Chapter

Basic Operations

Turning On/Off the Camera ....24

How to Use the Mode Dial ......25

LCD Monitor and LCD Panel ..26

Recording Mode...........................26

Play Mode ....................................27

Adjusting the LCD Monitor.....28

Adjusting the LCD Monitor

Contrast........................................28

Using the Stylus Pen ....................28

Fine Adjustment of the LCD

Monitor and Touch Screen ...........29

How to Select the Items..........31

Using the Stylus Pen ....................31

Selecting and Canceling Items.....32

Character Input and Writing/

Drawing ....................................35

Using the On-screen Keypad .......35

Using the Tool Palette..................37

Registering the Camera

Information ..............................39

Setting the Date and Time ...........39

Registering Owner Information ....42

Before You Start Recording ...43

Formatting the Storage Memory ..43

Adjusting the Viewfinder Diopter ..44

How to Hold the Camera ..............44

Turning On/Off the Camera

Use the power button to turn the camera on and off.

■Turning the Camera ON

APress the power button.

Note

• You can turn the camera on when

the LCD monitor is opened →

P.122 →“Turning the Camera On/

Off When the LCD Monitor is

Opened”

■Turning the Camera OFF

APress the power button.

Tips

Auto Power Off

The camera will turn off automatically (auto power off) to conserve

the battery if it is left idle (no buttons or switches operated) for a fixed

time. To resume use, turn the power on again. The auto power off

feature does not activate when the camera is powered by an AC

adapter. →P.117 “Auto Power Off Setting”

Basic Operations

How to Use the Mode Dial

The camera offers a number of modes for shooting and playback. Use the

mode dial to select the mode you need.

Mode Dial Mode Action

Setup mode For changing and verifying camera

settings.

Motion Picture For recording motion pictures with sound.

mode

Continuous Enables continuous shooting while the

Shooting mode shutter release button is pressed.

Text mode Used when recording text. Eliminates

gradations and records in black and white.

Voice Memo mode Used when recording sound.

Still Picture mode Basic shooting mode.

Play mode For playing back recorded files.

PC mode For connecting the camera to a PC,

transmitting images from the camera to

the PC and operating the camera from the

PC.

Communication For transmitting images and using Internet

mode functions.

ATurn the mode dial to change the

mode used.

The screen displayed on the LCD monitor

differs according to the mode. For details of

operation, refer to the following.

•(Setup) →P.116

•(Motion Picture) →P.60

•(Continuous Shooting) →P.59

•(Text) →P.58

•(Voice Memo) →P.59

•(Still Picture) →P.55

•(Play) →P.84

Note

•For details of the (PC mode) and (Communication mode), see

‘Connecting to a Personal Computer’operation manual and

‘Communication/Internet’operation manual.

LCD panel LCD monitor

Storage Memory

Flash mode

Red-eye reduction

mode

White balance —

File type

Size/No. of pixels

2048 ×1536, 1024 ×768, 640 ×480

Image quality/ F, N, E, NC

Compression rate

Exposure compensation —EV –2.0 ~ EV +2.0

value

Digital zoom —×1.3, ×1.6, ×3.2

ISO Sensitivity —AUTO, ISO 200, ISO 400

Auto bracket —AB

Focus —AF, MF

Macro shooting —

Self timer mode

Battery symbol —

Soft mode —SOFT

Time Exposure mode —L1, L2, L4, L8

Note

•For details of the messages displayed on the LCD panel and LCD

monitor, see “Error Messages”(P.133).

LCD Monitor and LCD Panel

The LCD monitor or LCD panel displays the camera status, such as the battery

level, recordable picture count and mode setting, in symbols and figures.

