InfoPrint 4247 Model Z03 printer features increased durability

and faster print speed for demanding applications

Table of contents

2Key prerequisites 8Technical description

2Planned availability date 9Publications

2Description 10 Technical information

7Product positioning 16 Terms and conditions

8Product number 17 Pricing

At a glance

The new InfoPrint® 4247 Model Z03 printer is built on the strengths of previous models of the

InfoPrint 4247 family.

• Print speed of up to 1100 characters per second (cps) in Fast Draft mode

• Rugged design with metal covers for demanding transaction applications

• Remote printer management capabilities when LAN attached

• Parallel, Ethernet, Serial, and USB 2.0 optional integrated attachments

• Auto forms loading, auto thickness adjustment, and auto eject to enhance operator

productivity

• Workload capacity of up to 64,000 pages per month

• Multiple data stream emulations to provide easy replacement of older printers

• Forms width from 3 to 17 in (76 to 432 mm)

• Maximum print width of 13.6 in (348 mm)

• One or two continuous forms front tractors for maximum forms-feeding reliability

• Easy-to-use operator panel

• Fast Draft, DP, DP Text, NLQ Gothic, NLQ Courier, OCR-A, and OCR-B resident fonts

Overview

A fast and reliable printer for harsh conditions

The InfoPrint 4247 Model Z03 is a professional industrial impact matrix printer capable of printing

at speeds of up to 1100 cps in Fast Draft mode.

A rugged printer with metal covers, the Model Z03 is designed for harsh environments and

demanding applications.

InfoPrint Solutions Company Canada Hardware

Announcement A08-1078 InfoPrint is a registered trademark of Ricoh Co., Ltd. 2

The Model Z03 can have either one or two straight continuous-forms paper paths for outstanding

paper-feeding reliability. One paper path is standard; the second path is an optional feature.

The printer features new black covers, a full-size 2 line x 24 character 14 key operator panel,

and a workload of up to 64,000 pages per month. Print-quality choices are Fast Draft mode, DP

mode (DP), DP Text mode (DP Text), Near Letter Quality mode (NLQ), OCR-A, and OCR-B.

Versatile paper-handling capability provides printing on up to 8-part carbonless forms.

Typical applications include transaction processing for invoices, office or internal business

documents, as well as bar codes, labels, and multipart forms.

Support for a range of connectivity options and hardware environments

Optional attachments include:

• Parallel

• Ethernet 10/100 local area network attachment for either IPDS™ or ASCII data streams

• USB 2.0

• Serial port for RS-232C 9-pin

Key prerequisites

None

Planned availability date

July 25, 2008

This Announcement is only for the following country:

• Canada

Description

Print speed

Print speeds in characters per second (cps) of the 4247-Z03 at 10 cpi are up to:

• 1100 cps in Fast Draft mode

• 800 cps in DP mode

• 480 cps in DP Text

• 240 cps in NLQ mode

The print speed in lines per minute in Fast Draft mode, 10 cpi, 6 lines per inch is up to:

• 500 lines per minute at 60 characters per line (with a 6-inch line length)

• 310 lines per minute at 136 characters per line (with a 6-inch line length)

Heavy-duty, reliable printing

The 4247-Z03 is a professional industrial heavy-duty printer with metal covers and a workload

capacity of up to 64,000 pages per month. The 18-wire print head provides reliable printing on up

to 8-part carbonless forms in Data Processing (DP), Data Processing Text (DP Text), Near Letter

Quality (NLQ), and OCR print modes.

Flexible forms handling

InfoPrint Solutions Company Canada Hardware

Announcement A08-1078 InfoPrint is a registered trademark of Ricoh Co., Ltd. 3

The InfoPrint 4247 printer provides exceptional forms-handling flexibility. The base printer

includes one continuous-forms tractor path; a second continuous-forms front tractor paper path

is optional.

This dual front paper path capability can translate into a single printer performing work that

formerly required two or more printers. Users can load different forms into each tractor path and

then enable the path that corresponds to the desired print job.

