REVELL KIT 1742 Manuale utente

Á LIRE AVANT DE COMMENCER

• DÉGAGGEZ UN ESPACE POUR

TRAVAILLER.

• ÉTUDIEZ LES ÉTAPES DE MONTAGE

AVANT DE COMMENCER.

• CHAQUE PIÉCE EN PLASTIQUE PORTE

UN NUMÉRO DE PIÉCE.

• LISEZ LA RE MARQUE CONCERNANT

L´APPLICATION DES AUTO-COLLANTS,

´A L´ ÉTAPE 7 .

MISE EN GARDE:

POSITIONNEZ AVEC PRÉCAUTION

TOUTES LES PIÉCES DE CE MODÉLE

RÉDUIT, CAR VOUS NE POUVEZLES

EMBOîTER QU’UNE SEULE FOIS.

SHERMAN TANK

85174210200

READ BEFORE YOU BEGIN

• CLEAR A SPACE TO WORK ON

• STUDY THE ASSEMBLY DRAWINGS

BEFORE YOU BEGIN

• EACH PLASTIC PART IS IDENTIFIED BY

A PART NUMBER

• SEE NOTE ABOUT APPLYING

STICKERS IN STEP #7

CAUTION:

POSITION ALL PARTS IN THIS KIT

CAREFULLY. PARTS WILL ONLY SNAP

TOGETHER ONCE.

KIT 1742

* REPEAT SEVERAL TIMES

* A REPETER PLUSIEURS FOIS

* REMOVE AND THROW AWAY

* A RETIRER ET JETER

* APPLY STICKER

* APPLIQUEZ LES AUTO-COLLANTS

The Sherman M4A1 rock-

et launcher tank had a

cast iron hull and earned

the nickname “Sreamin

Mimi” from the shriek-

ing sound the missles

made as they left the “Cal-

liope” rocket launcher.

Your Revell model has

a movable turret, cannon

and launcher and rolls on

hidden wheels. Also in-

cluded is a scale U.S Army

Jeep with motorcycle and

three soldier gures and

authentic military peel

and stick decal markings.

If you have any questions or comments, call our hotline at: (800) 833-3570

or, please write to:

Revell Inc Consumer Service Department, 1840 Howard Street Unit A, Elk Grove Village, Illinois 60007

Be sure to include the plan number (85174210200), part number, description, your return address and phone number.

Visit our website: www.revell.com

Step 1

Step 2

HULL

TOP

HULL

BOTTOM

HULL

REAR

WHEEL

TREADS

WHEEL

TREADS

KIT 1742 Page - 1

Step 3

Step 4

CUPOLA

BOTTOM

CUPOLA

PIVOT

CUPOLA

PIVOT

CANNON

SHEILD

CANNON BARREL

MACHINE

GUN

ROCKET SIDE SUPPORT

CANNON

PIVOT

KIT 1742 Page - 2

Step 7 Sticker Placement Guide

NOTE: When applying stickers, avoid touching the “sticky” side to prevent finger prints on stickers. Bend sticker sheet slightly

to lift edge of sticker & use a fingernail to lift sticker from sheet. Line up sticker on body and carefully press an edge

into place, slowly working sticker with a fingernail until sticker is fully on model.

REMARQUE : Pendant l’application des autocollants, éviter de toucher à la face collante pour ne pas laisser d’empreintes.

Plier légèrement la feuille d’autocollants pour relever le bord d’un autocollant, et le détacher de la feuille avec le

bout d’un ongle. Aligner l’autocollant sur la carrosserie, appuyer pour coller un de ses bords, et continuer de

l’appliquer lentement du bout de l’ongle jusqu’à ce qu’il soit complètement collé sur le modèle réduit.

Step 5

Step 6

TURN TURRET TO RAISE AND

LOWER GUN AND ROCKET

LAUNCHER

SHORT ROCKET

TUBES

BOTTOM

SHORT

ROCKET

TUBES

TOP

PIVOT

ARM

TUBE

SUPPORT

LONG

ROCKET

TUBES

TOP

LONG ROCKET

TUBES BOTTOM

COMPLETED ROCKET

ASSEMBLY

REPEAT fOR

OTHER SIDE

KIT 1742 Page - 3
