Rinnai ZERO CLEARANCE Manuale utente

RIB2310/RIB2311 Sapphire/Neo Zero Clearance Box Assembly

11955-F 06-14

Rinnai New Zealand Ltd. 0800 746 624

Rinnai Australia Pty. Ltd. 1300 555 545

Before installation:

• Unpacktheassemblyandcheckfordamage—DONOTinstallanydamageditems

• Checkallcomponentshavebeensupplied

• Readtheseinstructionstogetanoverviewofthestepsrequiredbeforestartingtheinstallation

Failuretofollowtheseinstructionscouldcauseamalfunctionoftheappliance.Thiscouldresultin

seriousinjuryandpropertydamage.

R2340

Item Qty. Description

1 1 ZCboxbase

2 2 ZCboxside

3 1 ZCboxtop

4 1 ZCboxrear

5 1 ZCspigotguide

6 2 Panelburnboxguideside

7 1 Airductoutletgasket

8 1 Spigottopassembly

9 1 Spigotrear

10 2 Edgeprotectorwhite

11 31 Screw8x10ABzinc

12 2 Rivetpopplain73AS4.2

Important

Toensurethespigotassemblylinesupcorrectlyinsidetheenclosureandthattheapplianceis

installedush,thefrontedgeofthezeroclearanceboxshouldsitushwiththefrontedgeofthe

claddingsurface.

Thedrywalldropsdowntothelevelindicatedbythetwoarrowseithersideofthebox.

Toputtogetherthefullassemblyyoualsoneedtohavetheuespigot(orderedseparately).

RIB2310/RIB2311 Sapphire/Neo

Zero Clearance Box assembly

RIB2310/RIB2311 Sapphire/Neo Zero Clearance Box Assembly

11955-F 06-14

Rinnai New Zealand Ltd. 0800 746 624

Rinnai Australia Pty. Ltd. 1300 555 545

General information

Ø 146

790

361

Ø 53

650

Assembly

1. Rivet the spigot guide to the spigot assembly

Assembleuespigot,andrivetfromtheunderside,thespigotguidehandleprovidedinthezero

clearanceboxkittothespigotassembly.

When this spigot is used with the zero clearance box

these dimples are to be drilled at Ø3.2

RIB2310/RIB2311 Sapphire/Neo Zero Clearance Box Assembly

11955-F 06-14

Rinnai New Zealand Ltd. 0800 746 624

Rinnai Australia Pty. Ltd. 1300 555 545

Assembly

2. Assemble base, sides and rear panel of zero clearance box

Liethebasepanelontheoorandusingthescrewsprovidedintheassemblypack,screwtheside

panelstothebaseandthenattachtherearpanel.

3. Attach full spigot assembly and top panel

Drilloutthetwo3.3mmholesinthespigotwherethetwodimplesarelocated.Screwthefullspigot

assemblytothebackpanelofthezeroclearancebox(thoughthebackofbox)andattachthetoppanel.

RIB2310/RIB2311 Sapphire/Neo Zero Clearance Box Assembly

11955-F 06-14

Rinnai New Zealand Ltd. 0800 746 624

Rinnai Australia Pty. Ltd. 1300 555 545

Assembly

4. Slide into the enclosure and secure

Slidetheassembledzeroclearanceboxintotheenclosureandxthetopandsidestotheenclosure.

Therearetwosetsofscrewholes,thesetyouusewillbedependentonthecladdingthickness.Thezero

clearanceboxMUSTBEinstalledushwiththecladdingsurfacetoensurealignmentoftheue.

Cladding surface

Zero clearance box

front cutout

Top of Neo engine

Top of zero clearance box

5. Apply edge protector

Applywhiteedgeprotectorsprovidedintheassemblypacktothegasandelectricalaccessholes.

6. Side rails

Siderails(number8onfrontpage)needtobeattachedtothetopoftheNeoengineasshown.

Side rails Spigot guide handle