Print quality comparison

Print modes include Fast Draft, Data Processing (DP), Data Processing Text (DP Text), Near

Letter Quality (NLQ), OCR-A, and OCR-B. Print qualities on the 4247-Z03 are equivalent

in character size, shape, and resolution to the print qualities available on the previous 4247

printers.

The following table summarizes the print quality for Fast Draft, DP, DP Text, and NLQ at 10

characters per inch.

Print Quality Horizontal Vertical Horizontal Vertical

dpi dpi Cell Size Cell Size

(Dots) (Dots)

Fast Draft 45 72 9 9

DP 60 72 12 9

DP Text 100 72 20 9

NLQ 100 144 20 18

Operator panel

The 4247-Z03 includes a redesigned, improved full-size operator panel.

The operator panel enables access to many of the printer's functions including paper path

selection, paper loading and parking, and the printer configuration.

The Operator Panel includes:

• A 2 line by 24 character LCD display

• Fourteen push buttons

• Three status indicators

• An audible alarm

When LAN attached, the Operator Panel display can be viewed from any Web browser and

remotely controlled with the Remote Printer Management Utility (RPMU) virtual operator panel.

Paper handling:

• Continuous forms

The 4247-Z03 will handle up to 8-part carbonless continuous forms in either front paper path.

For the front tractor paths:

– Form weight can range from 56 grams per square metre (gsm) (15 lb) to 150 gsm (40 lb).

Paper weights outside this range must be tested by the customer for proper operation.

– Overall (total) form thickness for all parts may range from 0.08 mm (0.003 in) to 0.64 mm

(0.025 in).

The following forms widths and lengths are supported:

– Form width from 76.2 mm (3 in) to 431.8 mm (17 in)

– Form lengths from 76.2 mm (3 in) to 609.6 mm (24 in)

InfoPrint Solutions Company Canada Hardware

Announcement A08-1078 InfoPrint is a registered trademark of Ricoh Co., Ltd. 4

Forms less than 152.4 mm (6 in) in length or width should be tested for satisfactory stacking

and may require operator assistance.

Printer data stream emulations

In addition to native 4247 mode, the following emulations are supported for easy replacement of

many older printers.

• ASCII emulation for the Proprinter III XL, IBM® 2381 Personal, and Epson FX printers.

• IPDS emulation for the IBM 4224 and the IBM 4230 printers.

Parallel, USB 2.0, Serial, and Ethernet attachment

For the parallel, USB 2.0, Serial, and Ethernet ports:

• Printers emulated are Proprinter III XL, IBM 2381 Personal Printer, and Epson FX80 - 1170.

• Data streams supported are IBM PPDS and Epson FX.

• IPDS is supported by the Ethernet attachment only.

Existing 4247 Model V03 RPQs

No existing InfoPrint 4247 RPQs currently available for the Model V03 are presently available for

the Model Z03. Submit RPQ requests if an RPQ is needed.

Bulk order for optional features

Since the 4247-Z03 features are all customer installable, in some cases it is desirable to bulk

order certain features so that machines can be easily reconfigured by Business Partners and

end users. Thus, there is no maximum order quantity for 4247-Z03 MES features.

The maximum number of initial-order attachment features that can be ordered is one.

Initial MES

Order Order

Additional Front Tractor 4006 4007

SBCS Ctlr Par, Ser, USB 5350 5351

SBCS Ctlr Par, Eth 10/100, ASCII 5352 5353

SBCS Ctlr Par, Eth 10/100, IPDS 5356 5357

No Controller 9300

Open Printer Stand, black 4470 4471

Cabinet Prtr Stand, black 4472 4473

Shipping:

Ocean Shipping 5250

Air Freight Shipping 5251

Ordering information

The following must be included on all initial orders for a 4247-X03 printer:

1. One controller feature (feature number 5350, 5352, 5356, or 9300). Feature number 9300

indicates that no controller is required.

2. One printer language kit (feature number 9450, 9451, 9452, 9453, 9454, 9455, 9456, 9457,

9458, 9459, 9460, 9461, 9462, 9465, or 9468) A language kit must be included. There are no

defaults.

