Roborock S4 Max Manuale utente
Roborock S4 Max Robot Vacuum
Cleaner User Manual
Read this user manual carefully before using this product and store it properly
for future reference.
2
Safety Information
Restrictions
• This product is designed for indoor oor cleaning only, do not use it outdoors
(such as on an open-ended terrace), on any surface other than the ground
(such as a sofa), or in any commercial or industrial environment.
• Do not use this product on elevated surfaces without barriers such as the
oor of a loft, an open-ended terrace, or on top of furniture.
• Do not use the product when the ambient temperature is higher than 104°F
(40°C), lower than 39°F (4°C), or if there are liquids or tacky substances on the
oor.
• Before using the product, move wires o the ground or place them to the side
to prevent them being pulled on by the cleaner.
• To prevent blocking the product and to avoid damage to valuables, remove
lightweight items (such as plastic bags) and fragile objects (such as vases)
from the oor before cleaning.
• Children should be supervised to ensure that they do not play with the
appliance.
• This product is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
3
Safety Information
use of the product by a person responsible for their safety (CB).
• This product can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the product in a safe way and understand the hazards
involved. Children shall not play with the product. Cleaning and user
maintenance shall not be made by children without supervision (EU).
• Keep the main brush cleaning tools out of reach of children.
• Do not place any object (including children and pets) on the product, whether
it is in operation or not.
• Keep hair, loose clothing, ngers, and all parts of the body away from
openings and moving parts.
• Do not use the product on burning objects (such as cigarette butts).
• Do not use the product on high pile carpets (product eectiveness may also
be reduced on dark carpets).
• Do not use the product to clean hard or sharp objects (such as decoration
wastes, glass and nails).
• Do not carry the product using the laser scanner cap, main unit cover, or
collision buer.
4
• The product must be switched o and the plug must be removed from socket
outlet before cleaning or maintaining the product.
• Do not use wet cloth or liquids for cleaning the product.
• Do not use the mopping module on carpets.
• Use the product according to the manual. Any loss or damage caused from
improper use will be borne by the user.
• This product contains batteries that are only replaceable by skilled persons.
• Do not charge non-rechargeable batteries.
• For the purposes of recharging the battery, only use the detachable supply
unit roborock CDZ11RR or CDZ12RR provided with this product.
• Do not dismantle, repair or modify the battery or charging dock.
• Keep the charging dock away from heat (such as heating vents).
• Do not wipe or clean the charging contact with wet cloth or wet hands.
• If the power cord is damaged, stop using it immediately. It must be replaced
by the manufacturer, its service agent, or similarly qualied persons to avoid a
hazard.
Safety Information
Battery and Charging
WARNING
5
• Make sure the product is powered o before shipment.
• Use of the original packaging is advised.
• If to be left unused for a long period of time, fully charge the product and
switch it o before storing it in a cool, dry place.
• Charge it at least every three months to avoid over discharging the battery.
• To satisfy RF exposure requirements, a separation distance of 20 cm or
more should be maintained between this device and persons during device
operation. To ensure compliance, operations at closer than this distance is not
recommended.
• The antenna used for this transmitter must not be co-located in conjunction
with any other antenna or transmitter.
Safety Information
6
Roborock robot vacuum cleaner troubleshooting
Name Troubleshooting
Robot
Problem listed in the User Manual
Charging dock
The product cannot be powered on
The main brush, side brush, fan, or main wheels do not work
Power cable
The robot does not receive power
The charging dock cannot be supplied with power
7
Product Introduction
Robot
Cover latch
Dock/Spot Clean
• Press to return to the dock
• Press and hold to spot clean
Note:
Press any button to pause cleaning, returning
to dock, or spot cleaning.
On/O
• Press to start cleaning
• Press and hold to power on or o
Power indicator
• White: Battery level ≥ 20%
• Red: Battery level < 20%
• Flashing slowly: Charging or starting up
• Flashing red: Error
8
Product Introduction
Parts list
Charging dock Power cable
9
Product Introduction
Dustbin Robot
Cover latch
Dustbin latch
Air lter
WiFi indicator light
• O: WiFi disabled
• Slow ashing: Waiting for
connection
• Fast ashing: Connecting
• Steady: WiFi connected
System reset
Air vent
Main brush cleaning tool
Speaker
10
Product Introduction
Robot and sensors
Recharge sensor
Wall sensor
Cli sensor
Omnidirectional
wheel
Charging contact
Side brush
Main wheels
Main brush
Main brush
cover latch
Bumper
Laser distance
sensor
Vertical Bumper
