Renault MEDIA-NAV EVOLUTION Manuale utente

MEDIA-NAV Evolution

Quick guide

WELCOME TO THE WORLD OF MEDIA NAV Evolution.

Congratulations on your choice.

In order to ensure you make the most of your integrated touch screen device, we recommend that you read this document to find out about the main functions and

settings for your multimedia system.

Translated from French. Copying or translation, in part or in full, is forbidden unless prior written permission has been obtained from the vehicle manufacturer.

This document does not replace the driver’s handbook.

Please read the driver’s handbook for more detailed information on the features mentioned in the “References” guide for your multimedia system.

The “References” guide covers all the functions (standard and optional) available; their presence in the Média Nav Evolution navigation system depends on the

version, the options selected and the marketing country. Depending on the make and model of your telephone, some functions may be partially or completely

incompatible with your vehicle’s multimedia system.

For more details, please consult an Authorised Dealer.

First use

Entering a destination

Guidance

Listening to the radio

Multimedia

Bluetooth® device connection

Making and receiving a call

Eco² driving

System settings

Updating the system

Switching on

The multimedia system switches on automatically

when the ignition is switched on. In other cases,

press the 1button on your system.

With the ignition off, the system will operate

for 20 minutes. Press 1again to switch on your

system after 20 minutes.

Switching off

The system switches off automatically when the

vehicle’s ignition is switched off.

TOUCH SCREEN A

The multimedia system is fitted with a touch-

screen device A. Touch with a finger to select a

menu or a display button.

Auxiliary function

You have a USB connection 3and an analogue aux-

iliary input 4on the control panel for connecting an

external audio device.

Standby screen

With the ignition on, press the 1or 5button on

your system to put the system on standby. The

clock and the exterior temperature are displayed

on the screen.

Note: in this mode, the radio or the guidance

system do not operate.

Volume

To modify the volume of the sources and the voice

navigation instructions (during an instruction),

turn 5or press one of the buttons 2.

Voice recognition

The button 6on the steering wheel allows you

to use the voice recognition on your multimedia

system and/or your phone if it is connected to the

system.

For more information, see the multimedia system

user manual.

FIRST USE (1/3)

13 4 5

7 8

Radio Media Phone

Driving eco² Nav Setting

Dark

FIRST USE (2/3)

910

Set Time

13 14

Player List Presets Options

13 Mode selection area:

– displays the selected mode;

– when the mode selection area is touched, a

drop-down menu will appear.

14 Table of contents area:

– shows the contents of a menu item and

related information.

15 Menu area:

– display subordinate menu of mode;

– shows current menu as highlighted.

16 Home or return to navigation area.

Menu screen

7Mode standby and clock display

8Telephone information area.

9Exterior temperature.

10 Time area.

11 Area for selecting programmed engine start-up

12 Menus area.

Navigation screen

17 Map mode (2D /3D and 2D North).

18 Name of the next street to take on your route.

19 Access the current media (USB, AUX, AM, FM,

DAB, iPod®, and Bluetooth®)

20 Options for route and map setting.

21 Voice guidance On/Off.

22 Traffic information (TMC).

Destination

192022 21

Steering column controls

23 Choose audio source (FM / AM / DAB / USB /

iPod® / Bluetooth® / AUX).

24 Tap: access the “Phone” menu.

Press and hold: activate/deactivate multimedia

system voice recognition.

When receiving a call:

– short press: answer the call;

– long press: reject the call.

Brief press during a call: end call.

25, 26 Adjust the volume.

25+26 Mute/unmute the sound;

FIRST USE (3/3)

27 Change the playback mode of the radio stations

or the media (USB / iPod®) currently in use.

28 Rear dial:

– radio: change radio mode (preset/list/fre-

quency);

– media: previous/next track.

29 Change media (CD / USB / AUX).

30 Tap: change radio mode (FM /AM /DAB).

Press and hold: activate/deactivate multimedia

system voice recognition.

23 24

29 30

31, 33 Adjust the volume.

32 Listening to an audio source: mute/unmute.

When receiving a call:

– short press: answer the call;

– long press: reject the call.

Brief press during a call: end call.

34 Rear dial:

– radio: change radio mode (preset/list/fre-

quency);

– media: previous/next track.

Short press: confirm an action.

– select a destination on the map from “Find on

map”;

– select a latitude and longitude from “Coordinate”.

ENTERING A NEW “ADDRESS”

This item allows you to enter all or part of the ad-

dress: country, city, street and house number.

Note: only addresses known on the digital map are

authorised.

When using this for the first time, you must select

your country. Then enter the name of the town or

city wanted using the keypad;

The system may suggest several town names in

the area 1.

If these choices are not correct, access the full

list corresponding to your search by pressing

the 2button.

The system displays a list.

ENTERING A DESTINATION (1/3)

Menu “Destination”

Press the home button to access the “Nav” menu,

then on the “Destination” tab at the bottom of the

screen.

To enter a destination:

– enter an address from “Address”;

– select an address from “Points of interest”;

– select a recent destination from the locations in

“History”;

– select a previously saved address from

“Favourites”;

Refer to the instructions for further information.

– select the town or city;

– follow the same procedure for the “Street”,

“Intersecting street” and “Street number”

screens, if necessary.

When entering the address, the system will high-

light certain letters to help with entering the in-

formation.

Note: “Intersecting street” and “Street Number”

can be activated after selecting “Street”.

Note: The system stores previous addresses in its

memory. Once you have entered a destination by

address, that address will be displayed when the

device is next used.

