Rocket Fish RF-UPCUWR Manuale utente

Universal CPU Cooler

RF-UPCUWR User Guide

Universal CPU Cooler

Contents

Important safety instructions ..................................3

Features............................................................................4

Package contents.................................................7

Installing the cooler.....................................................8

Installing on an LGA 775/1156 platform .....8

Installing on an AMD platform.....................11

Specifications.............................................................. 15

One-year limited warranty ..................................... 17

RF-UPCUWR

Important safety

instructions

1Read these instructions.

2Keep these instructions.

3Heed all warnings.

4Follow all instructions.

5Do not use this apparatus near water.

6Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

7Only use attachments/accessories

specified by the manufacturer.

8The cooler is designed for computer

usage only. Using the cooler in any other

application will void the warranty.

9If you are not familiar with computer

hardware installation, see a qualified

computer technician.

Features

Compatible with Intel Socket LGA

775/1156

RF-UPCUWR

Compatible with AMD Socket

754/939/940/AM2/AM

• Silent CPU cooler at only 18 dBA(at

800 rpm)

• Maximum compatible CPU wattage:

over 130 W TDP

• Three direct-contact heat-pipes with

aluminum fins to provide excellent heat

dissipation

• Option for adding second fan to

increase cooling performance

• 92 mm PWM fan with distinguished

blade shape and anti-vibration rubber

pads

• Easily swappable fan using clips

•Flexiblemountings

RF-UPCUWR

Package contents

Item Description Quantity

ACooler 1

BScrews (a) 4

CScrews (b) 8

DK8/AM2 retention plate (A) 1

EK8/AM2 retention plate (B) 1

F775/1156 retention plate (1) 2

G775/1156 retention plate (2) 1

HThermal grease 1

ABC

Installing the cooler

Installing on an LGA 775/1156 platform

To install the cooler:

1Make sure that you select the correct

retention plate for your processor. See

“Package contents” on page 7.

2Assemble the retention plate.

LGA 775 1156

RF-UPCUWR

3Remove the protective cover from the

bottom of the cooler, then apply a small

dab (about 1/2 the size of a pea) of

thermal grease on the surface of the

installed CPU. When the cooler is

clamped to the processor, the grease will

spread evenly to form a thin layer.

4Place the cooler on the CPU, then press

the push pins into place two at a time.

5Connect the fan power cable. The

following graphic is for reference only.

Refer to the documentation for your

system board for the location of the

power connector.
