USER MANUAL
Please read and keep these instrucons
ALL TERRAIN
COMPACT SEAT WALKER
RG4412
redgumbrand.com.au
REDGUM Brand owns the copyright to the All Terrain Compact Seat Walker user manual.
Any informaon contained in this user manual shall not be photocopied, reproduced or
translated into any other languages without the prior wrien consent of REDGUM Brand.
REDGUM Brand strives to provide the highest quality products possible.
Product is subject to change without noce.
© Copyright REDGUM Brand 2021
REDGUM Brand is part of FOR-DE Group Pty Ltd
redgumbrand.com.au
CONTENTS
1. INTRODUCTION - INTENDED USE
2. PRODUCT OVERVIEW - FEATURES / SPECIFICATIONS
3. SET UP - UNPACK and INSPECT SUPPLIED PARTS
4. SET UP - UNFOLDING / FOLDING WHEELS
5. SET UP - UNFOLDING / FOLDING FRAME
6. SET UP - FIT BAG
7. OPERATION - HANDLE ADJUSTMENT
8. OPERATION - HAND BRAKES
9. OPERATION - BRAKE ADJUSTMENT
10. USAGE GUIDELINES - DO’s + DON’Ts
11. PRODUCT CARE - INSPECTIONS / CLEANING
12. WARRANTY
redgumbrand.com.au
INTRODUCTION
Thank you for purchasing this quality REDGUM Brand product.
If you have any issues or quesons about the All Terrain Compact Seat Walker
please contact your supplier or REDGUM Brand direct:
T: +61 8 9248 4180
F: +61 8 9248 9452
E: sales@for-de.com.au
A: 1 Business Way, Malaga Western Australia 6090
INTENDED USE
This product has limitaons and should be used in accordance to these guidelines.
Failure to follow these guidelines may result in damage to the product and injury
to the user. It is the responsibility of the user to ensure the suitability of this product
for its intended use. The user should consult their appropriate healthcare professional
if unsure of the correct product usage for their unique circumstances.
Only use the All Terrain Compact Seat Walker for its intended purpose which is as a
walking aid and a short term stac seang soluon.
The All Terrain Compact Seat Walker is designed
to be used both inside and outside the home.
Refer to usage guideline page for informaon
on how to use All Terrain Compact Seat Walker
in a safe manner.
IMPORTANT NOTE
This equipment MUST be assembled for
use and operated by a competent person.
1.
redgumbrand.com.au
PRODUCT OVERVIEW
FEATURES
Strong lightweight construcon
User friendly loop brake handles
Height adjustable handles
Ergonomic handgrips to reduce pressure
Brake + park brakes
Simple brake cable adjustment
Mesh seang
Padded Backrest
Large diameter wheels for excellent mobility
Pneumac tyres
Swivelling front wheels
Removable bag
Walking sck holder
Folds up for transit or storage
SPECIFICATIONS (All dimensions shown are nominal)
Overall: 890mm L x 610mm W x 900mm H
Overall Folded: 450mm L x 220mm W x 670mm H
Handle Height: 900 - 1025mm (5 sengs)
Seat: 460mm W x 250mm D x 600mm H
Wheel Diameter: Ø305mm / 12”
Carry Bag: 370mm L x 200mm W x 200mm D
Weight: 11kg
Maximum User Weight: 136kg
Please contact REDGUM Brand if you would like any further informaon
on the All Terrain Compact Seat Walker.
2.
redgumbrand.com.au
SET UP- UNPACK and INSPECT SUPPLIED PARTS
Ensure you have been supplied with the following parts:
We recommend that you visually inspect
the following aspects of the seat walker
prior to use:
- Framework
- Upholstery
- Wheels
- Brakes + cables
IMPORTANT NOTE:
If you see any damage
or suspect a fault,
DO NOT USE
THE PRODUCT
and contact
your supplier
for support.
3.
BAG
FOLDED
WALKER
Backrest / Seat
not shown for clarity
TYRE PUMP included
(Not shown)
redgumbrand.com.au
4.
SET UP- UNFOLDING / FOLDING WHEELS
The All Terrain Compact Seat Walker comes folded
and requires unfolding prior to use.
Please follow these steps:
1. Lay the folded seat walker on its side.
2. Remove both hand screws.
3. Rotate front and rear wheels
down as shown.
4. Fix wheels into place with
hand screws.
5. Flip seat walker over and repeat process
on other side.
HAND SCREWS
IMPORTANT NOTE
Ensure all hand screws
have been suciently ghtened
prior to using seat walker
Backrest / Seat
not shown for clarity
redgumbrand.com.au
SET UP- UNFOLDING / FOLDING FRAME
The All Terrain Compact Seat Walker
requires unfolding prior to use.
Please follow these steps:
1. Pull OUT on both of the handles at the
same me to open out the seat walker.
2. Push down rmly on the outside edges
of seat unl two loud clicks are heard.
3. Check to ensure seat walker is fully unfolded
and locked in posion prior to use.
To fold seat walker:
- Pull UP on handle in middle of seat.
5.
Important note:
DO NOT place ngers
underneath seat when
unfolding seat walker!
PUSH DOWN
ON SIDES
OF SEAT
PULL OUT
ON HANDLES
Backrest / Seat
not shown for clarity
redgumbrand.com.au
SET UP- FIT BAG
The All Terrain Compact Seat Walker comes with a bag that can be aached to the front
of the walker. Please follow these steps to t bag correctly:
1. Posion bag with bag opening facing
the front of the walker.
2. Line up straps on bag with pegs
on seat frame.
3. Slide both straps onto pegs.
4. Ensure both straps
fully locate
onto pegs.
Note:
Bag can remain on seat walker when folded if empty.
If not empty remove from walker prior to folding.
6.
2kg Max.
bag load
redgumbrand.com.au
7.
OPERATION - HANDLE ADJUSTMENT
The All Terrain Compact Seat Walker has adjustable height handles.
Please follow these steps to adjust the handle height correctly:
1. Depress the push buon located on the outside of the upright.
2. Move the handle to the required height.
(You will need to depress the push buon
for every height seng change)
3. Check to ensure press buon has fully engaged
with hole prior to use.
Press
Buon
Press buon
MUST protrude
3mm out from upright
when properly
located in place
Indice
