Rocket Fish RF-QX3 Manuale utente

Wireless Bluetooth Headset

RF-QX3

User Guide

2RF-QX3 Wireless Bluetooth Headset

Wireless Bluetooth Headset

Contents

Important safety instructions .......................................... 3

Introduction ........................................................................... 4

Features.................................................................................... 4

Package contents ............................................................ 4

Components...................................................................... 5

Using the headset ................................................................ 6

Headset functions ...........................................................6

Charging the battery......................................................7

Turning the headset on or off .....................................7

Pairing the headset with a compatible phone .....7

Disconnecting the headset from the phone .........8

Reconnecting the headset to the phone................ 8

Making a call .....................................................................8

Answering or ending a call .......................................... 9

Rejecting a call..................................................................9

Redialing the last number dialed...............................9

Muting a call......................................................................9

Using voice dialing.......................................................... 9

Adjusting the earpiece volume .................................. 9

Switching between the headset and phone .......10

RF-QX3 Wireless Bluetooth Headset

Erasing all pairing information .................................10

Turning the indicator on or off .................................10

Checking the battery status ......................................10

Resetting the headset..................................................10

Maintaining ..........................................................................11

Troubleshooting .................................................................11

Specifications.......................................................................11

Legal notices ........................................................................12

One-year limited warranty..............................................13

Important safety instructions

1Read these instructions.

2Keep these instructions.

3Heed all warnings.

4Follow all instructions.

5Do not expose the headset to water.

6Clean only with a dry cloth.

7Do not plug in the wall charger near any heat sources such as radiators,

heat registers, stoves, or other chargers that produce heat.

8Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other. A

grounding type plug has two blades and a third grounding prong. The

wide blade or the third prong are provided for your safety. If the

provided plug does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

9Protect the power cord from being walked on or pinched particularly at

plugs, convenience receptacles, and the point where they exit from the

charger.

10 Only use attachments/accessories specified by the manufacturer.

11 Unplug this charger during lightning storms or when unused for long

periods of time.

12 Refer all servicing to qualified service personnel. Servicing is required

when the apparatus has been damaged in any way, such as

power-supply cord or plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

4RF-QX3 Wireless Bluetooth Headset

13 To reduce the risk of fire or electric shock, do not expose the charger to

rain, moisture, dripping, or splashing.

14 An apparatus with a three-prong, grounding-type plug is a Class I

apparatus, which needs to be grounded to prevent possible electric

shock. Make sure that you connect this Class I device to a

grounding-type, three-prong outlet.

15 In order to charge your headset correctly, the wall outlet must be in

correct working condition.

16 Batteries should not be exposed to excessive heat.

Caution: Danger of explosion if battery is incorrectly replaced. Replace only with the

same or equivalent type.

Introduction

Congratulations on your purchase of the RF-QX3 wireless headset.

This headset represents the state of the art in wireless headset design

and is designed for reliable and trouble-free performance.

Features

Package contents

•QX3headset

• Ear loop

• USB charging cable and A/C wall charger

• Earbuds (small, medium, and large)

•UserGuide

• Quick Setup Guide

Note: The ear loop and medium earbud come preattached.

RF-QX3 Wireless Bluetooth Headset

Components

#Component Description

1Volume down Press to decrease the earpiece volume.

2Volume up Press to increase the earpiece volume.

3Earpiece Transmits the callers voice.

Power/Send/End button • Switches the headset on and off.

• Answers incoming calls.

•Endsactivecalls.

• Rejects incoming calls.

• Activates voice dialing

6RF-QX3 Wireless Bluetooth Headset

Using the headset

Headset functions

Indicator light Power on—Lights solid yellow-green for 1 second and the headset beeps

once.

Pairing mode—Rapidly flashes yellow-green.

The flashing continues for approximately three minutes or until the headset is

connected to a compatible phone. If the headset is not connected to a phone

during this time, the headset enter connectable status.

Connectable—Flashes yellow-green once every 2.5 seconds.

Connection active—Flashes yellow-green every 5 seconds.

Incoming call—Flashes yellow-green two times every 1 second.

Active call—Flashes yellow-green every 5 seconds.

