REVELL KIT 1180 Manuale utente

If you have any questions or comments, call our hotline at: (800) 833-3570

or, please write to:

Revell Inc Consumer Service Department, 1850 Howard Street Unit A, Elk Grove Village, Illinois 60007

Be sure to include the plan number (85118010200), part number, description, your return address and phone number.

Visit our website: www.revell.com

F-14 TOMCAT

KIT 1180 85118010200

The Grumman F-14 is an air

superiorty fighter without equal. It

has been proven to be one of the

most maneuverable combat fighters

ever developed. The "Tomcat" utilizes

movable, variable geometry wings

to provide maximum performance

over a broad spectrum of flight

characteristics. The F-14 is equipped

with an array of sophisticated systems

that transforms it into a lethal combat

aircraft.

The F-14 is a two seat aircraft

capable of speeds in excess of Mach

two. The aircraft is powered by two

Pratt and Whitney TF-30 Turbofan

engines that develop nearly 21,000

pounds of thrust each. The "Tomcat"

is 62 feet long and has a wingspan of

61 feet , 10 inches.

* REPEAT SEVERAL TIMES

* A REPETER PLUSIEURS FOIS

* REMOVE AND THROW AWAY

* A RETIRER ET JETER

* TRIM

*D´ECOUPER

* OPTIONAL PARTS

* PIECES EN OPTION

* APPLY STICKERS

*APPLIQUEZ LES AUTO-COLLANTS

READ BEFORE YOU BEGIN

• CLEAR A SPACE TO WORK ON.

• STUDY THE ASSEMBLY DRAWINGS

BEFORE YOU BEGIN.

• EACH PLASTIC PART IS IDENTIFIED BY

A PART NUMBER.

• THIS KIT MAY BE SNAPPED TOGETHER BUT PARTS

MAY BE CEMENTED IF YOU PREFER.

• TRIM TO REMOVE EXTRA PLASTIC AND FILE

SMOOTH BEFORE PART ASSEMBLY.

CAUTION:

POSITION ALL PARTS IN THIS KIT CAREFULLY.

PARTS WILL ONLY SNAP TOGETHER ONCE.

• DÉGAGGEZ UN ESPACE POUR TRAVAILLER.

• ÉTUDIEZ LES ÉTAPES DE MONTAGE AVANT DE

COMMENCER.

• CHAQUE PIÉCE EN PLASTIQUE PORTE UN NUMÉRO DE

PIÉCE.

• CETTE MAQUETTE L´ASSEMBLAGE PAR SIMPLE

PRESSION, MAIS VOUS POUVEZ COLLER LES PIECES

SI VOUS LE PREFEREZ.

•

D´ECOUPER POUR ENLEVER LE PLASTIQU SUPERFLU

ET BIEN LIMER DES PI'ECES AVANT L´ASSEMBLAG

MISE EN GARDE:

POSITIONNEZ AVEC PRÉCAUTION TOUTES LES

PIÉCES DE CE MODÉLE RÉDUIT, CAR VOUS NE

POUVEZLES EMBOîTER QU’UNE SEULE FOIS.

Step 1

Step 2

Step 3

ASSEMBLED WINGS IN PLACE

NOTE: CAREFULLY SNAP WING RETAINER INTO PLACE, TRAPPING WINGS

AGAINST THE FUSELAGE. MAKE SURE THE WINGS ARE ALIGNED PROPERLY.

A B

Kit 1180 - Page 2

1st

2nd

WING BOTTOM

WING TOP

FUSELAGE TOP

WING RETAINER

COCKPIT PILOTS

FUSELAGE BOTTOM

FUSELAGE TOP

Step 5

Step 4

MISSILES SHOWN IN PLACE

Kit 1180 - Page 3

AFTERBURNER

NOZZLE

REAR OF FUSELAGE

BOTTOM

REAR OF FUSELAGE TOP FRONT OF FUSELAGE TOP

CENTER

OF FUSELAGE

BOTTOM

TOP SIDE IS SHOWN 10

CANARDS

MISSILES

VERTICAL

STABILIZER

VERTICAL

STABILIZER

CANOPY

A B

321415

109

8 13 9 11

714912

Step 7

Step 6

Kit 1180 - Page 4

BASE ARM

BASE

NOTE: AFTER SLIDING PART # 17 INTO

PART #16, SLIDE

BACK TO LOCK INTO PLACE.

NOTE: "SWING WINGS" ARE POSITIONABLE. PUT YOUR WINGS

FORWARD FOR TAKEOFF AND BACK FOR SUPERSONIC FLIGHT.

NOTE: INSERT FRONT

HOOK INTO SLOT FIRST.

NOTE: When applying stickers, avoid touching the “sticky” side to prevent finger prints on stickers. Bend sticker sheet slightly to lift edge of sticker & use a finger nail

to lift sticker from sheet. Line up sticker on body and press an edge into place, slowly working sticker with a finger nail until sticker is fully on model.

REMARQUE : Pendant l’application des autocollants, éviter de toucher à la face collante pour ne pas laisser d’empreintes. Plier légèrement la feuille d’autocollants

pour relever le bord d’un autocollant, et le détacher de la feuille avec le bout d’un ongle. Aligner l’autocollant sur la carrosserie, appuyer pour coller un de ses bords, et

continuer de l’appliquer lentement du bout de l’ongle jusqu’à ce qu’il soit complètement collé sur le modèle réduit.

Bonus stickers are included

on the sticker sheet. You

may place them wherever

you like on your model or

wherever you want!
