Display Specifications
Display: 8” Full-color a-Si TFT
Display Type: TN
Resolution (Native):800x480 Pixels
Aspect Ratio: 16:9 Widescreen
Display Colors: 16.2M
Active Area: 176.64mm (H) x 99.36 (V)
Dot Pitch: 0.0736mm (H) x 0.2070 (V)
Surface Treatment: Anti-Glare
Weight: 251g (LCD Panel)
Input Voltage: 12V DC
Operating Temp: -30C to 85C
Total Power: 2.5W
Display Features
•Slimmest Open Frame Design in the Market
•Detachable Brackets for Versatile Mounting
•Convenient Extended Cables with Connectors
•Easy Installation & Cable Replacement
•VGA Analog Input
•DVI Digital Input (If Available)
•HDMI Digital Input
•1x RCA Composite (NTSC/PAL) Video Input
•2x RCA Composite Audio Input
•2x Speaker Level Outputs (for Internal Optional Speakers)
•Selectable Audio Input via On-Screen Menu (HDMI or External Audio Input)
Optical Specifications
Brightness: 450 Nits
Display Type: 500:1
Backlight Lifetime: 20,000 Hours (minimum)
Viewing Angle: Right 70 deg
Left 70 deg
Up 50 deg
Down 70 deg
Response Time: Tr 10ms
Tf 15ms
Luminance
Uniformity: 75%
Color Gamut: Not Available
