3.1.2 SERVICE CALL TABLES - 1

SC1xxx: Scanning

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

Exposure lamp error

The peak white level is less than 64/255 digits (8 bits) when scanning

the shading plate.

Exposure lamp defective

Lamp stabilizer defective

Exposure lamp connector defective

Standard white plate dirty

Scanner mirror or scanner lens out of position or dirty

101 D

1. Check and clean the scanner mirror(s) and scanner lens.

2. Check and clean the shading plate.

3. Replace the exposure lamp.

4. Replace the lamp stabilizer.

5. Replace the scanner mirror(s) or scanner lens.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

Scanner home position error 1

The scanner home position sensor does not detect the “OFF” condition

during operation.

Scanner motor driver defective

Scanner motor defective

Harness between SIO board and scanner motor disconnected

Scanner HP sensor defective

Harness between SIO and HP sensor disconnected

120 D

1. Check the cable connection between the SIO board and scanner

motor.

http://www.manuals4you.com

SC Tables

D027/D029 APPENDICES 3-6 SM

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

2. Check the cable connection between the SIO and HP sensor.

3. Replace the scanner motor.

4. Replace the HP sensor.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

Scanner home position error 2

The scanner home position sensor does not detect the “ON” condition

during operation.

Scanner motor driver defective

Scanner motor defective

Harness between SIO board and scanner motor disconnected

Scanner HP sensor defective

Harness between SIO and HP sensor disconnected

121 D

1. Check the cable connection between the SIO board and scanner

motor.

2. Check the cable connection between the SIO and HP sensor.

3. Replace the scanner motor.

4. Replace the HP sensor.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

Black level detection error

The black level cannot be adjusted within the target value during the

zero clamp.

Harness disconnected

Defective SBU

141 D

1. Check the cable connection

2. Replace the SBU.

SC Tables

SM 3-7 D027/D029 APPENDICES

Appendix

Service Call

Conditions

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

White level detection error

The white level cannot be adjusted within the target during auto gain

control.

Dirty exposure glass or optics section

SBU board defective

Exposure lamp defective

Lamp stabilizer defective

Scanner motor defective

142 D

1. Clean the exposure glass, white plate, mirrors, and lens.

2. Check if the exposure lamp is lit during initialization.

3. Check the harness connection between SBU and BICU.

4. Replace the exposure lamp.

5. Replace the scanner motor.

6. Replace the SBU board.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

SBU communication error

The SBU connection cannot be detected at power on or recovery from

the energy save mode.

Defective SBU

Defective harness

Defective detection port on the BICU

144 D

1. Replace the harness.

2. Replace the SBU.

3. Replace the BICU.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

161 IPU error

http://www.manuals4you.com

SC Tables

D027/D029 APPENDICES 3-8 SM

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

The error result of self-diagnostic by the ASIC on the BICU is detected.

Defective BICU

Defective connection between BICU and SBU

001 D

1. Check the connection between BICU and SBU.

2. Replace the BICU.

Detected an error during an access to the Ri.

Defective BICU board

002 D

1. Replace the BICU board.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

Copy Data Security Unit error

The copy data security board is not detected when the copy data

security function is set "ON" with the initial setting.

A device check error occurs when the copy data security function is

set "ON" with the initial setting.

Incorrect installation of the copy data security board

Defective copy data security board

165 D

1. Reinstall the copy data security board.

2. Replace the copy data security board.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

Serial Number Mismatch

Serial number stored in the memory does not have the correct

code.

195 D

NVRAM defective

BICU replaced without original NVRAM

SC Tables

SM 3-9 D027/D029 APPENDICES

Appendix

Service Call

Conditions

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

1. Check the serial number with SP5-811-002.

2. If the stored serial number is incorrect, contact your supervisor.

http://www.manuals4you.com

SC Tables

D027/D029 APPENDICES 3-10 SM

3.1.3 SERVICE CALL TABLES - 2

SC Codes Group 2: Exposure

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

Polygon motor error 1: ON timeout

The polygon mirror motor does not reach the targeted operating speed

within the specified time after turning on or changing speed

Defective or disconnected harness to polygon motor driver board

Defective polygon motor driver board

Defective polygon motor.

202 D

1. Replace the polygon motor.

2. Replace the laser optics housing unit.

3. Replace the harness.

4. Replace the BICU.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

Polygon motor error 2: OFF timeout

The polygon mirror motor does leave the READY status within 3

seconds after the polygon motor switches off.

Disconnected or defective harness to polygon motor driver board

Defective polygon motor driver board

Defective polygon motor

203 D

1. Check or replace the harness.

2. Replace the polygon motor.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

204 D Polygon motor error 3: XSCRDY signal error

SC Tables

SM 3-11 D027/D029 APPENDICES

Appendix

Service Call

Conditions

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

The SCRDY_N signal goes HIGH (inactive) while the laser diode is

firing.

