Renault CAPTUR Manuale utente

DRIVER’S HANDBOOK

CAPTUR

Photo credit: Total/DPPI Imacom group

ELF has developed a complete range of lubricants for RENAULT:

fengine oils

fmanual and automatic gearbox oils

Benefiting from the research applied to Formula 1,

lubricants are very high-tech products.

Updated with the help of RENAULT’s technical

teams, this range is perfectly compatible with the

specific features of the brand’s vehicles.

fELF lubricants enhance

your vehicle’s performance significantly.

RENAULT recommends approved ELF lubricants for oil changes and top-ups.

Contact your RENAULT Dealer or visit www.lubrifiants.elf.com

Warning: to ensure the engine operates optimally, the use

of a lubricant may be restricted to certain vehicles. Please

refer to your maintenance document.

RENAULT recommends ELF

Une marque de

0.1

ENG_UD28953_1

Bienvenue (X87 - Renault)ENG_NU_1007-1_X87_Renault_0

Translated from French. Copying or translation, in part or in full, is forbidden unless prior written permission has been obtained from the vehicle manu-

facturer.

This Driver’s Handbook contains the information necessary:

– for you to familiarise yourself with your vehicle, to use it to its best advantage and to benefit fully from the all the functions and

the technical developments it incorporates.

– to ensure that it always gives the best performance by following the simple, but comprehensive advice concerning regular main-

tenance.

– to enable you to deal quickly with minor faults not requiring specialist attention.

It is well worth taking a few minutes to read this handbook to familiarise yourself with the information and guidelines it contains

about the vehicle and its functions and new features. If certain points are still unclear, our Network technicians will be only too

pleased to provide you with any additional information.

The following symbol will help you when reading this handbook:

Welcome to your new vehicle

The descriptions of the models given in this handbook are based on the technical specifications at the time of writing. This hand-

book covers all items of equipment (both standard and optional) available for these models but whether or not these are

fitted to the vehicle depends on the version, options selected and the country where the vehicle is sold.

This handbook may also contain information about items of equipment to be introduced later in the model year.

Throughout the manual, the “approved Dealer” is your RENAULT Dealer.

To indicate a hazard, danger or safety recommendation.

Enjoy driving your new vehicle.

0.2

ENG_UD20783_6

Filler NU (X06 - C06 - S06 - X35 - L35 - X44 - C44 - G44 - X45 - H45 - X65 - L65 - S65 - X73 - B73 - X74 - B74 - K74 - X77 - J77 - F77 - R77 - X81 - J81 - X84 - B84 - C84ENG_NU_1007-1_X87_Renault_0

0.3

ENG_UD10779_7

Sommaire Général (X06 - C06 - S06 - X35 - L35 - X44 - C44 - G44 - X45 - H45 - X65 - L65 - S65 - X73 - B73 - X74 - B74 - K74 - X77 - J77 - F77 - R77 - X81 - J81 - X84 -ENG_NU_1007-1_X87_Renault_0

Getting to know your vehicle ...............................

Driving ...................................................................

Your comfort .........................................................

Maintenance .........................................................

Practical advice ....................................................

Technical specifications ......................................

Alphabetical index ...............................................

Sections

CONTENTS

0.4

ENG_UD20783_6

Filler NU (X06 - C06 - S06 - X35 - L35 - X44 - C44 - G44 - X45 - H45 - X65 - L65 - S65 - X73 - B73 - X74 - B74 - K74 - X77 - J77 - F77 - R77 - X81 - J81 - X84 - B84 - C84ENG_NU_1007-1_X87_Renault_0

1.1

ENG_UD28957_1

Sommaire 1 (X87 - Renault)ENG_NU_1007-1_X87_Renault_1

Section 1: Getting to know your vehicle

RENAULT card: general information, use, deadlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2

Openingandclosingthedoors..................................................... 1.9

Locking,unlockingtheopeningelements............................................. 1.11

Automaticlockingwhendriving..................................................... 1.13

Headrests-Seats............................................................... 1.14

Seat belts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.16

Additionalmethodsofrestraint..................................................... 1.19

tothefrontseatbelts....................................................... 1.19

totherearseatbelts ....................................................... 1.23

side..................................................................... 1.24

Childsafety:generalinformation.................................................... 1.26

