Riotoro CR1088 Manuale utente

MINI TOWER PC CASE

CR1088

Note: This manual is a guide for the CR1088 MINI TOWER case. For instructions on installing the motherboard and other components,

please refer to their documentation.

Thank you for purchasing the CR1088!

The CR1088 Prism takes the core of the award-winning CR1080 and takes it to

the next level with a muscular new black/red exterior, RGB lighting, increased

internal space, and additional dust filters. Dual compartments: one for the

motherboard, CPU, and graphics card, and a second for the power supply

and drives, direct airflow to critical components for improved cooling efficiency.

Additional mount points for fans or liquid radiators add cooling flexibility. To ease

installation, CR1088 has modern builder-friendly features such as tool-free mounts

and cable tie-downs.

Welcome to RIOTORO

CR1088 MINI TOWER CASE

Before You Begin

- Exploded view

- What is in the box

- Precautions

- Requirements

2Ready, Setup, Go

- Specifications

- Remove the side panels

- Install the motherboard

- Connect the front panel switches and LEDs

- Power supply installation

- Fan installation - front, bottom, rear

- Attaching the case fan cables

- RGB hub details

- Lighting control with RGB motherboards

- Customizing RGB lighting

- SSD / HDD installation

- Water cooling installation - 120.0 mm or 240.0 mm options

- Air cooling installation

- GPU Installation

3Top / Front Panel Assembly

- General Maintenance

- Important Safety Information

- Limited product warranty ("Limited Warranty")

- Troubleshooting your new CR1088

- Recommended parts

CONTENTS

Before You Begin

www.riotoro.com/cases

CR1088 MINI TOWER CASE

Exploded view

1. RGB front panel

2. Acrylic side panel

3. 120.0 mm fan

4. I/O panel

5. Structure

6. HDD / SSD

storage bracket

7. HDD / SSD caddies

8. Side panel

Before You Begin 4

8624

CR1088 MINI TOWER CASE

Standoffs Motherboard

installation 2

WHAT’S IN THE BOX

QTY

ITEM IMAGE USEDESCRIPTION

CR1088

MINI TOWER Case

Nylon ties

Long screws

Fan screws

1Build your gaming

machine

Cable management

Water cooling

installation

Fan installation

Phillip screws Motherboard

installation 12

Before You Begin 5

SSD Screws Secure SSD Drives 12

CR1088 MINI TOWER CASE

Please take the following precautions:

- Handle all PC components and cards with care.

- Hold cards and processors by their edges to avoid damaging

components.

- To avoid damaging components by electrostatic discharge, periodically

ground yourself by touching an unpainted metal surface or by using a

wrist grounding strap.

- Before connecting cables, make sure the connectors are

correctly aligned.

- Consult the documentation of your motherboard and other components

for specific installation instructions and troubleshooting.

Before You Begin 6

PRECAUTIONS

CR1088 MINI TOWER CASE

Before You Begin 7

Note: Handle all components with care, should you need any assistance go to www.riotoro.com/support

REQUIREMENTS

In order to configure the CR1088 you will need:

1. A flat working area (e.g. desk or table)

with sufficient space

2. A magnetic Phillips screw driver

This means you need to have the Phillips screw driver

available in order to complete this assembly.

Ready, Setup, Go

www.riotoro.com/cases

CR1088 MINI TOWER CASE

SPECIFICATIONS

Chapter 2 9

- Type:

- Color:

- Case Material:

- With Power Supply:

- Motherboard Compatibility:

- Side Panel Window:

- External 5.25" Drive Bays:

- External 3.5" Drive Bays:

- Internal 3.5" Drive Bays:

- Internal 2.5" Drive Bays:

- Expansion Slots:

GENERAL

MINI TOWER

Black

Steel, ABS Plastic

ATX, Micro ATX, Mini-ITX

Yes

EXPANSION

- Top Panel:

EXTERNAL

PORTS

2x USB 3.0

2x USB 2.0

1x Headphone

1x Microphone

- Included Fans:

- Fan Mounts:

- Water Cooling Mounts:

COOLING

SYSTEM

Front: 1x 120.0 mm

Front: 2x 120.0 mm

Bottom: 2x 120.0 mm

Rear: 1x 80.0 mm

Front: 1x 120.0 or 1x 240.0 mm

- Max GPU Length:

- Max CPU Cooler Height:

- Max PSU Length:

MAX

DIMENSIONS

290.0 mm

135.0 mm

175.0 mm

- RGB button

- Fan Slow/Fast Buttons
