Reolink Reolink Go Plus Manuale utente
Go Plus
Reolink Go Plus, a 100% wire-free mobile HD security camera, operates on 4G-LTE
and 3G networks. An ideal video monitoring solution with no cords, no wiring
hassles, when in areas with limited or no WiFi access, no electrical power source!
1. Specs
1
6 IR LEDs
2
Built-in Mic
3
Status LED
4
Lens
5
Daylight Sensor
6
Built-in PIR Motion Sensor
7
Speaker
8
Micro USB Port
Status Light
Note:
If the camera connects the network successfully,there will be no status LED light up
during idle mode.
Status Light
Camera Status
Red LED solid light up then starts to
flash
Camera cannot recognize the SIM
card or there is PIN code of the SIM
card.
Red LED solid light up then flash
slowly about once every second
Camera cannot register the mobile
carrier network.
Red LED solid light up then flash
quickly about 3 times in 1s
Data call failed or requires to input
the APN.
1
Micro SD Card Slot
2
SIM Card Slot
3
Reset Hole
4
Battery Status LED
Red LED solid light up then blue LED
starts to flash and goes off completely
Network connection failed.
Red LED solid light up then blue LED
starts to flash and solid light up
Network connection succeed.
2. Setup and Install
Set up the Camera
What’s in the Box
Note: The package content may vary and update with different version and
platforms, please take the below information only for a reference. And the actual
package content are subject to the latest information on the product selling page.
Go Plus
Activate the SIM Card for the Camera
The SIM card shall support WCDMA and FDD LTE.
Activate the card on your smartphone or with your network carrier before inserting
it into the camera.
Notes:
Camouflage Skin *1
Surveillance Sticker*1
Pack of Screws*1
Reset Needle*1
Mounting Template *1
Go Plus*1
Quick Start Guide*1
USB Cable*1
Mount*1
Some SIM cards have a PIN code, please use your smartphone to disable the
PIN first.
Do not insert the IoT or M2M SIM card into your smartphone.
Install the SIM Card
1. Remove the back cover by rotating counterclockwise and insert the SIM card
into the slot.
2. Insert the battery into the camera and tighten the back cover to power on the
camera.
3. A red LED will be on and solid for a couple of seconds, then it will go out.
4. “Network connection succeeded”. A blue LED will flash for a few seconds and
then go solid before going out, which means the camera has been successfully
connected to the network.
Note:
You may also run into the following situations:
No.
Voice Prompts
Camera Status
Solutions
1
“SIM card cannot be
recognized”
Camera cannot
recognize this SIM
card.
1. Check if the SIM card is
facing the reverse
direction.
2. Check if the SIM card is
not fully inserted and
insert it again.
2
“The SIM card is locked
with a PIN. Please
disable it”
Camera cannot
recognize this SIM
card.
Put the SIM card into your
mobile phone and disable
the PIN.
3
“Not registered on
network. Please activate
your SIM card and check
the signal strength”
Camera fails to
register to the
operator network.
1. Check whether your
card is activated or not.
If not, please call your
operator to activate the
SIM card.
2. The signal is weak at
the current position.
Please move the camera
to a location with better
signal.
3. Check if you are using
the correct version of the
camera.
4
“Network connection
failed”
Camera fails to
connect to the
server.
The camera will be in
standby mode and
reconnect later.
5
“Data call failed. Please
confirm your cellular
data plan is available or
import the APN
settings”
The SIM card has run
out of data or APN
settings are not
correct.
1. Please check whether
the data plan for the SIM
card is still available.
2. Import the correct APN
settings to the camera.
Set up the Camera on the App
Please follow the steps below to do initial setup for the battery-powered cameras
via Reolink App.
Step 1. Tap the icon in the top right corner to add the camera.
Step 2. Scan the QR code on the back of the camera. If the phone doesn't respond,
please tap Input UID/IP below the scan window, and then enter the 16-digit UID
number under the QR code of the camera.
Step 3. Create the login password and name your camera. Then tap Next.
Step 4. Select a scene according to the place where your camera will be installed.
Then tap Next.
Step 5. Read the note and then tap Finish to complete the initialization of your
camera.
Now the initialization is finished and you can move it to the position you want. Here
is an article to choose a good position for the camera.
Install the Camera
We offer you guides on different scenes in which the camera could be installed.
Check out them respectively.
Mount the Camera to the Wall
1. Drill holes in accordance with the mounting hole template and screw the
security mount to the wall. If you are mounting the camera on any hard surface,
insert plastic anchors into the holes first.
2. Install the camera on the security mount.
3. To get the best field of view, loosen the adjustment knob on security mount and
turn the camera.
4. Stiffen the adjustment knob to lock the camera.
