Renault KOLEOS Manuale di istruzioni

DRIVER’S HANDBOOK

KOLEOS

Ofrecido por www.electromanuales.com

ELF is developing a complete range of

lubricants for RENAULT: engine oils, manual

and automatic transmission oils.

These are very high-technology

lubricants stimulated by applied

research in Formula One.

This range is updated with RENAULT’s

engineering teams to perfectly meet the

specific needs of RENAULT vehicles.

►ELF lubricants are a major factor in your

vehicle’s performance.

RENAULT recommends the approved ELF lubricants for your oil changes and top-ups.

Contact your RENAULT representative or visit the site: www.lubricants.elf.com

Important: to optimize engine operation the use of a lubricant

may be restricted to certain vehicles. Please refer to the

maintenance documentation.

recommends ELF

The oil born in Formula One

Ofrecido por www.electromanuales.com

0.1

ENG_UD17239_2

Bienvenue (X35 - X44 - X45 - X73 - X81 - J81 - X84 - X85 - B85 - C85 - S85 - X91 - X70 - X76 - X83 - X61 - X77 ph2 - K85 - X95 - X33 - X43 - X38 - X65 PH5 - X62 - X32ENG_NU_830-5_H45_Renault_0

Translated from French. Copying or translation, in part or in full, is forbidden unless prior written permission has been obtained from RENAULT,

92100 Billancourt 2010.

This Driver’s Handbook contains the information necessary:

– for you to familiarise yourself with your vehicle, to use it to its best advantage and to benefit fully from the all the functions and

the technical developments it incorporates.

– to ensure that it always gives the best performance by following the simple, but comprehensive advice concerning regular main-

tenance.

– to enable you to deal quickly with minor faults not requiring specialist attention.

It is well worth taking a few minutes to read this handbook to familiarise yourself with the information and guidelines it contains

about the vehicle and its functions and new features. If certain points are still unclear, our Network technicians will be only too

pleased to provide you with any additional information.

The following symbol will help you when reading this handbook:

Welcome to your new vehicle

The descriptions of the models given in this handbook are based on the technical specifications at the time of writing. This hand-

book covers all items of equipment (both standard and optional) available for these models but whether or not these are

fitted to the vehicle depends on the version, options selected and the country where the vehicle is sold.

This handbook may also contain information about items of equipment to be introduced later in the model year.

Throughout the manual, the “approved Dealer” is your RENAULT Dealer.

To indicate a hazard, danger or safety recommendation.

Enjoy driving your new vehicle.

Ofrecido por www.electromanuales.com

0.2

ENG_UD9525_5

Filler NU (X06 - C06 - S06 - X35 - L35 - X44 - C44 - G44 - X45 - H45 - X65 - L65 - S65 - X73 - B73 - X74 - B74 - K74 - X77 - J77 - F77 - R77 - X81 - J81 - X84 - B84 - C84ENG_NU_830-5_H45_Renault_0

Ofrecido por www.electromanuales.com

0.3

ENG_UD7342_6

Sommaire Général (X06 - C06 - S06 - X35 - L35 - X44 - C44 - G44 - X45 - H45 - X65 - L65 - S65 - X73 - B73 - X74 - B74 - K74 - X77 - J77 - F77 - R77 - X81 - J81 - X84ENG_NU_830-5_H45_Renault_0

Getting to know your vehicle ...............................

Driving ...................................................................

Your comfort .........................................................

Maintenance .........................................................

Practical advice ....................................................

Technical specifications ......................................

Alphabetical index ...............................................

Sections

CONTENTS

Ofrecido por www.electromanuales.com

0.4

ENG_UD9525_5

Filler NU (X06 - C06 - S06 - X35 - L35 - X44 - C44 - G44 - X45 - H45 - X65 - L65 - S65 - X73 - B73 - X74 - B74 - K74 - X77 - J77 - F77 - R77 - X81 - J81 - X84 - B84 - C84ENG_NU_830-5_H45_Renault_0

Ofrecido por www.electromanuales.com

1.1

ENG_UD18346_11

Sommaire 1 (X45 - H45 - Renault)ENG_NU_830-5_H45_Renault_1

Section 1: Getting to know your vehicle

RENAULT cards: general information, use, deadlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2

Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.9

Automatic locking when driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.13

Headrests/seats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.14

Seat belts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.18

in addition to the rear seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20

Additional methods of restraint:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.22

to the front seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.22

to the rear seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26

side protection devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.27

Child safety: general information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.29

choosing a child seat mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.32

fitting the child seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.34

deactivating/activating the front passenger air bags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.37

Driving position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.40

Warning lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.44

Instrument panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.48

trip computer and warning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.50

Time and external temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.60

Steering wheel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.61

Power-assisted steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.61

Door mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.62

Audible and visual signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.63

Exterior lighting and signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.64

Electric beam height adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.67

Windscreen wash/wipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.68

Rear screen wash/wipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.70

Fuel tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.71

Ofrecido por www.electromanuales.com

locking the doors ..................................(up to the end of the DU)

emergency key .....................................(up to the end of the DU)

child safety............................................(up to the end of the DU)

children (safety)....................................(up to the end of the DU)

RENAULT card

use ..................................................(up to the end of the DU)

1.2

ENG_UD6635_1

Carte RENAULT : généralités (X45 - H45 - Renault)ENG_NU_830-5_H45_Renault_1

Jaune Noir Noir texte

Cartes RENAULT : généralités, utilisation, supercondamnation

RENAULT CARDS: general information (1/2)

1Unlocking the doors and the tail-

gate;

2Locking the doors and the tailgate;

3Switching on the lighting remotely;

4Unlocking/locking the tailgate;

5Integrated key.

The RENAULT card is used

for:

– locking and unlocking the doors

and tailgate (refer to the following

pages);

– depending on the vehicle, automati-

cally closing the electric windows

and sunroof remotely (see the in-

formation on “Electric windows” and

“Electric sunroof” in Section 3);

– switching on the vehicle lighting re-

motely (refer to the following pages);

– starting the engine; refer to the in-

formation on “Starting the engine” in

Section 2.

Battery life

Make sure that the correct battery type

is being used, and that the battery is in

good condition and inserted correctly.

Its service life is approximately two

years: replace it when the message

“Low card battery” appears on the in-

strument panel (refer to the informa-

tion on the “RENAULT card: Battery” in

Section 5).

Note: you can still lock/unlock and start

your vehicle, even with a flat battery.

Refer to the information on “Locking/

unlocking the doors” in Section 1 and

“Starting the engine” in Section 2.

Range of the RENAULT card

This varies according to the environ-

ment. It is important to make sure when

handling the RENAULT card that you

do not lock or unlock the doors by inad-

vertently pressing the buttons.

Driver’s responsibility

Never leave your vehicle

with the Renault card inside

and never leave a child

(or a pet) unsupervised, even for a

short while.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or by locking the

doors.

Risk of serious injury.

Ofrecido por www.electromanuales.com

Jaune Noir Noir texte

1.3

ENG_UD6635_1

Carte RENAULT : généralités (X45 - H45 - Renault)ENG_NU_830-5_H45_Renault_1

RENAULT CARDS: general information (2/2)

Replacement: need for an

additional RENAULT Card

If you lose your RENAULT card or

require another, you can obtain one

from an approved dealer.

If a RENAULT card is replaced, it

will be necessary to take the vehi-

cle and all of its RENAULT cards

to an approved dealer to initialise

the system.

You can use up to four RENAULT

cards per vehicle.

Advice

Avoid leaving the card in hot, cold or

humid areas.

Do not keep the RENAULT card in a

place where it could be bent or dam-

aged accidentally, such as in a back

pocket of a garment.

Access to key 5

Press button 6and pull on key 5then

release the button.

Using the key

Refer to the information on “Locking/

unlocking the doors”.

Once you have accessed the vehicle

using the integrated key, replace it

in its housing in the RENAULT card,

then insert the RENAULT card into

the card reader to start the vehicle.

Integrated key 5

The integrated key is used to lock or

unlock the front left-hand door if the

RENAULT card does not work:

– when the RENAULT card battery is

drained, discharged battery, etc.

– use of devices using the same fre-

quency as the card;

– if the vehicle is located in a zone of

high electromagnetic radiation.