Address Points of interest History

Favourites Find on map Coordinate

Destination Itinerary Options Options

Navigation

ENTERING A DESTINATION (2/3)

“POINTS OF INTEREST”

A place of interest is a service, an establishment

or a tourist destination. The locations are classified

into different categories – restaurants, museums,

car parks, etc.

You can search for a point of interest by:

– category:

– name of the point of interest;

– finding a point of interest on the map.

“FAVOURITES”

The favourites can be destinations such as your

place of work, home, school, etc. You can include

a new destination on your favourites list when set-

ting a route to this destination for the first time

(see the “Confirm destination” section).

– select the Home button, “Nav”, then the

“Destination” tab;

– choose “Favourites”;

– select the required destination in the list of

stored addresses.

Address Points of interest History

Favourites Find on map Coordinate

Destination Itinerary Options

Navigation

“HISTORY”

This item enables you to select a destination from

the list of addresses last used. This information is

stored automatically once guidance starts.

From the main menu select “Nav”, the “Destination”

tab, then choose the “History” menu.

From the list of stored destinations, select an ad-

dress then confirm this address as the destination.

ENTERING A DESTINATION (3/3)

“FIND ON MAP”

This function allows you to define a destination

from the map.

From the navigation screen, move around on the

map to position the cursor on your destination,

then press “OK” to confirm: the system calculates

the route.

“COORDINATE”

This function allows you to define a destination

using latitude and longitude values.

– “Options”, then “Back to car” enables you to pin-

point your vehicle’s current location;

– “OK” activates guidance.

Confirming the

destination

When the calculation is complete, the system

offers you several options:

– “Options”, then “Add to favourites” enables you

to add destination addresses to your favourites;

– “Options” then “Current traffic” obtains informa-

tion on traffic incidents flagged on your route, or

in your immediate vicinity;

– “Options”, then “News” allows you to consult the

address, latitude, longitude and phone number

(phone number is only activated after selecting

a point of interest known to the system);

Options OK Options OK

Add to favourites

Current traffic

News

Coordinate

Options OK

If the coordinates or map location entered do not

match an accessible location (street or path), the

system will create an error message.

Back to car

GUIDANCE

Cancel the route

To stop guidance when in progress, in the main

menu, select “Nav”, “Itinerary” in the tab at the

bottom of the screen, “Cancel Route” then con-

firm.

Configuring a route

“Route settings”, accessible from the “Options”

menu, allows you to select the type of route to take

during navigation.

Route information

This function allows you to view your route before

guidance begins. Select the home button, “Nav”,

then “Itinerary” after entering a destination.

There are six types of settings:

– “Edit route”;

– “Avoidances”;

– “Overview”;

– “Cancel Route”;

– “Alternative routes”;

– “Itinerary”.

Alternative routes

This section, which is accessed through the

“Options” menu after activating your route, enables

the driver to modify the route planning method.

There are three options available:

– “Fast”;

– “Economical”;

– “Short”.

Note: The choice of route configuration, accord-

ing to the selected road type, can greatly affect the

proposed route.

Destination Itinerary Options

Navigation

Destination Itinerary Options

Navigation

Warnings Route settings Map settings

Language Setting Coordinate format GPS

Edit route Avoidances Overview

Cancel Route Alternative routes Itinerary

Alternative routes

Fast

Economical

Short

Altri manuali per MEDIA-NAV EVOLUTION

Indice

Altri manuali Renault Sistema video per auto

Renault

Renault R&Go Manuale utente

Renault

Renault EASY CONNECT Manuale utente

Renault

Renault EASY CONNECT EASY LINK Manuale di riferimento

Renault

Renault MEDIA-NAV EVOLUTION Manuale utente

Renault

Renault R-Link 2 Manuale utente

Renault

Renault EASY LINK Manuale utente

Renault

Renault R-LINK2 Manuale utente

Renault

Renault Radio Connect R & GO Manuale utente

Renault

Renault R-Link 2 Manuale utente

Renault

Renault Clio 4 Manuale utente

Renault

Renault Radio Connect R & GO Manuale utente

Renault

Renault R-Link Manuale utente

Renault

Renault R-Link 2 Manuale utente

Renault

Renault R&Go Manuale utente

Renault

Renault Radio Connect R & GO Manuale utente

Renault

Renault MEDIA-NAV EVOLUTION Manuale utente

Renault

Renault EASY CONNECT Manuale utente

Renault

Renault EASY CONNECT EASY LINK Manuale utente

Manuali Sistema video per auto popolari di altre marche

Stinger

Stinger HEIGH10 RB10RAM13B Manuale utente

Eonon

Eonon E1057 Manuale utente

Milion

Milion D2223 Manuale utente

Metra Electronics

Metra Electronics 99-8153 Manuale utente

Voxx Electronics

Voxx Electronics HR8MA1 Manuale utente

Axxera

Axxera AV604Bi Manuale utente

Clarion

Clarion NX706E Manuale utente

Pyle view

Pyle view PLDN74BTi Manuale utente

Clarion

Clarion NX602 Manuale utente

PowerAcoustik

PowerAcoustik PTID-5850N Manuale utente

RCA

RCA DRC6296 - Twin 9" Mobile DVD System Guida utente

Lanzar

Lanzar SVDVD5 Manuale utente

Kia

Kia MTXM100YPPE Manuale utente

Eonon

Eonon E1060 Manuale utente

Macrom

Macrom M-AN900 Manuale utente

Hyundai

Hyundai BAPE-L3000N Manuale utente

r.LiNK

r.LiNK RL2-UCON8-SM Manuale utente

Blaupunkt

Blaupunkt DVP 01C Manuale utente