3. One line cord (feature number 9970, 9971, 9972, 9973, 9974, 9975, 9976, 9250, 9251, 9950,

9978, 9979, or 9997). A line cord feature must be ordered. There are no defaults.

4. Optionally, a printer stand (feature number 4470 or 4472) and/or an additional front tractor

(feature number 4006) may be ordered.

5. A shipping feature (feature number 5250 or 5251) is required.

InfoPrint Solutions Company Canada Hardware

Announcement A08-1078 InfoPrint is a registered trademark of Ricoh Co., Ltd. 5

Additional front tractor assembly- Initial (#4006)

Additional front tractor assembly - MES (#4007)

This feature provides a second 6-pin front continuous forms tractor path. This tractor feature is in

addition to the standard continuous forms tractor paper path standard with the Model Z03. Up to

8-part carbonless or 6-part carbon forms may be used in the front tractor path.

• Maximum per 4247-Z03 printer: One

• Minimum: None

• Maximum order quantity: No maximum quantity for the MES feature

• Corequisites: None

• Prerequisites: Base Z03 or X03 printer

• Field installation: Yes; feature number 4007

• Customer setup: Yes

Printer Controller Cards

SBCS Controller with Parallel, Serial, and USB - Initial (#5350)

SBCS Controller with Parallel, Serial, and USB - MES (#5351)

This feature provides a Single-Byte Character Set Controller with serial, parallel, and USB ports

for host attachment.

• Maximum per 4247-Z03 printer: One

• Minimum per 4247-Z03 printer: Zero

• Maximum order quantity: No maximum quantity for the MES feature

• Corequisites: None

• Prerequisites: 4247-Z03

• Limitations: Not with any other controller card feature; each printer can have only one of the

following (feature number 5350, 5351, 5352, 5353, 5356, 5357, or 9300) on an initial order

• Field installation: Yes; feature number 5351

• Customer setup: Yes

SBCS Controller with Parallel and Ethernet 10/100 ASCII - Initial (#5352)

SBCS Controller with Parallel and Ethernet 10/100 ASCII - MES (#5353)

This feature provides a Single-Byte Character Set Controller with parallel and Ethernet 10/100

ports for host attachment.

• Maximum per 4247-Z03 printer: One

• Minimum per 4247-Z03 printer: Zero

• Maximum order quantity: No maximum quantity for the MES feature

• Corequisites: None

• Prerequisites: 4247-Z03

• Limitations: Not with any other controller card feature; each printer can have only one of the

following (feature number 5350, 5351, 5352, 5353, 5356, 5357, or 9300) on an initial order

• Field installation: Yes; feature number 5353

• Customer setup: Yes

InfoPrint Solutions Company Canada Hardware

Announcement A08-1078 InfoPrint is a registered trademark of Ricoh Co., Ltd. 6

SBCS Controller with Parallel, Ethernet 10/100 ASCII-IPDS - Initial (#5356)

SBCS Controller with Parallel, Ethernet 10/100 ASCII-IPDS - MES (#5357)

This feature provides a Single-Byte Character Set Controller with a parallel port and a 10/100

Ethernet attachment for IPDS and ASCII.

• Maximum per 4247-Z03 printer: One

• Minimum per 4247-Z03 printer: Zero

• Maximum order quantity: No maximum quantity for the MES feature

• Corequisites: None

• Prerequisites: 4247-Z03

• Limitations: Not with any other controller card feature; each printer can have only one of the

following (feature number 5350, 5351, 5352, 5353, 5356, 5357, or 9300) on an initial order

• Field installation: Yes; feature number 5357

• Customer setup: Yes

No Controller - Initial (#9300)

This feature specifies that no controller is to be ordered with the base printer. This feature would

normally only be ordered by Business Partners who have an inventory of control unit features

that can be added to a base printer.

The Model Z03 printer must always have at least one control unit feature (feature number 5350,

5351, 5352, 5353, 5356, or 5357) to be operational.