Ofrecido por www.electromanuales.com

locking the doors ..................................(up to the end of the DU)

RENAULT card

use ...................................................................(current page)

1.4

ENG_UD6636_1

Cartes RENAULT à télécommande : utilisation (X45 - H45 - Renault)ENG_NU_830-5_H45_Renault_1

REMOTE CONTROL RENAULT CARD: use

Locking the doors

Press the locking button 2.

The hazard warning lights flash twice

to indicate that the doors have locked:

if a door or the tailgate is open or not

properly shut, or if a RENAULT card is

still in the reader, the doors and tailgate

quickly lock then unlock and the hazard

warning lights and indicator lights do

not flash.

Unlocking/locking the tailgate

only

Press button 4to unlock or lock the tail-

gate.

Unlocking the doors

Press unlocking button 1.

The hazard warning lights flash once

to indicate that the doors have been un-

locked.

The card buttons are deactivated

when the engine is running.

Distance lighting function

This can, for example, identify the ve-

hicle from a distance when parked in a

car park.

The dipped beam headlights, indicator

lights and interior lights come on for ap-

proximately 30 seconds when button 3

is pressed.

Note: pressing button 3again switches

off the lighting.

RENAULT card non-detection

alarm

The message “card not detected” and

a beep will warn you if you open a door

with the engine running and the card is

not in the reader. The warning disap-

pears when the card is inserted in the

reader again.

The flashing status of the hazard

warning lights informs you of the ve-

hicle status:

– one flash indicates that the vehi-

cle is unlocked;

– two flashes indicates that the

vehicle is locked.

Ofrecido por www.electromanuales.com

Altri manuali per KOLEOS

Indice

Altri manuali Renault Automobile

Renault

Renault 2013 Clio Cup Manuale utente

Renault

Renault MEGANE COUPE CABRIOLET Manuale utente

Renault

Renault Duster Manuale utente

Renault

Renault Twingo Clio Istruzioni operative

Renault

Renault Master Van 2004 Manuale utente

Renault

Renault Talisman Manuale utente

Renault

Renault TWINGO Manuale utente

Renault

Renault LAGUNA Manuale utente

Renault

Renault GRAND SCENIC Manuale utente

Renault

Renault zoe Manuale utente

Renault

Renault KANGOO Z.E. Manuale utente

Renault

Renault 2016 CLIO Manuale utente

Renault

Renault MEGANE COUPE CABRIOLET Manuale utente

Renault

Renault MEGANE Manuale utente

Renault

Renault KANGOO BE BOP Manuale utente

Renault

Renault Latitude Manuale utente

Renault

Renault Clio 2007 Manuale utente

Renault

Renault velSatis Manuale utente

Renault

Renault velSatis Guida alla configurazione

Renault

Renault Trafic Manuale utente

Renault

Renault 2005 Megane Manuale utente

Renault

Renault Megane Berline Manuale utente

Renault

Renault ZOE 2018 Manuale tecnico

Renault

Renault 2000 Megane Manuale utente

Manuali Automobile popolari di altre marche

Toyota

Toyota 2000 Tundra Manuale utente

CITROËN

CITROËN DS4 DSign Manuale utente

Lexus

Lexus 2015 CT 200h Manuale utente

Cadillac

Cadillac CTS 2008 Manuale utente

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuale utente

Porsche

Porsche Boxster S Manuale utente

GMC

GMC 2010 Savana 1500 Cargo Manuale utente

KIAM

KIAM SPORTAGE 2014 Manuale elenco delle parti

GMC

GMC 2013 Terrain Istruzioni per il montaggio

GMC

GMC T-Series 1999 Manuale utente

Mercury

Mercury 1998 Mystique Manuale utente

Mercury

Mercury 2007 Mariner Manuale utente

Mazda

Mazda 2007 Mazdaspeed 3 Guida

Mazda

Mazda 2014 CX-5 Manuale utente

GMC

GMC Chevrolet Express 2022 Manuale utente

GMC

GMC 1997 Jimmy Manuale utente

Chevrolet

Chevrolet 2012 Malibu Manuale utente

Cadillac

Cadillac 2010 Escalade Manuale utente
