Riverlea Rustics NEBRASKA Manuale utente

NEBRASKA

ASSEMBLY INSTRUCTIONS

BASE SIZE: 3.600m x 2.490m

• Baery Drill

• Riveter

• Hammer

• Tape Measure

• Ladder

• Skillsaw

• Level

• Screwdriver - Flat

• 3/8 Hex Drive bit

• 8mm Hex Drive bit

• Drill Bit 3.2mm

• Socket Set

• Read all instrucons carefully.

• Idenfy all parts and check quanes against checklist.

• Do not aempt to build your shed in high winds.

• Beware of sharp edges.

• Protect your eyes and ears.

• Use electric tools with care. Use a Safety Trip Switch.

• It is easier and quicker if this shed is erected by two people.

• Your shed must be level. Achieve this by either levelling the

ground or by using blocks.

Tools Required:

Select your site:

Safety:

Before you start:

PG 1

NEBRASKA

Descripon Size Qty

PACK ONE - SHED

Standard Door 895 x 1780 1

Std Wall Panels 1200 x 1877 5

Front Wall Panel 300 x 1877 1

End Wall Panels (L/H) 1200 x 2389 2

End Wall Panels (R/H) 1200 x 2389 2

Door Lintel 110 x 900 1

Cedar Corner Clashings 85 x 17 x 1902 4

30 x 17 Std Cedarbead 30 x 17 x 1877 3

15 x 17 Std Cedarbead 15 x 17 x 1877 2

30 x 17 Gable Cedarbead 30 x 17 x 2389 2

Silicone Tube 300g 2

Roof Truss 535 x 2490 2

Barge Flashings 85 x 40 x 2960 2

Temporary Door Stop 45 x 45 x 900 1

Roof Sheets 845 x 1450 10

Ridge Flashing 175 x 2010 2

15mm Packer 15 x 45 x 1740 1

Hardware Pack

Tek Screws 14G x 75mm, CL4 50

Framing Nails 75 x 3.15mm 80

Bead Nails 50 x 2.5mm 60

Galv Clouts 30 x 2.5mm 50

Colour Rivets 3.2 x 8.2mm 50

Roong Screws and Washers 50mm 30

Padbolt and Keeper 1

Padbolt Screws 32 x 8g 6

Instrucons 1

Oponal

Building Paper (Roof + 20 clouts) 1370 x 7500 1

Clear Roof Panel (Panel replaces roof sheet) Qty

PACK TWO - STIFFENERS (& FLOOR if required)

Purlins (Top) 100 x 25 x 3740 2

Purlins (Boom) 50 x 25 x 3740 2

Spoung 3735mm 2

Seners 45 x 45 x 3600 2

Floor Joists 70 x 45 x 3590 5

Floor Boards 150 x 19 x 2480 24

Floor Nails 50 x 2.5mm 240

Packed by: Date: / /

NEBRASKA PARTS LIST

PG 2

PG 3

Step 1: Establish size of shed and excavate sucient area. Re-

member to allow for rear roof overhang up to 150mm, and

120mm on each end.

Step 2: Ensure that the base substrate is compacted rmly.

We suggest that the slab should be 80mm thick in the middle

and 100mm thick around the edges.

Step 3: Lay boxing to the required size, the raised slab

size should be 3585 x 2475mm and at least 30mm

above the ground line.

Step 4: Lay plasc sheeng if required. Plasc sheeng under slab

will prevent moisture coming through from underneath.

Step 5: Pour concrete and screed ush

Building a Raised Concrete Base

100mm

80mm

100mm

NEBRASKA CONCRETE FLOOR OPTION

PG 4

NEBRASKA FLOOR OPTION

Step 1: Lay out oor joists, spacing them evenly

as shown. Using 50mm ooring nails, nail a oor

board on each end, ensuring ends are ush with

joists. Make sure oor is level and joists are sup-

ported at 1240mm centres.

Step 2: Lay out remaining oor boards. Measure

diagonals to ensure measurements are equal (I.e.

oor is square). Rip down last oor board to suit

gap, and nail o oor with 50mm ooring nails

(10 nails per board).

Step 3: Unpack panels and idenfy wall panels

and door posions as per the wall plan located

on page 5.

Select two panels that go either side of a corner

(gable and standard panel) and stand together.

Example: R (standard) and LG (Gable)

Located on the boom plate of each wall.