• Maximum per 4247-Z03 printer: One for initial order

• Minimum per 4247-Z03 printer: Zero

• Maximum order quantity: One

• Corequisites: None

• Prerequisites: 4247-Z03

• Limitations: Not with any other controller card feature; each printer can have only one of the

following (feature number 5350, 5351, 5352, 5353, 5356, 5357, or 9300) on an initial order

• Field installation: No, this feature is only applicable to initial orders

• Customer setup: Not applicable

Ocean shipping - Initial (#5250)

This feature can only be used when a quantity of printers sufficient to fill a 20-foot ocean

container is being ordered. Since this container holds 40 printers, this feature can only be used

when an order is being placed for 40 or a multiple of 40 (for example 80, 120, 160) printers.

There is no additional charge for ocean shipping.

• Maximum per 4247-Z03 printer: One per printer

• Minimum per 4247-Z03 printer: Multiples of 40 printers must be ordered

• Maximum order quantity: One

• Corequisites: None

• Prerequisites: 4247-Z03

• Limitations: Either feature number 5250 or 5251 must be ordered with each 4247-Z03 printer;

refer to ordering quantity limitation above

• Field installation: No, this feature is only applicable to initial orders

• Customer setup: Not applicable

Air freight shipping - Initial (#5251)

This feature specifies that the 4247-Z03 printer being ordered is to be shipped by air freight. This

is a chargeable feature.

InfoPrint Solutions Company Canada Hardware

Announcement A08-1078 InfoPrint is a registered trademark of Ricoh Co., Ltd. 7

• Maximum per 4247-Z03 printer: One

• Minimum per 4247-Z03 printer: Zero

• Maximum order quantity: One

• Corequisites: None

• Prerequisites: 4247-Z03

• Limitations: Either feature number 5250 or 5251 must be ordered with each 4247-Z03 printer

• Field installation: No, this feature is only applicable to initial orders

• Customer setup: Not applicable

Open printer stand, black - Initial (#4470)

Open printer stand, black - MES (#4471)

Provides a sturdy printer stand designed for the 4247 Model Z03 printer.

• Maximum per 4247-Z03 printer: One

• Maximum order quantity: Ten

• Minimum: None

• Corequisites: None

• Prerequisites: None

• Field installation: Yes; feature number 4471

• Customer setup: Yes

The open printer stand (#4470, 4471) dimensions are:

• Top surface width: 28.5 in (724 mm)

• Top surface depth: 16 in (406 mm)

• Top surface height: 28 in (711 mm)

• Weight: 63 lb (28.6 Kg)

• Footprint with output tray attached: 28.5 in (72.4 cm) x 32 in (81.3 cm)

Cabinet printer stand, black - Initial (#4472)

Cabinet printer stand, black - MES (#4473)

Provides a sturdy printer stand designed for the 4247 Model Z03 printer.

• Maximum per 4247-Z03 printer: One

• Maximum order quantity: Ten

• Minimum: None

• Corequisites: None

• Prerequisites: None

• Field installation: Yes; feature number 4473

• Customer setup: Yes

The cabinet printer stand (#4472, 4473) dimensions are:

• Top surface width: 28.6 in (726 mm)

• Top surface depth: 16.2 in (411 mm)

• Top surface height: 30.5 in (775 mm)

• Weight: 98.1 lb (44.5 kg)

• Footprint with output tray attached: 726 mm (W) x 792 mm (D) or 28.6 in wide x 31.2 in deep

Product positioning

InfoPrint Solutions Company Canada Hardware

Announcement A08-1078 InfoPrint is a registered trademark of Ricoh Co., Ltd. 8

The InfoPrint 4247-Z03 is a professional industrial printer for the most demanding printing

applications, including high-level print quality and graphic capabilities.

