RET1032
Retina Weatherproof Color Camera
with SONY High Resolution CCD Sensor & On-Screen Adjustability
USER MANUAL
SPECIFICATIONS
Model RET1032
Pick Up Element 1/3” SONY Super HAD CCD
Effective Picture Elements (H X V)
NTSC: 811(H) X 508(V) PAL: 795(H) X 596(V)
Horizontial Resolution 600 TV Lines
Minimum Illumination 0.001 Lux, 0 Lux ( with IR LED ON)
S/N Ratio More than 48db
Scanning System 2.1 Interface
Synchronous System Internal, Negative sync.
Auto Electronic Shutter
NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic 0.45
IR Distance 20 Meters (with ¢ 5 x 24PCS infrared LED)
Video Output 1Vpp, 75Ω
Auto Gain Control Auto
Power/Current DC12v 400mA
Lens 3.6-mm Board lens
Dimension (mm) 175(W) x 124 (H) x 83 (D) mm
Weight (g) 400
Storage Temperature -30~+60°C RH 95% MAX
Operating Temperature -10~+45°C RH 95% MAX
ON-SCREEN SETTINGS
TROUBLESHOOTING
1. No picture after providing power.
Possible power supply voltage abnormality. Check for proper power supply voltage and
polarity. Ensure that all the connecting cables and monitors are hooked up properly.
2. Interference (hum bars) are moving through the picture.
Check the monitor and peripheral equipment used.
3. The picture background changes color continuously.
The fluorescent light’s electromagnetic field can cause color roll. This is a normal
phenomenon. Reduce the number of fluorescent lights, or increase the distance
between the camera and the fluorescent lights.
4. The picture quality is poor or “fuzzy”
This is usually due to poor quality cables or poor connections. Ensure that all the
connecting cables and monitors are hooked up properly, or switch to higher quality
connecting cables.
LIMITED WARRANTY
This warranty remains in effect for one year from the date of purchase. Except as specified be-
low, this warranty covers all defects in material and workmanship. The following are not covered:
Damaged caused by accident, misuse, abuse, product modification or neglect, damage occurring
during shipment, damage from failure to follow instructions contained in the owner’s instruction
booklet, damage resulting from the performance of repairs by someone not authorized by Retina
Security Equipment, or any claims based on misrepresentations by the seller. This warranty does
not cover incidental or consequential damages. It does not cover the cost of removing or reinstall-
ing the unit. This warranty is void if the serial number has been removed or defaced.
This warranty gives you specific legal rights. You may also have other rights which vary from
state to state. Some states do not allow the exclusion or limitations of incidental or consequential
damages or limitation on how long an implied warranty lasts so the above may not apply to you.
HOW TO OBTAIN SERVICE
Please call us at (800) 844-9555 Monday – Friday 8am – 5pm. Central Standard Time.
We may direct you to an authorized dealer/technician or request that you return the prod-
uct for repair. You must present the original bill of sale to establish the date of purchase.
Please do not ship your product to us for repair without prior authorization. You are
responsible for transportation of your product and payment of any shipping charges. If
the repairs are covered under warranty, we will pay the return shipping charges.
NOTE: Do not attempt to disassemble the camera. Doing so may void your warranty.
No user-serviceable parts inside.
MANUAL/DC/VIDEOLENS
AUTO,1/50,1/250,1/500,1/2000,1/5000,1/10000,1/100000,x2,x4,x8,x16,x32,x64,x128,x256
0-100
ON/OFF
ON/OFF
FREEZE/ON/OFF
MIRROR
D-ZOOM
GAMMA
RETURN
CAM ID
ID DISPLAY
BAUD RATE
ON/OFF
OFF
LEFT/RIGHT
WIDTH
TOP/BOTTOM
HEIGHT
COLOR
INT
CHINESE/ENGLISH/JAPANESE
0-31
0-100
0-100
FACTORY RESET/RETURN
AREA SELECT
AREA DISPLAY
NEG.IMAGE
ATW/AWB/AWC/MANUAL/INDOOR/OUTDOOR
AUTO/COLOR/BW
LOW/MIDDLE/HIGH/OFF
2x TO 128x
OFF/BLC/HSBLC
OFF/INDOOR/OUTDOOR
EXPOSURE
SHUTTER
BRIGHTNESS
AGC
SENSE UP
BLC
D-WDR
RETURN
CAM TITLE
D-EFFECT
RS485
MOTION
PRIVACY
SYNC
LANGUAGE
RETURN
SHARPNESS
BLUE
RED
RETURN
WHITE BAL
DAY/NIGHT
3DNR
SPECIAL
ADJUST
RESET
EXIT
