time About 3 hours
Operating System (OS) Windows XP/Vista or above/Win7/MAC
Dimension 59.27*41.13*29.28
Note: Specifications could be subject to modification due to upgrading
or updating. Please regard the actual product as the standard form.
Note: For 1080 60 FPS recordings you will need to use a Class 6 or
higher Micro SD card.