Product number

Description Machine Model

InfoPrint 4247 Model Z03 4247 Z03

Initial MES

Order Order

Feature Feature

Number Number

Add'l Front Tractor, Black 4006 4007

SBCS Ctlr Par, Ser, USB 5350 5351

SBCS Ctlr Par, Eth 10/100 ASCII 5352 5353

SBCS Ctlr Par, Eth 10/100 IPDS 5356 5357

No Controller 9300

Open Prtr Stand, Black 4470 4471

Cabinet Prtr Stand, Black 4472 4473

Printer Language Kits:

Language Kit - English 9450 4550

Language Kit - German 9451 4551

Language Kit - French 9452 4552

Language Kit - Spanish 9453 4553

Language Kit - Italian 9454 4554

Language Kit - Danish 9455 4555

Language Kit - Dutch 9456 4556

Language Kit - Finnish 9457 4557

Language Kit - Norwegian 9458 4558

Language Kit - Swedish 9459 4559

Language Kit - Brazilian Portuguese 9460 4560

Language Kit - Russian 9461 4561

Language Kit - Polish 9462 4562

Language Kit - Turkish 9465 4565

Language Kit - Arabic 9468 4568

Line Cord - Europe 9970 4770

Line Cord - UK 9971 4771

Line Cord - Italy 9973 4773

Line Cord - South Africa 9972 4772

Line Cord - Switzerland 9974 4774

Line Cord - Denmark 9975 4775

Line Cord - Israel 9976 4776

Line Cord - US - 9 foot 9251 4751

Line Cord - US - 6 foot 9250 4750

Line Cord - Australia 9979 4779

Line Cord - S. America 9978 4778

Line Cord - Argentina 9997 4797

Line Cord - Taiwan 9950 4650

Shipping:

Ocean Shipping 5250

Air Freight Shipping 5251

No model conversions apply.

Technical description

• High speed:

– Fast Draft print speed of up to 1100 characters per second (cps)

– DP print speed of up to 800 cps

– DP Text print speed of up to 480 cps

– NLQ print speed of up to 240 cps

InfoPrint Solutions Company Canada Hardware

Announcement A08-1078 InfoPrint is a registered trademark of Ricoh Co., Ltd. 9

• Optional Attachments include:

– Ethernet 10/100 BaseT with RJ-45 connector

– RS-232 9-pin Serial

– USB 2.0 port

– Centronics-compatible 36-pin PC Parallel Port

• 4247 native and IBM 4202 Proprinter III XL, IBM Personal Printer 2381, and Epson FX series

emulation modes for all attachments

• IPDS only for Ethernet LAN attach

• Native mode 4247-Z03 drivers for AIX® and OS/400® environments available on the InfoPrint

Web site.

• Native mode 4247-Z03 drivers for Windows® 95/98, Windows NT® 4.0, Windows 2000,

and Windows XP, and Windows Vista available for downloading on the InfoPrint Solutions

Company Web site.

• Downloadable font support (IBM Proprinter or Epson)

• Resident bar codes - accessible via ASCII data streams using 4247 native mode commands

and via IPDS:

– Code 3-of-9

– UPC-A and UPC-E

– EAN-8 and EAN-13

– UPC/EAN Supplemental encodations (2 and 5 characters)

– Matrix 2-of-5

– Industrial 2-of-5

– Interleaved 2-of-5

– MSI

– Code 128

– Codabar

– Postnet

• Maximum text print resolution of 200 x 144 dots per inch at 20 characters per inch Near Letter

Quality (NLQ) mode

• Maximum graphics print resolution of 240 x 144 dots per inch

Publications

InfoPrint 4247 Printer Model Z03: User's Guide

Language Form Number

English S550-1018-00

Arabic SB20-2256-00

B-Portuguese S517-9196-00

Dutch SA15-6088-00

French SF11-1032-00

German SA12-5167-00

Italian SA13-2220-00

Polish SA85-0195-00

Russian S571-0092-00

Spanish S510-3190-00

Turkish SB10-7077-00

InfoPrint 4247 Printer Model Z03: Quick Setup Guide

Language Form Number

English S550-1017-00

Arabic SB20-2257-00

Brazilian-

InfoPrint Solutions Company Canada Hardware

Announcement A08-1078 InfoPrint is a registered trademark of Ricoh Co., Ltd. 10

Portguese S517-9197-00

Danish S511-5868-00

Dutch SA15-6089-00

Finnish SC23-8019-00

French SF11-1033-00

German SA12-5168-00

Italian SA13-2221-00

Norwegian SA15-4892-00

Polish SA85-0196-00

Russian S571-0093-00

Spanish S510-3191-00

Swedish SA14-3073-00

Turkish SB10-7078-00

The following 4247 Model Z03 publications are shipped with each printer.