Disconnected or defective harness to polygon motor driver board

Defective polygon motor

Defective polygon motor driver board

1. Check or replace the harness.

2. Replace the polygon motor.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

210 C Laser synchronizing detection error: end position [K]

211 C Laser synchronizing detection error: end position [Y]

212 C Laser synchronizing detection error: end position [M]

213 C Laser synchronizing detection error: end position [C]

The laser synchronizing detection signal for the end position of LDB [K],

[Y], [M], [C] is not detected for one second after the LDB unit turned on

when detecting the main scan magnification.

Disconnected or defective harness to synchronizing detector for

end position

Defective synchronizing detector board

Defective LD board or driver

Defective BICU

- -

1. Replace the harness of the LD board.

2. Replace the laser optics housing unit.

3. Replace the BICU.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

220 D Laser synchronizing detection error: start position [K]: LD0

http://www.manuals4you.com

SC Tables

D027/D029 APPENDICES 3-12 SM

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

221 D Laser synchronizing detection error: start position [K]: LD1

222 D Laser synchronizing detection error: start position [Y]: LD0

223 D Laser synchronizing detection error: start position [Y]: LD1

224 D Laser synchronizing detection error: start position [M]: LD0

225 D Laser synchronizing detection error: start position [M]: LD1

226 D Laser synchronizing detection error: start position [C]: LD0

227 D Laser synchronizing detection error: start position [C]: LD1

The laser synchronizing detection signal for the start position of the

LDB [K], [Y], [M], [C] is not output for two seconds after LDB unit turns

on while the polygon motor is rotating normally.

Disconnected cable from the laser synchronizing detection unit or

defective connection

Defective laser synchronizing detector

Defective LDB

Defective BICU

- -

1. Check the connectors.

2. Replace the laser-synchronizing detector.

3. Replace the LDB.

4. Replace the BICU.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

FGATE ON error: K

The PFGATE ON signal does not assert within 5 seconds after

processing the image in normal job or MUSIC for start position [K].

230 D

Defective ASIC (Lupus)

Poor connection between controller and BICU.

Defective BICU

SC Tables

SM 3-13 D027/D029 APPENDICES

Appendix

Service Call

Conditions

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

1. Check the connection between the controller board and the BICU.

2. Replace the BICU.

3. Replace the controller board.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

FGATE OFF error: K

The PFGATE ON signal still asserts within 5 seconds after

processing the image in normal job or MUSIC for end position [K].

The PFGATE ON signal still asserts when the next job starts.

231 D

See SC 230 for troubleshooting details.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

FGATE ON error: Y

The PFGATE ON signal does not assert within 5 seconds after

processing the image in normal job or MUSIC for start position [Y].

232 D

See SC 230 for troubleshooting details.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

FGATE OFF error: Y

The PFGATE ON signal still asserts within 5 seconds after

processing the image in normal job or MUSIC for end position [Y].

The PFGATE ON signal still asserts when the next job starts.

233 D

See SC 230 for troubleshooting details.

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

234 D FGATE ON error: M

http://www.manuals4you.com

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Ricoh Stampante tutto in uno

Ricoh

Ricoh Pro C651EX Manuale utente

Ricoh

Ricoh CL1000N Manuale utente

Ricoh

Ricoh A172 Manuale utente

Ricoh

Ricoh G179 Manuale utente

Ricoh

Ricoh PRO C7200 Manuale utente

Ricoh

Ricoh Aficio 1035 Series Manuale utente

Ricoh

Ricoh Aficio MP 9002 Manuale utente

Ricoh

Ricoh Aficio 106/LD215c Manuale di istruzioni e di sicurezza

Ricoh

Ricoh Pro 8100S Manuale utente

Ricoh

Ricoh Aficio 400 Manuale utente

Ricoh

Ricoh G565 Manuale utente

Ricoh

Ricoh Aficio MP C2030 Manuale utente

Ricoh

Ricoh D179 Manuale utente

Ricoh

Ricoh Aficio MP 8001 Manuale utente

Ricoh

Ricoh Aficio 3224C Manuale di servizio

Ricoh

Ricoh Priport DX 3343 Manuale utente

Ricoh

Ricoh 5502 Istruzioni utente

Ricoh

Ricoh M 2701 Manuale utente

Ricoh

Ricoh Aficio SG 3100SNw Manuale per l'uso e la cura

Ricoh

Ricoh Robin Manuale utente

Ricoh

Ricoh Aficio 1050 Istruzioni utente

Ricoh

Ricoh Aficio SP C210 Manuale utente

Ricoh

Ricoh MP 7503SP Guida rapida

Ricoh

Ricoh Aficio 1515 Manuale utente

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Brother

Brother MFC-J430w Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Brother

Brother MFC-9760 Manuale utente

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Canon

Canon ImageCLASS 2300 Manuale

Lexmark

Lexmark X925 Manuale utente

Brother

Brother Business Smart MFC-J4510dw Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente

Oce

Oce VarioLink 5022 Manuale utente
