HandPunch 1000

Installation and Operation Manual

Recognition Systems Inc.

1520 Dell Ave.

Campbell, CA 95008

Customer Care: 408-341-4110

RSI Main Tel: 408-341-4100

RSI Main Fax: 408-341-4101

Web: www.handreader.com

P/N: 70100-6009

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used

in accordance with the Installation Manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful

interference, in which case the user will be required to correct the interference at the user’s own

expense.

This Class A digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulations.

Cet appareil numerique de la classe A respecte toutes les exigences du Reglemente sure le

materiel brouilleur du Canada.

Document Part Number: 70100-6009 – Revision 1.2 – March, 2002

HandPunch is a trademark of Recognition Systems, Inc.

Windows is a trademark of Microsoft Corporation.

The trademarks used in this Manual are the property of the trademark holders. The use of these

trademarks in this Manual should not be regarded as infringing upon or affecting the validity of

any of these trademarks.

Recognition Systems, Inc. reserves the right to change, without notice, product offerings or

specifications.

No part of this publication may be reproduced in any form without the express written permission

of Recognition Systems, Inc.

HandPunch 1000 Installation and Operation Manual

Revision 1.2 Page 3

Table of Contents

HandPunch 1000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Biometrics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Principle of Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

The HandPunch Terminal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Planning an Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Site Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

HandPunch Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Mechanical Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Wall Plate Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Wiring Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Wiring Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Setting the DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

End of Line Termination. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Communication Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Erasing HandPunch Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Closing the HandPunch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Powering the HandPunch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Programming the HandPunch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Authority Level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Programming Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

System Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Design an ID Numbering System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Enter a Command Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Service Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Management Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Enrollment Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Special Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

HandPunch 1000 Installation and Operation Manual

Page 4 Revision 1.2

This page is intentionally left blank.

HandPunch 1000 Installation and Operation Manual

Revision 1.2 Page 5

1.0 HandPunch 1000

The HandPunch 1000 is a member of the Recognition Systems’ line of biometric hand

geometry Time and Attendance Terminals1. The HandPunch records and stores the

three-dimensional shape of the human hand for comparison and identity verification.

Upon verification, the HandPunch records the time, date, user ID number, and

collected time and attendance data for collection by a host computer. The HandPunch

can communicate with a host computer.

The HandPunch provides proof-positive employee identification combined with the

sophisticated operating features one expects in a modern Time and Attendance

Terminal. Because of this unique combination of capabilities, the HandPunch provides

the most accurate Time and Attendance data collection terminal available. The key

features of the HandPunch include:

• Transaction Buffer

- 5,120 event capacity

• Programmable Clock and Date Formats and Daylight Savings Switch-over

1.1 Biometrics

Biometrics is a term describing the automatic measurement and comparison of human

characteristics. While its origins are ancient, the evolution of advanced scanning and

microprocessor technology brought biometrics into everyday life. Electronic hand

geometry technology first appeared in the 1970s. Recognition Systems Inc., founded

in 1986, built the first mass-produced hand geometry readers and made biometric

technology affordable for the commercial market. Today, Recognition Systems’

products are in use in every imaginable application from protecting cash vaults to

verifying employee attendance in hospitals.

1. For the sake of using a consistent name throughout the manual, the HandPunch 1000 terminal is

referred to as the HandPunch for the remainder of this manual.

HandPunch 1000 Installation and Operation Manual

Page 6 Revision 1.2

1.2 Principle of Operation

The HandPunch uses low-level infrared light, optics, and a CCD (IC chip) camera to

capture a three-dimensional image of the hand. Using advanced microprocessor

technology, the HandPunch converts the image to an electronic template. It stores the

template in a database with the user’s ID number.

To gain punch, the user enters his or her ID number at the HandPunch’s keypad or uses

an external card reader. The HandPunch prompts the user to place his or her hand on

the HandPunch’s platen1. The HandPunch compares the hand on the platen with the

user’s unique template. If the images match, the HandPunch records the transaction for

processing.

1.3 The HandPunch Terminal

The HandPunch is a time and attendance terminal designed for use with time and

attendance software. Refer to Figure 1-1 on page 7 when reviewing the information in

this section.

The HandPunch has an integrated keypad for ID entry (see Figure 1-1). The

and keys are used for data entry and programming.

Four different features assist the user with hand placement and read verification.

1. A light emitting diode (LED) hand placement display on the HandPunch’s top

panel assists users with hand placement on the platen.

2. A liquid crystal display (LCD) shows operational data and programming menus.

3. “Red light/Green light” verification LEDs quickly inform users if their verification

attempts were rejected or accepted.

4. An internal beeper provides audible feedback during keypad data entry and user

verification.

1. The Platen is the flat surface at the base of the HandPunch (see Figure 1-1). This is where users

place their hands for enrollment and verification. It has guide pins to assist positioning the

fingers during use.

CLEAR ENTER

HandPunch 1000 Installation and Operation Manual

Revision 1.2 Page 7

Figure 1-1: The HandPunch 1000

No Enter

Clear

Recognition Systems Inc.

PLATEN AND GUIDE PINS

HAND

PLACEMENT

DISPLAY

LCD DISPLAY

VERIFICATION

LIGHTS

UMERICAL

KEYPAD

HandPunch 1000 Installation and Operation Manual

Page 8 Revision 1.2

1.4 Specifications

Table 1: Specifications

Size: 8.85 inches wide by 11.65 inches high by 8.55 inches deep

22.3 cm wide by 29.6 cm high by 21.7 cm deep

Power: 12 to 24 VDC or 12 to 24 VAC 50-60 Hz, 7 watts

Weight: 6 lbs (2.7 kg) – 7 lbs (3.2 kg) with optional backup battery

Temperature: -10°C to +60°C – non-operating/storage (14°F to 140°F)

5°C to 40°C – operating (40°F to 110°F)

Relative Humidity

Non-Condensing:

5% to 95% – non-operating/storage (non-condensing)

20% to 80% – operating

Verification Time: 1 second or less

Memory Retention: 5 years using a standard internal lithium battery

Transaction Buffer: 5,120 transactions

ID Number Length: 1 to 10 digits

Baud Rate: 300 to 28.8 K bps

Communications: RS-232, optional Modem

User Capacity: 50, 100, 512 users

HandPunch 1000 Installation and Operation Manual

Revision 1.2 Page 9

1.5 Options

The HandPunch has the following options available.

• Backup Battery Support See Technical Note 70200-0012 – Rev. C

• Modem Communication See Technical Note 70200-0013 – Rev. C

• Memory Upgrade See Technical Note 70200-0039 – Rev. A

Recommended European Power Supply:

Ault, Inc.

7300 Boone Ave. North

Minneapolis, MN 55428 USA

PH: 612-493-1900

E-mail: [email protected]

Part number: D48-121000-A040G

230 VAC Input, 12 VDC @ 1Amp output (unregulated)

Ault style #41 connector (barrel plug)

approved

recyclable

HandPunch 1000 Installation and Operation Manual

Page 10 Revision 1.2

This page is intentionally left blank.