PG 5

NEBRASKA WALL PLAN

NEBRASKA

WALL PLAN

1200RG

1200LG

1200 L

300

1200 R

1200RG

1200LG

1200 R

1200 C

1200 L

15 x 17mm Std Cedar bead

30 x 17mm Std Cedar bead

30 x 17mm Gable Cedar bead

Corner Clashing

45 x 20mm Packer

Tek Screws (To secure Walls to Floor)

Truss Locaon

Please note: The walls are not screwed down to the oor unl all the walls

are erected, the roof is in place and the door is about to be installed.

The Boom Plate of each wall will be labelled L, R, C, LG or RG based on

the posion it goes in the wall plan.

Step 4: Screw wall panels together using 75mm tek

screws (3 per low connecon, 4 per high connecon),

ensuring gable walls are inside the standard walls as

per the wall plan on the previous page.

Step 5: Silicone edge of weatherboards on the stand-

ing panel, and lying your next wall down silicone the

connecng edges weatherboards. Nail the bead to the

laid down panel. ( 4 bead nails per standard bead, 5

per gable bead)

Make sure bead is properly sealed to avoid leaks.

Note: On standard panels only, top of bead is bevelled

to allow for slope of roof.

Step 6: Silicone and nail remaining beads on each panel. Screw panels together us-

ing 3 tek screws per join and 4 on the longer joins on gable panels as menoned

above.

PG 6

NEBRASKA WALL INSTALLATION

PG 7

NEBRASKA DOOR LINTEL

Step 8: Using 75mm framing nails, nail both top

plate seners into standard wall panels studs, as

shown using 2 nails per each end stud, and 1 nail

for each remaining stud. Ensure ends are evenly

spaced before nailing.

Step 9: Using 30mm clouts nail top cedar boards

to seners (2-3 nails per board). Predrill holes to

stop boards from spling.

NEBRASKA STIFFENERS

Step 7: Using the 15mm Packer screw the door

lintel into place, using 2 x 75mm tek screws at

each end. Screwing though the stud into the

lintel.

Tip: Using the screw to predrill a hole before

aempng to screw into the lintel will make this

easier.

Above Lintel from the outside, below Lintel from

the inside.

PG 8

NEBRASKA CORNER CLASHINGS

NEBRASKA ROOF

Step 11: Posion roof trusses over the join of

the panels on the front and back walls, as

shown in the wall plan. Using 75mm framing

nails, nail the truss to the seners. Predrill the

truss as to avoid spling the mber.

Refer to Wall Plan on page 5 for correct truss locaon.

Step 12: Posion purlins on roof. (Top Purlins

100mm, boom purlins 50mm) Top purlins

should be together and boom purlins should

be against the Seners. Using 75mm framing

nails, predrill then nail purlins into top of gable

end panels and truss (2 nails per join).

Check that overhangs are even all around.

Condensaon can form on the under side of shed roof. If

building paper is required, t now. Nailing to the purlins with

the clouts provided.

Please note: The image above has one truss, this

model requires two.

Please note: The image above has one truss, this

model requires two trusses.

Step 10: Ensuring the clashing is ush at the top.

Silicone and nail corner clashings on all corners as

shown using 4 x bead nails per clashing.

Silicone both edges where the clashing meets the

weatherboards to ensure this doesn't leak.

PG 9

NEBRASKA ROOF

Step 13: Ensure shed is square, by measuring

diagonals at top corner of wall panels.

Step 14: Posion rst full sheet with rib ush with

end of purlins and top of sheet ush with the top

of the purlin.

Tack top of the sheet into the top purlin using a

30mm clout through the pan. Using a 35mm

Roong Screw with Washer, screw through the

rst full rib into the boom purlin to a depth of

approximately 10mm.

Tip: Predrilling with a 3mm drill bit may make this easier.

First full Rib

Pan

Step 15: Lay out remaining full roof sheets, with

sucient overlap that the last lip lines up with

the opposite ends purlins.

This may require overlapping mulple ribs.

Rivet these sheets together, 3 rivets per join, to

make 1 large roof panel as shown in photo.

Rivet top, middle and boom.

Tack remaining top corner and screw the boom

corner ensuring edge of sheet is ush with end of

purlins and height is correct.

Ensure purlins are straight, Nail through every

fourth pan using 30mm clouts into the top purlin,

using 35mm roong screws with washers screw

through every fourth rib into the boom purlin.

Tip: If you have string or a long piece of mber use it as a

guide to screw on a straight line.
