Ricoh Aficio 340 Manuale utente

Read this manual carefully before you use this product and keep it handy

for future reference.

For safety, please follow the instructions in this manual.

COPY REFERENCE

340/350/450

OPERATING INSTRUCTIONS

ND0A0101

Introduction

This manual contains detailed instructions on the operation and maintenance of this machine. To get

maximum versatility from this machine all operators should carefully read and follow the instructions in

this manual. Please keep this manual in a handy place near the machine.

Please read the Safety Information before using this machine. It contains important information related

to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.

-Notes:

Some illustrations may be slightly different from your machine.

Certain options may not be available in some countries. For details, please contact your local dealer.

Operator Safety:

This machine is considered a class 1 laser device, safe for office/EDP use. The machine contains two

5-milliwat, 760 – 800 nanometer wavelength, GaAIAs laser diodes. Direct (or indirect reflected) eye

contact with the laser beam might cause serious eye damage. Safety precautions and interlock mech-

anisms have been designed to prevent any possible laser beam exposure to the operator.

The following label is attached on the back side of the machine.

Laser Safety:

The optical housing unit can only be repaired in a factory or at a location with the requisite equipment.

The laser subsystem is replaceable in the field by a qualified Customer Engineer. The laser chassis is

not repairable in the field. Customer engineers are therefore directed to return all chassis and laser sub-

systems to the factory or service depot when replacement of the optical subsystem is required.

Warning:

Use of controls or adjustment or performance of procedures other than those specified in this manual

might result in hazardous radiation exposure.

Notes:

The model names of the machines do not appear in the following pages. Check the type of your ma-

chine before reading this manual. (For details, see ⇒P.1

“Machine Types”

• Type 1: Aficio 340

• Type 2: Aficio 350

• Type 3: Aficio 450

Certain types might not be available in some countries. For details, please contact your local dealer.

Two kinds of size notation are employed in this manual. With this machine refer to the metric version.

For good copy quality, Ricoh recommends that you use genuine Ricoh toner.

Ricoh shall not be responsible for any damage or expense that might result from the use of parts other

than genuine Ricoh parts in your Ricoh office product.

Power Source

220 – 240 V, 50/60 Hz, 6 A or more

Please be sure to connect the power cord to a power source as above. For details about power source,

see ⇒P.167

“Power Connection”

CLASS 1 LASER PRODUCT

IN ACCORDANCE WITH IEC 825

LASER KLASSE 1 nach IEC 825

SAFETY INFORMATION

When using your machine, the following safety precautions should be always be

followed.

Safety During Operation

In this manual, the following important symbols are used:

Examples Of Indications

WARNING:

Ignoring this warning could cause serious injury or even death.

CAUTION:

Ignoring this caution could cause injury or damage to property.

Symbols Rmean a situation that requires you take care.

Symbols vmean “Hot surface”.

Do NOT carry out the operation represented by this symbol m.

This example means “Do not take apart”.

Symbols ●mean you MUST perform this operation.

This example means “You must remove the wall plug”.

WARNING:

•

Only connect the machine to the power source described on

the inside front cover of this manual.

•

Avoid multi-wiring.

•

Do not damage, break or make any modifications to the pow-

er cord. Do not place heavy objects on it, pull it hard or bend

it more than necessary. These actions could cause an elec-

tric shock or fire.

•

Do not plug or unplug the power cord with your hands wet.

Otherwise, an electric shock might occur.

•

Make sure the wall outlet is near the machine and freely ac-

cessible so that in event of an emergency it can be un-

plugged easily.

•

Do not remove any covers or screws other than those spec-

ified in this manual. Some parts of the machine are at a high

voltage and could give you an electric shock. Also, if the ma-

chine has laser systems, direct (or indirect) reflected eye

contact with the laser beam may cause serious eye damage.

When the machine needs to be checked, adjusted, or re-

paired, contact your service representative.

•

Do not take apart or attempt any modifications to this ma-

chine. There is a risk of fire, electric shock, explosion or loss

of sight. If the machine has laser systems, there is a risk of

serious eye damage.

