Ricoh GXR Manuale utente

Before You Begin

Before using your camera body, take a few moments to familiarize

yourself with the controls and displays (pages 1–10). Refer to this

section as you read through the rest of the manual.

Basic Photography and Playback

Read this section before using the camera for the rst time. It covers the

steps involved in readying the camera for use, taking photographs,

and playing them back (pages 11–44).

Reference

Read this section for information on topics not covered in “Basic Photography

and Playback.”It covers advanced shooting and playback options, and

describes how to print photographs, customize camera settings,

and copy pictures to a computer (pages 45–187).

The rechargeable battery needs to be charged before use. The

battery is not charged at the time of purchase.

GXR DIGITAL CAMERA BODY

Camera Body User Guide

The product serial number can be found on the bottom of

the camera body.

Package Contents

Conrm that the package contains the items listed

below.

* The actual appearance of included items may dier.

GXR camera body

The serial number

can be found on

the bottom of the

camera body.

USB cable with

mini-B connector

Connect the

camera body to

a computer or

printer.

A/V cable

Connect the

camera body to

a TV.

Connector Cap

The cap

comes

mounted on

the camera

body.

Hot shoe cover

The cover comes

mounted on the

hot shoe of the

camera body.

DB-90 rechargeable

battery

BJ-9 battery charger

• CD: Contains software and a Software User Guide.

• Camera Body User Guide (this manual)

• Neck strap

• Warranty

Tip: Attaching the Neck Strap

Put the ends of the neck strap

through the strap eyelets on each

side of the camera body, and

thread the ends through the clips

as shown.

iii

Notices

• Safety precautions: Read all safety precautions thoroughly to ensure

safe use.

• Test shots: Take test shots to ensure that the camera is working

properly before taking photos on important occasions.

• Copyright: Reproduction or alteration of copyrighted documents,

magazines, and other materials, other than for personal, home,

or other similarly limited purposes, without the consent of the

• Exemption from liability: Ricoh Co., Ltd. assumes no liability for failure to

record or display images as a result of product malfunction.

• Warranty: This product is manufactured to local specications and the

warranty is valid within the country of purchase. The manufacturer

assumes no responsibility for servicing the product in other countries

or bearing any expense thereby incurred.

• Radio interference: Operating this product in the vicinity of other

electronic equipment may adversely aect both the camera and

the other device. Interference is particularly likely if the camera is

used in close proximity to a radio or television. This can be resolved

by moving the camera as far as possible from the other device,

reorienting the radio or television antenna, or plugging the radio or

television into a dierent outlet.

be reproduced in whole or in part without Ricoh’s express written

permission. Ricoh reserves the right to change the contents of this

document at any time without prior notice.

Every eort has been made to ensure the accuracy of the information in

this document. Should you nevertheless notice any errors or omissions,

we would be grateful if you would notify us at the address listed on the

back cover of this booklet.

Microsoft, Windows, Windows Vista, and Internet Explorer are registered

trademarks of Microsoft Corporation in the United States of America

and other countries. Macintosh and Mac OS are registered trademarks of

Apple Inc. in the United States of America and other countries. Adobe,

the Adobe logo, and Adobe Reader are trademarks of Adobe Systems

Incorporated.

HDMI, the Logo and High-Denition Multimedia Interface are

trademarks or registered trademarks of HDMI Licensing LLC.

All other trade names mentioned in this document are the property of

their respective owners.

Safety Precautions

Warning Symbols

Various symbols are used throughout this instruction manual and

on the product to prevent physical harm to you or other people and

damage to property. The symbols and their meanings are explained

below.

Danger

This symbol indicates matters that may lead to

imminent risk of death or serious injury if ignored or

incorrectly handled.

Warning This symbol indicates matters that may lead to death

or serious injury if ignored or incorrectly handled.

Caution This symbol indicates matters that may lead to injury

or physical damage if ignored or incorrectly handled.

Sample Warnings

The symbol alerts you to actions that must be performed.

The symbol alerts you to prohibited actions.

The symbol may be combined with other symbols to indicate

that a specic action is prohibited.