Choosingachildseatmounting............................................... 1.29

Fittingachildseat ......................................................... 1.31

Deactivating, activating the front passenger airbag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.35

Drivingposition................................................................. 1.38

Instrumentpanel................................................................ 1.42

On-boardcomputer ........................................................ 1.47

Steeringwheel/Power-assistedsteering.............................................. 1.57

Clockandexteriortemperature..................................................... 1.58

Doormirrors.................................................................... 1.60

Exterior lighting and signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.61

Audibleandvisualsignals......................................................... 1.64

Headlightadjustment............................................................. 1.65

Windscreenwashersandwipers.................................................... 1.67

Fueltank(fillingwithfuel)......................................................... 1.70

RENAULT card

use ..................................................(up to the end of the DU)

doors/tailgate........................................(up to the end of the DU)

locking the doors ..................................(up to the end of the DU)

children..................................................................(current page)

emergency key .....................................(up to the end of the DU)

children (safety).....................................................(current page)

1.2

ENG_UD29988_2

Carte Renault : généralités (X98 - X87 - Renault)ENG_NU_1007-1_X87_Renault_1

Jaune Noir Noir texte

RENAULT card: general information, use, deadlocking

The RENAULT card is used

for:

– locking/unlocking the doors and tail-

gate (doors, tailgate) and the fuel

filler flap (see the following pages);

– switch on the vehicle lighting re-

motely (refer to the following pages);

– starting the engine; refer to the in-

formation on “Starting the engine” in

Section 2.

Battery life

Make sure that the correct battery type

is being used, and that the battery is in

good condition and inserted correctly.

Its service life is approximately two

years: replace it when the message

“KEYCARD BATTERY LOW” appears

on the instrument panel (refer to the in-

formation on the “RENAULT card: bat-

tery" in section 5).

1 Unlocking the doors and tailgate.

2 Locking all doors and tailgate.

3Switch on the courtesy lighting re-

motely.

4 Unlocking/locking the tailgate

5 Integrated key.

RENAULT CARD: general information (1/2)

Driver’s responsibility

Never leave your vehicle

with the RENAULT card

inside and never leave a

child (or a pet) unsupervised, even

for a short while.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or by locking the

doors.

Risk of serious injury.

When the battery is flat, you can

still lock/unlock and start your ve-

hicle. Refer to the information on

“Locking/unlocking the doors” in

Section 1 and “Starting the engine”

in Section 2.

1 2 3

RENAULT card operating

range

This varies according to the surround-

ings: when handling the RENAULT

card, it is important to make sure that

you do not lock or unlock the doors by

inadvertently pressing the buttons.

Jaune Noir Noir texte

1.3

ENG_UD29988_2

Carte Renault : généralités (X98 - X87 - Renault)ENG_NU_1007-1_X87_Renault_1

Access to key 5

Press button 6and pull on key 5then

release the button.

Using the key

Please refer to the information on

“Locking and unlocking the opening el-

ements”.

Once you have accessed the vehicle

using the integrated key, replace it

in its housing in the RENAULT card,

then insert the RENAULT card into

the card reader to start the vehicle.

Integrated key 5

The integrated key is used to lock or

unlock the front left-hand door if the

RENAULT card does not work:

– when the RENAULT card battery is

drained, flat battery, etc.

– use of devices using the same fre-

quency as the card;

– vehicle located in a high electromag-

netic radiation zone.

RENAULT CARD: general information (2/2)

Replacement: need for an

additional RENAULT Card

If you lose your RENAULT card or

require another, you can obtain one

from an authorised dealer.

If a RENAULT card is replaced, it

will be necessary to take the vehi-

cle and all of its RENAULT cards to

an approved Dealer to initialise the

system.

You may use up to four RENAULT

cards per vehicle.

Advice

Avoid leaving the card in hot, cold or

humid areas.

Do not keep the RENAULT card in

a place where it could be bent or

damaged accidentally, such as in a

back pocket of a garment.

RENAULT card

use ..................................................(up to the end of the DU)

central door locking ..............................(up to the end of the DU)

doors/tailgate........................................(up to the end of the DU)

locking the doors ..................................(up to the end of the DU)

1.4

ENG_UD30249_2

Carte Renault : utilisation en mode télécommande (X98 - X87 - Renault)ENG_NU_1007-1_X87_Renault_1

Unlocking/locking the

luggage compartment only

Press button 4to unlock/lock the lug-

gage compartment.