•

If the machine looks damaged or breaks down, smoke is

coming out, there is a strange smell or anything looks un-

usual, immediately turn off the operation and main power

switches then unplug the power cord from the wall. Do not

continue using the machine in this condition. Contact your

service representative.

•

If metal, liquid or foreign matter falls into the machine, turn

off the operation and main power switches, and unplug the

main power cord. Contact your service representative. Do

not keep using the machine with a fault or defect.

•

Do not put any metal objects or containers holding water

(e.g. vases, flowerpots, glasses) on the machine. If the con-

tents fall inside the machine, a fire or electric shock could

occur.

iii

•

Do not incinerate used toner or toner containers. Toner dust

might ignite when exposed to an open flame. Dispose of the

used toner containers according to local regulations for

plastics.

CAUTION:

•

Keep the machine away from humidity and dust. A fire or an elec-

tric shock might occur.

•

Do not place the machine on an unstable or tilted surface. If it top-

ples over, it could cause injury.

•

After you move the machine, fix it with the caster fixture. Other-

wise, the machine might move or come down to cause a personal

injury.

•

When you move the machine, unplug the power cord from the

wall outlet to avoid fire or electric shock.

•

When the machine will not be used for a long time, unplug the

power cord.

•

When you pull out the plug from the socket, grip the plug to avoid

damaging the cord and causing fire or electric shock.

•

If you use the machine in a confined space, make sure there is a

continuous air turnover.

•

Do not reuse stapled paper. Do not use aluminum foil, carbon-

containing paper or other conductive paper. Otherwise, a fire

might occur.

•

When removing misfed paper, do not touch the fusing section be-

cause it could be very hot.

•

This machine has been tested for safety using this supplier's

parts and consumables. We recommend you only use these

specified supplies.

•

Do not eat or swallow toner.

•

Keep toner (used or unused) and toner containers out of reach of

children.

•

This equipment is only to be installed by a qualified service per-

sonnel.

•

Deliver to collection point for waste products. Do not be disposed

of via domestic refuse collection.

HOW TO READ THIS MANUAL

Symbols

In this manual, the following symbols are used:

WARNING:

This symbol indicates a potentially hazardous situation that might result in

death or serious injury when you misuse the machine without following the in-

structions under this symbol. Be sure to read the instructions, all of which are de-

scribed in the Safety Information section.

CAUTION:

This symbol indicates a potentially hazardous situation that might result in mi-

nor or moderate injury or property damage that does not involve personal injury

when you misuse the machine without following the instructions under this

symbol. Be sure to read the instructions, all of which are described in the Safety

Information section.

* The statements above are notes for your safety.

Important

If this instruction is not followed, paper might be misfed, originals might be

damaged, or data might be lost. Be sure to read this.

Preparation

This symbol indicates the prior knowledge or preparations required before op-

erating.

Note

This symbol indicates precautions for operation, or actions to take after misop-

eration.

Limitation

This symbol indicates numerical limits, functions that cannot be used together,

or conditions in which a particular function cannot be used.

Reference

This symbol indicates a reference.

[ ]

Keys that appear on the machine's panel display.

{ }

Keys built into the machine's operation panel.

vii

viii

WHAT YOU CAN DO WITH THIS MACHINE

(COPY MODE)

1*1

Cover / Paper Designate

⇒Page 91.

Paper Designate

Both Covers

Front Cover

Amm

Bmm

amm

bmm

Directional Size

Magnification(mm)

⇒Page 69. a%

Directional

Magnification(%)

⇒Page 71.

111*1

OHP Slip Sheet

⇒Page 96.

Positive / Negative

⇒Page 98.

Series Copies

⇒Page 82.

Enhanced Image Copy ⇒Page 38.

Clear Image Copy

Map

ND0X0400

12 1 2

Image Repeat ⇒Page 99.

Image Repeat

Double Copies

RRRR

RRR

Archive File ⇒Page 102.

Store

Recall

MAP Memory