Examples

Do not touch Do not disassemble

Observe the following precautions to ensure safe use of this

equipment.

Danger

Do not attempt to disassemble, repair or alter the equipment

yourself. The high-voltage circuitry in the equipment poses

signicant electrical hazard.

Do not attempt to disassemble, alter or directly solder the

battery.

Do not put the battery in a re, attempt to heat it, use it in a

high temperature environment such as next to a re or inside a

car, or abandon it. Do not put it into water or the sea or allow it

to get wet.

Do not attempt to pierce, hit, compress, drop, or subject the

battery to any other severe impact or force.

Do not use a battery that is signicantly damaged or deformed.

Warning

Turn o the power immediately in the event of abnormalities

such as smoke or unusual odors being emitted. Remove the

battery as soon as possible, being careful to avoid electric

shocks or burns. If you are drawing power from a household

electrical outlet, be sure to unplug the power cord from the

outlet to avoid re or electrical hazards. Discontinue use of the

equipment immediately if it is malfunctioning. Contact the

nearest service center at your earliest convenience.

Turn o the power immediately if any metallic object, water,

liquid or other foreign object gets into the camera body.

Remove the battery and memory card as soon as possible,

being careful to avoid electric shocks or burns. If you are

drawing power from a household electrical outlet, be sure to

unplug the power cord from the outlet to avoid re or electrical

hazards. Discontinue use of the equipment immediately if it

is malfunctioning. Contact the nearest service center at your

earliest convenience.

Avoid any contact with the liquid crystal inside the picture

display, should the monitor be damaged. Follow the

appropriate emergency measures below.

• SKIN: If any of the liquid crystal gets on your skin, wipe it o

and rinse the aected area thoroughly with water, then wash

well with soap.

• EYES: If it gets in your eyes, wash your eyes with clean water

for at least 15 minutes and seek medical advice immediately.

• INGESTION: If any of the liquid crystal is ingested, rinse the

mouth out thoroughly with water. Have the person drink a

large amount of water and induce vomiting. Seek medical

assistance immediately.

Follow these precautions to prevent the battery from leaking,

overheating, igniting or exploding.

• Do not use a battery other than those specically

recommended for the equipment.

• Do not carry or store together with metal objects such as

ballpoint pens, necklaces, coins, hairpins, etc.

• Do not put the battery into a microwave or high pressure

container.

• If leakage of battery uid or a strange odor, color change, etc.

is noticed during use or during charging, remove the battery

from the camera body or battery charger immediately and

keep it away from re.

Please observe the following in order to prevent re, electrical

shock or cracking of the battery while charging.

• Use only the indicated power supply voltage. Also avoid the

use of multi-socket adapters and extension cords.

• Do not damage, bundle or alter power cords. Also, do not

place heavy objects on, stretch or bend power cords.

• Do not connect or disconnect the power plug with wet hands.

Always grip the plug section when disconnecting a power

cord.

• Do not cover equipment while charging.

vii

Keep the battery and SD memory card used in this equipment

out of the reach of children to prevent accidental ingestion.

Consumption is harmful to human beings. If swallowed, seek

medical assistance immediately.

Keep the equipment out of the reach of children.

Do not touch the internal components of the equipment if they

become exposed as a result of being dropped or damaged. The

high-voltage circuitry in the equipment could lead to an electric

shock. Remove the battery as soon as possible, being careful

to avoid electric shocks or burns. Take the equipment to your

nearest dealer or service center if it is damaged.

Do not use the equipment in wet areas as this could result in re

or electric shock.

Do not use the equipment near ammable gases, gasoline,

benzene, thinner or similar substances to avoid the risk of

explosion, re or burns.

Do not use the equipment in locations where usage is restricted

or prohibited as this may lead to disasters or accidents.

Wipe o any dust that accumulates on the electrical plug as this

may lead to re.

To avoid the risk of re, electric shock or injury, do not use

the battery charger with commercially available electronic

transformers when traveling abroad.

viii

Observe the following precautions to ensure safe use of this unit.

Caution

Contact with uid leaking from a battery can lead to burns. If

part of your body comes in contact with a damaged battery,

rinse the area with water immediately. (Do not use soap.)