Recording Mode

LCD panel LCD monitor

Remaining picture count •Remaining recording time

Folder name

Zoom bar Date and timeMessage

Basic Operations

LCD panel LCD monitor

Storage memory

File type

Size/No. of pixels

2048 ×1536, 1024 ×768, 640 ×480

Image quality/ F, N, E, NC

Compression rate

Battery symbol —

Protect symbol —

Voice annotation

Keypad memo —

Play Mode

LCD panel LCD monitor

Rewind Advance Date and time

Switching to the Edit mode

Playback file no./Total no. of files

Folder name/File name

Adjusting the LCD Monitor

This section explains how to use the LCD monitor including adjusting the

contrast of the LCD monitor and using the fine adjustment function.

Adjusting the LCD Monitor Contrast

If the LCD monitor is hard to see, for example in bright sunlight, adjust the

contrast of the monitor.

APress the LCD contrast adjustment

buttons (왓/왕) to adjust the LCD

monitor contrast to a favorable

setting for viewing.

Using the Stylus Pen

■Stylus Pen

Pull the stylus pen out in the following way and replace it after use.

APull the stylus pen out in the direction

shown by the arrow.

Replace by sliding it back in from the tip.

Basic Operations

ARotate the LCD monitor as illustrated.

Do not rotate beyond the limits of the angle

shown.

BOpen the LCD monitor

perpendicularly, rotate it at an angle

of 180 degrees in the direction of the

arrow and close it.

Fine Adjustment of the LCD Monitor and Touch

Screen

You can use the stylus pen supplied with the camera to select and set items. If

the touch screen does not function properly, use the fine adjustment function to

adjust the LCD monitor and touch screen.

ASet the mode dial to [ ].

See

•P.24 “Turning On/Off the Camera”

•P.25 “How to Use the Mode Dial”

■LCD Monitor

When using the stylus pen, set the LCD monitor as shown below.

CFlip up the LCD monitor

perpendicularly, turn it 180 degrees in

the direction of arrow and close it.

DTouch the marks in the corners with

the pen.

BMove the focus (green frame

enclosing an item) using the

button to select [TOUCH SCREEN

CALIBRATION] and press the ENTER

button.

See

•P.32 “Selecting and Canceling

Items”

Basic Operations

How to Select the Items

You can select items, and confirm or cancel camera settings using the buttons

on the operation panel and stylus pen. This section explains how to use the

buttons and stylus pen.

Using the Stylus Pen

Basically, the stylus pen can be used in the following two ways.

●Touching

Touching is the action of lightly pressing the

screen with the pen. It is used to select items

on the screen or to select the button, such as

[OK] and [CANCEL].

This manual contains instructions such as

“Touch with the pen”and “Select with the

pen”.

●Dragging

Dragging is the action of moving the pen

while keeping it pressed lightly against the

screen. It is used to write characters, drawing

diagrams and designate the scope on the

screen.

This manual contains instructions such as

“Drag the pen”.

Note

•You can perform the above operations using your finger in the same

way as the stylus pen. Touch the screen lightly with the tip of your

finger.

Selecting and Canceling Items

This section explains how to operate the buttons on the touch screen and stylus

pen.

■Switching the Displays

Note

•The legends (“CANCEL”and “ENTER”) above the buttons (EXIT or

OK) are used for annotation with the button operation.

■Selecting and Canceling Items

Note

•The dimmed items can not be selected.

(1)

→

←

(2)

(1)

→

←

(2)

(1)

→

←

(3)

(2)

→

Using the pen

Using the

buttons

Using the pen

Using the

buttons

Select the item (1)

Touch the target

item.

Press the

buttons to move the

focus and press the

ENTER button.

Select the setting (2)

Touch the target

setting and touch

[OK].

Press the

buttons to move the

focus, press

SELECT button

and then press

ENTER button.

Cancel the setting (3)

Touch CANCEL.

Press the CANCEL

button.

Previous screen (2)

Touch on the

lower left of the

screen.

Press the button

to move the focus

on the upper item.

When the focus is

on the top item,

press the

button.

Next screen (1)

Touch on the

lower left of the

screen.

Press the button

to move the focus

(green frame

enclosing an item)

on the lower item.

When the focus is

on the bottom item,

press the button.

Exit the MENU screen

Touch CANCEL.

Press the CANCEL

button.