RENAULT card not detected

alarm

If you open a door while the engine

is running and the card is not in the

reader, the message “Keycard not de-

tected” and a beep will warn you. The

warning disappears when the card is in-

serted in the reader again.

Distance lighting function

The interior lights come on for approxi-

mately 30 seconds when button 3is

pressed. This can be used, for exam-

ple, to identify the vehicle from a dis-

tance when parked in a car park.

Note: pressing button 3again switches

off the lighting.

Locking the doors and

luggage compartment

Press the locking button 2. The hazard

warning lights flash twice to indicate

that the doors have locked. If a door

or the luggage compartment is open

or not properly shut, or if a RENAULT

card is still in the reader, the doors and

luggage compartment lock then quickly

unlock and the hazard warning lights

do not flash.

Unlocking the doors and

tailgate

Press button 1.

The hazard warning lights flash once

to indicate that the doors have been un-

locked.

When unlocking is only active for the

driver’s door, (refer to the information

on the “vehicle settings customisation

menu” in Section 1):

– pressing button 1unlocks only the

driver’s door and the fuel filler flap;

– pressing button 1twice unlocks all

the doors and the tailgate.

REMOTE CONTROL RENAULT CARD: use

The card buttons are deactivated

when the engine is running.

The flashing status of the hazard

warning lights informs you of the ve-

hicle status:

– one flash indicates that the vehi-

cle is completely unlocked;

– two flashes indicate that the ve-

hicle is completely locked.

If the vehicle has been unlocked

but neither the doors or tailgate are

open, it locks again automatically

after two minutes.

Altri manuali per CAPTUR

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Renault Automobile

Renault

Renault KANGOO Z.E. Manuale utente

Renault

Renault LAGUNA Manuale utente

Renault

Renault GRAND SCENIC Manuale utente

Renault

Renault KANGOO 2021 Manuale utente

Renault

Renault MEGANE E-TECH 100% ELECTRIC 2022 Manuale utente

Renault

Renault Kangoo Manuale utente

Renault

Renault Clio Cup Manuale utente

Renault

Renault 2016 ESPACE Manuale utente

Renault

Renault velSatis Guida alla configurazione

Renault

Renault GRAND SCENIC Manuale utente

Renault

Renault ALASKAN 2020 Manuale utente

Renault

Renault KADJAR 2021 Manuale utente

Renault

Renault LAGUNA 2000 Manuale utente

Renault

Renault Laguna Coupe Manuale utente

Renault

Renault Duster Manuale utente

Renault

Renault Latitude Manuale utente

Renault

Renault Modus Manuale utente

Renault

Renault Clio Manuale utente

Renault

Renault MEGANE Manuale utente

Renault

Renault KANGOO Z.E. Manuale utente

Renault

Renault 2013 Clio Cup Manuale utente

Renault

Renault MEGANE Manuale utente

Renault

Renault Kangoo Manuale utente

Renault

Renault Espace Manuale utente

Manuali Automobile popolari di altre marche

Toyota

Toyota 2000 Tundra Manuale utente

CITROËN

CITROËN DS4 DSign Manuale utente

Lexus

Lexus 2015 CT 200h Manuale utente

Cadillac

Cadillac CTS 2008 Manuale utente

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuale utente

Porsche

Porsche Boxster S Manuale utente

GMC

GMC 2010 Savana 1500 Cargo Manuale utente

KIAM

KIAM SPORTAGE 2014 Manuale elenco delle parti

GMC

GMC 2013 Terrain Istruzioni per il montaggio

GMC

GMC T-Series 1999 Manuale utente

Mercury

Mercury 1998 Mystique Manuale utente

Mercury

Mercury 2007 Mariner Manuale utente

Mazda

Mazda 2007 Mazdaspeed 3 Guida

Mazda

Mazda 2014 CX-5 Manuale utente

GMC

GMC Chevrolet Express 2022 Manuale utente

GMC

GMC 1997 Jimmy Manuale utente

Chevrolet

Chevrolet 2012 Malibu Manuale utente

Cadillac

Cadillac 2010 Escalade Manuale utente