Power off—Lights solid red for 1 second and the headset beeps once.

Low battery—Alternately flashes yellow-green and red, and the headset

beeps every 300 seconds.

6Charger connector Connect the charger to this jack and to a power outlet to charge the battery.

Headset function Button presses

Voice dial Press the power/send/end button.

Redial Double-press the power/send/end button.

Answer a call Press the power/send/end button.

End (cancel) a call Press and hold the power/send/end button for two

seconds.

Reject a call Double-press the power/send/end button.

Transfer a call between connected

devices

Double-press the power/send/end button while in

a call to transfer call to handset.

Mute or unmute Press volume up and volume down buttons at the

same time.

Adjust the earpiece volume Press volume up or volume down button.

Erase all pairing information When the headset is turned off, press and hold

power/send/end and volume up buttons until the

indicator flashes red and yellow-green alternately.

Turn the indicator on or off When the headset is connected to a phone, press

and hold the power/send/end and volume up

buttons for four seconds.

Check the battery status Press and hold the power/send/end for two

seconds.

#Component Description

RF-QX3 Wireless Bluetooth Headset

Charging the battery

Before using the headset, you must charge the battery for

approximately two hours. When the battery is fully charged, it

provides up to 8 hours of talk time or up to 300 hours of standby

time.

To charge the battery:

• Connect the charger to the headset and to a power outlet. While the

battery is charging the indicator lights red. When the battery is fully

charged, the indicator lights yellow-green.

Turning the headset on or off

To turn the headset on or off:

1To turn on the headset, press and hold the power button for about two

seconds. The headset beeps and the indicator blinks yellow-green. (The

first time you turn on the headset, you have to press and hold the power

button for five seconds.)

2To turn off the headset, press and hold the power button for about four

seconds. The headset beeps and the indicator briefly lights red.

Pairing the headset with a compatible phone

Pairing is the process of linking the headset with a Bluetooth-enabled

mobile phone. After you pair the headset with a phone, you can only

use the headset with the paired phone. If you want to use the

headset with a different phone, you must repeat the pairing process

with the new phone. The headset can be paired with up to eight

compatible phones, but it can be connected to only one phone at a

time.

To pair the headset with a compatible phone:

1Make sure that the compatible phone is turned on and within 33 feet

(10 meters) of the headset.

2Turn on the headset and make sure that the battery is fully charged.

3Press and hold the power/send/end button for about four seconds. The

indicator rapidly flashes yellow-green.

4Release the button. The headset is now in pairing mode.

5Activate the Bluetooth connection from the phone. See the

documentation that came with the phone for instructions.

6Set the phone to start searching for Bluetooth devices.

8RF-QX3 Wireless Bluetooth Headset

7Select RF-QX3 from the list of found devices displayed on the phone.

8If neccessary, enter a PIN code 0000 to pair and connect the headset with

your phone. With some phones, you need to make a connection

separately after pairing.

Disconnecting the headset from the phone

To disconnect the headset from the phone:

• Turn off the headset.

Or,

• Disconnect the headset in the phone’s menu.

Or,

• Move the headset more than 33 feet (10 meters) away from the phone.

Note: You do not need to delete the pairing with the headset to disconnect the

headset. When you reconnect the headset to a phone it has be paired with, you do

not have to enter the code 0000 again.

Reconnecting the headset to the phone

Note: The headset connects to the last connected phone by default. If the last phone is

out of the Bluetooth operating range or you are not using the last phone, the headset

searches and connects to the other paired phones.

To reconnect the headset to the last phone used:

• If the headset is turned off, turn it on. It automatically connects to the

phone.

Note: If the headset is out of Bluetooth operating range (33 feet/10 meters) for less

than two minutes, the headset sounds a warning tone and the indicator flashes

yellow-green every 2.5 seconds. If you move the headset back into operating range, it

automatically reconnects with the phone.

If the headset is out of Bluetooth operating range for more than two minutes, go

back into range then press and hold the power/send/end button until a beep sounds

to indicate the connection is reactivated.

Making a call

To make a call:

• Use the phone in the normal way. See the phone’s documentation for

instructions.

