REH4MAT NONO MINI Manuale utente
USER MANUAL
CHILDREN BATH CHAIR
TM
NONO MINI
TM
NONO MAXI
Manufacturer takes responsibility for proper usage of the device only when
theproduct was purchased from qualified REH4MAT Sławomir Wroński
employee or at specialized medical store!
REH4MAT Sławomir Wroński reserve the right to introduce technical and trading
changes in the content of the instruction without warning.
Product marked with the CE sign is Class I medical device, of rule 1, consistent with the
requirements of Regulation (EU) 2017/745 of the European Parliament and of the
Council of 5 April 2017 on medical devices.
regarding production, sales and service. The system is certified by Det Norske Veritas.
REH4MAT Company introduced quality management system ISO 13485
-20°C
80%
40%
50°C
CONTENTS
7. The use of the product....................................................................................................................................12
4. Size table................................................................................................................................................................7
5. Detailed description of how to apply the lounger upholstery.............................................................8
2. Indications and contraindications for use..................................................................................................5
1. The purpose of user manual............................................................................................................................5
10. Labelling...........................................................................................................................................................17
9. Maintenance and cleaning...........................................................................................................................15
8. Safety rules.........................................................................................................................................................13
3.1. Standard equipment.................................................................................................................................6
3. General characteristic of NONO children bath chair..............................................................................6
6. The adjustment of the product....................................................................................................................11
It goes without saying that it is sometimes tiring to take care of children who suffer from
various disorders and, more to the point, keeping hygiene may be very troublesome.
TM
We created NONO bath chair which can help you with all these difficulties. The use of
product makes bath easier due to the fact that child is secured and he/she is not going to
sustain any injury. Moreover, parents can perform all bath activities single-handedly. Child
adapts stable as well as comfortable position thanks to which it is easier for him/her to take
abath.
The construction of product is simple which makes the product easy to use while bathing.
Iteasily fits in standard bathtub and, moreover, it adjusts to child's needs.
TM
NONO children bath chair is created for children who suffer from cerebral palsy so as to help
them to keep hygiene. There are different symptoms of cerebral palsy, everything depends on
the form of disease.
Seat is equipped with foam covers which protect the product against moving in bathtub.
Furthermore, it also protects bathtub against mechanical damages.
Seat is made of aluminium pipes and their construction is neutral for harmful water influence.
What is more, the inside of pipes is filled with special foam thanks to which water cannot get
into pipes. Seat is equipped with the adjustment of backrest's tilt angle which makes it possible
to adjust it to child's needs ( both in sitting as well as lying position). Upholstery is made of
polyamide netting which is neutral for water influence. Seat is equipped with pelvic belt that
protects child when he or she experiences uncontrollable movements.
INTRODUCTION
Remember that complying with guideline is highly important. It assures safety
and extends durability as well as aesthetics of the device.
Before using the product, user is obliged to familiarize himself / herself with user
manual.
This manual contains information necessary for correct use of NONO™ children bath chair,
preparation of the device before the use, maintenance and cleaning as well as theguarantee
conditions.
Manual should be kept in an easy accessible place. The manual is addressed to parents,
doctors and physicaltherapists who take direct care of handicap children.
Please remember that following the rules of the user manual enables safe use of the product,
its extended life and esthetics.
5
źSpina bifida;
źOther neurological diseases with movement deficits in the form of paralysis and paresis of
the limbs and / or trunk.
źIncorrect positioning of the person with the use of bathing products may lead to
deformation of the joints, and long-term keeping of the person in one position significantly
increases the risk of pressure ulcers.
Intended purpose of the product with a defined target group:
źCerebral palsy (CP);
źMuscular dystrophy;
Contraindications for use:
źMax. user's weight: size mini do 60 kg, size maxi do 75 kg.
Indications for use:
Disabled people (children / adolescents) with cerebral palsy, muscular dystrophy, spina bifida,
spinal cord injuries and neurological deficits.
1. THE PURPOSE OF USER MANUAL
TM
Before using the NONO children bath chair, user is obliged to familiarize
himself/herself withthe user manual.
2. INDICATIONS AND CONTRAINDICATIONS
FOR USE
CHILDREN BATH CHAIR
TM
3. GENERAL CHARACTERISTIC OF NONO
3.1 STANDARD EQUIPMENT
FRAME
TRUNK SUPPORT
UPHOLSTERY
6
4. SIZE TABLE
Symbol
A
B
C1
Measurement
seat width
seat depth
backrest height
max. user weight
Unit
[cm]
[cm]
[cm]
[kg]
MINI
37,5
30
45
60
MAXI
37,5
30
58
75
Weight and dimensions of the device
width
width after folding
length
length after folding
wysokość
height after folding
weight
Unit
[cm]
[cm]
[cm]
[cm]
[cm]
[cm]
[kg]
MINI
40
40
65
73
49
14
2
MAXI
40
40
65
84
59
14
2,5
Note: Dimensional tolerance in the table is +/-1 cm.
7
5. DETAILED DESCRIPTION OF HOW TO APPLY
THE LOUNGER UPHOLSTERY
8
FRAME
FOOTREST FRAME
BACKREST FRAME
JOINT
JOINT
TRUNK SUPPORT
UPHOLSTERY
9
3. Push the bottom part of the upholstery
onto the footrest frame (fig. 3).
2. Insert the upper part of upholstery on
the frame of the back support (fig. 2).
To put on the upholstery on the frame you
must:
1. Press joints at the same time and adjust
the angle between the backrest and the
footrest according to fig. 1.
fig. 1
fig. 2 fig. 3
4. Fasten all straps with velcro closures from the underside of the lounger. Please keep in mind
that the straps should cover the frame (fig. 4, 5).
fig. 4 fig. 5
10
6. Mount trunk stabilizer. Choose the appropriate height of the stabilizer , on the backrest of
the lounger and fasten the stabilizer using straps with velcro closures (fig. 6, 7).
5. Lounger with upholstery set to the usable position.
fig. 6 fig. 7
