PIR Sensors

Product Codes: PIRB1, PIRW1

Box Contents -

1 x PIR Sensor

Dimensions: L: 125 x W:76 x D:100mm

Material: Flame Retardant ABS

IP Rating: IP44

Working

Temperature: -10°C - 40°C

Guarantee: 1 Year

Safety Warning

• The installation should be carried out

by a qualied electrician in compliance

with the current edition of the IEE

Wiring Regulations.

• Prior to installation, carry out the

necessary risk assessment considering

the people who could be at risk,

the level of risk and the precautions

required to control the risk

• Ensure that the circuit supply is

isolated either by the circuit supply

fuse being removed or the applicable

circuit breaker being turned o before

installation or any maintenance.

• Check the total load on the circuit

ensuring the luminaire does not exceed

the rating of the circuit cable, fuse or

circuit breaker.

• Long-term use and voltage uctuations

can reduce the life span of the tting.

• If the tting incorporates control gear,

ensure careful sizing to avoid instances

of nuisance tripping of the protective

device used in the installation.

• Follow the provided installation

instructions, using the xings supplied

or recommended.

• Keep out of reach of children.

INSTALLATION INSTRUCTIONS

Specication

Avoid installing it near heating or air conditioning.

N-Blue

L-Brown

Red

Connect Blue to the Neutral of the load and Red to the Live of the load. This product must be installed by a qualied electrician.

Installation Instructions

GUARANTEE

YR IP44

240V

L125mm

D100mm

W76mm

• The Sensor is equipped with two adjustment controls;

• After installation, please turn the time controller anti-clockwise to the minimum position before you switch on the power. Turn the lux control anti-

clockwise to the minimum value.

• Restore the main power; the light will be on for 30seconds.

• Adjust the lux and the time with the controls to suit your requirement.

Test: Auto Mode

PAGE 4 (THREE - INSIDE DPS)

PAGE 3 (TWO - INSIDE DPS)

This product is guaranteed for a period of 1 year from the date of purchase. The guarantee is invalid in the case of improper use, tampering, removal of the Q.C.

date label, installation in an improper working environment or installation not according to the current edition of the I.E.E. Wiring Regulations (BS7671). The

guarantee is also invalidated if the luminaire has been insulation tested. Should this product fail during the guarantee period it will be replaced free of charge,

subject to correct installation and return of the faulty unit. We do not accept responsibility for any installation costs associated with the replacement of this

product. Your statutory rights are not aected. We reserve the right to alter specications without prior notice.

Guarantee

• This tting will require routine cleaning if used in adverse (dust, paint, welding, oils etc) environments. Do not use solvents, aggressive detergents or

abrasives.

• When this tting comes to the end of it’s life or you choose to replace it, please do not dispose of it with your normal waste. Please recycle where the

facilities exist, check with your local authority for suitable options.

Maintenance

INS/ACCESSORIES/0007/PIR/V1

T: 0800 195 0006

sales@redarrowelectrical.co.uk

Red Arrow Electrical Distribution

Cortonwood Drive, Brampton,

Barnsley, S73 0UF

redarrowelectrical.co.uk

• To test the MANUAL mode (light permanently on), switch the light o and on quickly within 1-2 seconds at the light switch. The light should remain

permanently on regardless of the sensor operation.

• To reset the light into AUTO mode, switch it o for approximately 30-60 seconds before switching back on.

• After successfully testing the light, please ensure you adjust the settings to the desired LUX and TIME settings. Position the angle of the sensor head so

that the optimum coverage is achieved.

Test: Manual Mode

• To override the AUTO sensor mode and to use the light tting as an ordinary light, it needs to be switched to MANUAL mode. To do this, switch the unit o