• Model Z03: Quick Setup Guide (hardcopy)

• 4247 Model Z03: Safety Information (hardcopy)

• 4247 Model Z03: Statement of Limited Warranty (hardcopy when required by country law)

• A CD-ROM that contains softcopy of the following publications:

–InfoPrint 4247 Model Z03: Quick Setup Guide1

–InfoPrint 4247 Model Z03: User's Guide2

– InfoPrint 4247 Model Z03: Programmer's Reference

– InfoPrint 4247 Model Z03: Safety Information

– InfoPrint 4247 Model Z03: Warranty Information

1The Quick Setup Guide is on the CD in the following languages:

English, French, Brazilian-Portuguese, German, Italian, Spanish, Danish, Dutch, Finnish,

Norwegian, Swedish, Arabic, Polish, Russian, and Turkish.

2The User's Guide is on the CD in the following languages:

English, French, Brazilian-Portuguese, German, Italian, Spanish, Dutch, Arabic, Polish,

Russian, and Turkish.

This CD can also be ordered using Form number GK4T-3959.

All of the above publications are also available for download at the InfoPrint Solutions Company

Web site and can be accessed at

http://www.InfoPrintSolutionsCompany.com

• Select "product publications"

• Select "4247"

• Select the desired publication

The User's Guide contains the following sections:

• Getting Started

• Understanding the Operator Panel

• Printer Configuration Menus

• Setting Up Different Forms Paths

• Problem Solving

• Printer and Form Specifications

Technical information

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Ricoh Stampante tutto in uno

Ricoh

Ricoh Aficio 450 Manuale utente

Ricoh

Ricoh MP 7503SP Guida rapida

Ricoh

Ricoh Aficio SP 1100S Manuale utente

Ricoh

Ricoh SP 230SFNw Manuale utente

Ricoh

Ricoh Afico 180 Manuale utente

Ricoh

Ricoh Aficio MP C3500 Manuale utente

Ricoh

Ricoh DX 3340 Manuale utente

Ricoh

Ricoh B022 Manuale di istruzioni

Ricoh

Ricoh MP 2553 Manuale utente

Ricoh

Ricoh Aficio 220 Manuale utente

Ricoh

Ricoh MP 171L Manuale utente

Ricoh

Ricoh Aficio MP C2050 Manuale utente

Ricoh

Ricoh D025 Manuale utente

Ricoh

Ricoh Aficio MP 161 Manuale utente

Ricoh

Ricoh Aficio MP C305 Istruzioni per l'installazione

Ricoh

Ricoh Aficio 3224C Manuale utente

Ricoh

Ricoh Aficio MP 9001 Manuale utente

Ricoh

Ricoh Aficio SP 204SN Aggiornamento firmware

Ricoh

Ricoh LF 125 (H915) Manuale utente

Ricoh

Ricoh Aficio SP 3400SF Manuale utente

Ricoh

Ricoh 4051 Manuale utente

Ricoh

Ricoh Aficio MP C3500 Manuale utente

Ricoh

Ricoh Printer/Scanner Manuale utente

Ricoh

Ricoh C4540 Manuale utente

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Brother

Brother MFC-J430w Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Brother

Brother MFC-9760 Manuale utente

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Canon

Canon ImageCLASS 2300 Manuale

Lexmark

Lexmark X925 Manuale utente

Brother

Brother Business Smart MFC-J4510dw Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente

Oce

Oce VarioLink 5022 Manuale utente