If a battery starts to leak, remove it immediately from the

equipment and wipe the battery chamber thoroughly before

replacing it with a new battery.

Plug the power cords securely into the electrical outlets. Loose

cords pose a re hazard.

Do not allow the camera body to get wet. In addition, do not

operate it with wet hands. Both pose the risk of electric shock.

Do not re the ash at drivers of vehicles, as this may cause the

driver to lose control and result in a trac accident.

Safety

Precautions for

Accessories

When using optional products, carefully read the

instructions provided with the product before

using that product.

Product Manuals

The following manuals are provided with the GXR camera body:

Camera Body User Guide (this booklet)

This guide describes how to use your camera and install the

supplied software.

* Read this guide along with the documentation provided

with the camera unit.

Software User Guide (pdf le)

The Software User Guide describes how to copy pictures from

your camera body to a computer for display and editing. It is

available in several languages, each in its own folder in the

“DC Manual” folder on the supplied CD.

For ease of reference, copy the

pdf le from the CD to your

computer hard disk.

“Irodio Photo & Video Studio” image viewing and editing software

is also included with this product. For information on using this

software, see the Help menu in Irodio Photo & Video Studio or

telephone one of the following customer support centers:

• North America (U. S. A.): +1–800–458–4029 (toll free)

• U. K., Germany, France, and Spain: +800–1532–4865 (toll free)

• Other European countries: +44–1489–564–764

• China: +86–21–5385–3786

• Other Asian countries: +63–2–438–0090

Business hours: 9:00 AM to 5:00 PM

Table of Contents

Package Contents...................................................................................................... ii

Notices.............................................................................................................................iii

Safety Precautions ....................................................................................................iv

Product Manuals........................................................................................................ix

Before You Begin 1

Read this section before using your camera body for the rst time.

Introduction .................................................................................... 2

Parts of the Camera Body .....................................................................................2

Basic Photography and Playback 11

Read this section before using your camera for the rst time.

First Steps.......................................................................................12

Charging the Battery.............................................................................................12

Inserting the Battery .............................................................................................14

Inserting Memory Cards..................................................................................... 15

Attaching the Camera Unit to the Camera Body................................17

Turning the Power On and O .......................................................................18

Basic Setup..................................................................................................................20

Taking Photographs.....................................................................21

Holding the Camera..............................................................................................21

Taking a Photograph.............................................................................................22

Zoom ..............................................................................................................................26

Close-ups (Macro Mode)....................................................................................27

Flash Photography .................................................................................................28

Self-Timer .....................................................................................................................31

Tilt Indicator................................................................................................................32

Viewing and Deleting Photographs..........................................34

Viewing Photographs........................................................................................... 34

Deleting Photographs..........................................................................................39

O(DISP.) Button...................................................................................................42

Altri manuali per GXR

Indice

Altri manuali Ricoh Accessori per fotocamere

Ricoh

Ricoh SRS-1 Manuale utente

Manuali Accessori per fotocamere popolari di altre marche

Viltrox

Viltrox EF-NEX Istruzioni per l'installazione

Calumet

Calumet 7100 Series CK7114 Manuale utente

Ropox

Ropox 4Single Series Manuale utente

Cambo

Cambo Wide DS Digital Series Istruzioni operative

Samsung

Samsung SHG-120 Manuale utente

Ryobi

Ryobi BPL-1820 Manuale operativo

Aegis

Aegis ABL-36020P Manuale utente

Pentax

Pentax Data Back Fc Manuale utente

Fantasea

Fantasea EyeGrabber F Series Manuale utente

Honeywell

Honeywell HDZ20HD Manuale utente

EGO

EGO BA1400T Manuale utente

Sima

Sima SRW-62 Manuale utente

Shape

Shape A7SSMKIT Manuale utente

Slide Kamera

Slide Kamera HST-2 Manuale utente

Power works

Power works 2902613 Manuale utente

SES

SES SE-2047-2 Manuale utente

Olympus

Olympus PT-EP05L Manuale utente

Starlite

Starlite OctoDome nxt Manuale utente
