Resolution RE105 Manuale utente

RE105_GE_Temp_Instructions Page 1 of 3 7-Mar-16

24-Hour Tech Support Line: (715)808-0164

www.ResolutionProducts.com

RE105 Temp Range, GE-Compatible

Features

• Freeze and Overheat warnings.

o Can be used as just Freeze, just Overheat or both simultaneously.

o Unique D’s for each function.

• Cover tamper.

• Strong, reliable RF signal.

• 8-10 year battery life on CR123A battery.

• Low Battery indication.

• 3.3x1.4x1.1 inches.

Key Instructions

• Battery “+” faces towards spring.

• Enrolling:

 Freeze (1

D): enrolled by tamper switch.

• This D is on a label on the battery bucket.

 Overheat (2

D): enrolled by holding down tamper while

installing battery.

• This D is not on a label.

Operation

• Freeze (1st D)

Alarm: when room temperature drops below 45F.

Tamper: when cover is opened.

Supervisory: every hour.

• Overheat (2

Alarm: when room temperature rises above 100F.

Tamper: when cover is opened.

Supervisory: every hour.

RE105_GE_Temp_Instructions Page 2 of 3 7-Mar-16

24-Hour Tech Support Line: (715)808-0164

www.ResolutionProducts.com

Specifications

Freeze Alarm Temp: 45F +/- 2F

Freeze Restore: when temp increases 4F from alarm

Overheat Alarm Temp: 100F +/- 2F

Overheat Restore: when temp decreases 4F from alarm

Mounting hardware: # 4 or #6 screws

Replacement Battery: CR123A 1550 mAH

Temperature Range: 0F to 120F

Housing dimensions: 3.3x1.4x1.1 inches

Specifications subject to change without notice.

Internal Picture

Temp Element

RE105_GE_Temp_Instructions Page 3 of 3 7-Mar-16

24-Hour Tech Support Line: (715)808-0164

www.ResolutionProducts.com

Notices

“GE”, “Honeywell”, and “DSC” are trademarks owned by General Electric Company,

Honeywell International Inc , and Tyco Safety Products Canada LTD, respectively

Resolution Products, Inc products will function with one of either GE, DSC or Honeywell

systems However, no Resolution product is produced by, endorsed by, nor is officially

associated with GE, Honeywell or DSC Resolution recommends verifying operation at

installation

Warranty

Resolution Products, Inc will replace products that are defective in their first five (5) years

FCC Notice

This device complies with Part 15 of the FCC rules Operation is subject to the

following two conditions:

This device may not cause harmful interference

This device must accept any interference that may be received, including

interference that may cause undesired operation

Changes or modifications not expressly approved by the Resolution Products, Inc could

void the user's authority to operate this equipment

FCC ID: U5X-RE105

IC Notice

This device complies with Industry Canada license-exempt RSS standard(s) Operation is

subject to the following two conditions:

(1)This device may not cause interference, and

(2)This device must accept any interference, including interference that may

cause undesired operation of the device

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils

radio exempts de licence L'exploitation est autorisée aux deux conditions suivantes :

(1)l'appareil ne doit pas produire de brouillage, et

(2)l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d'en compromettre le fonctionnement

IC: 8310A-RE105