RF-QX3 Wireless Bluetooth Headset

Answering or ending a call

When you receive a call, you hear a ringing tone through the headset.

To answer or end a call:

• Press the power/send/end button to answer a call.

• Press and hold the power/send/end button for two seconds to end a call.

Note: Some phones have an Auto Answer function. If the phone has this function, you

can use it with the headset.

Rejecting a call

To reject a call:

• Double-press the power/send/end button.

Redialing the last number dialed

To redial the last number dialed:

• While no call is in progress, double-press the power/send/end button.

Muting a call

To mute a call:

• Briefly press the volume up and volume down buttons at the same time.

Press the volume up and volume down buttons again to unmute the call.

Using voice dialing

If the paired phone has a voice dialing feature, you can use it with the

headset.

To use voice dialing:

• When no call is in progress, press the power/send/end button. A tone

indicates that you can start saying the voice tag. The phone plays the

voice tag and dials the related phone number.

Adjusting the earpiece volume

To adjust the earpiece volume:

• Press the volume up or volume down button.

10 RF-QX3 Wireless Bluetooth Headset

Switching between the headset and phone

• While a call is in progress, double-press the power/send/end button or

use the switching function on the phone.

Erasing all pairing information

To erase all pairing information:

1Turn off the headset.

2At the same time, press and hold the power/send/end and volume up

buttons until the indicator flashes. After erasing all pairing information,

the headset enters pairing mode automatically.

Turning the indicator on or off

You can turn the indicator on or off when the headset is connected to

a phone or during a call.

To turn the indicator on or off:

• At the same time, press the power/send/end button and the volume up

button for about four seconds. The indicator turns off. Repeat this step to

turn the indicator back on.

Checking the battery status

When the headset is paired and connected to a phone, press and

hold the power/send/end button for about two seconds.

• If the indicator flashes once yellow-green, the battery level is over half of

battery capacity.

• If the indicator flashes once yellow-green and red, the battery level is less

than half, but has more than one hour of talk time.

• If the indicator flashes once red, the battery level has less than one hour

talk time.

Resetting the headset

To reset the headset:

• Connect the charger. The headset is turned off and reset.

Note: You should only use the reset function when the headset operates unusually.

When you reset the headset, pairing information is not erased.

Altri manuali per RF-QX3

Indice

Altri manuali Rocket Fish Cuffia

Rocket Fish

Rocket Fish RF-MAB2 Manuale utente

Rocket Fish

Rocket Fish RF-GPS31104 Manuale utente

Rocket Fish

Rocket Fish RF-GPS31201 Manuale utente

Rocket Fish

Rocket Fish RF-GPS31104 Manuale utente

Rocket Fish

Rocket Fish RF-BTHP02 Manuale utente

Rocket Fish

Rocket Fish RF-CNA3 Manuale utente

Rocket Fish

Rocket Fish RF-SH230 Manuale utente

Rocket Fish

Rocket Fish RF-BTHP01 Manuale utente

Rocket Fish

Rocket Fish RF-BTHP02 Guida rapida

Rocket Fish

Rocket Fish RF-QX5 Manuale utente

Rocket Fish

Rocket Fish RF-GUV1202 Manuale utente

Rocket Fish

Rocket Fish RF-GPS3007 Manuale utente

Rocket Fish

Rocket Fish RF-GPS31126 Manuale elenco delle parti

Rocket Fish

Rocket Fish RF-BTHP02 Manuale elenco delle parti

Rocket Fish

Rocket Fish RF-QX4-E Manuale utente

Rocket Fish

Rocket Fish RE-GUV1202 Manuale utente

Rocket Fish

Rocket Fish RF-GPS31126 Manuale di installazione e funzionamento

Rocket Fish

Rocket Fish RF-QX3 Manuale elenco delle parti

Rocket Fish

Rocket Fish RF-GUV1202 Manuale utente

Rocket Fish

Rocket Fish RF-QX4-T Manuale utente

Rocket Fish

Rocket Fish RF-GUV1202 Guida rapida

Rocket Fish

Rocket Fish RF-GPS31204 Manuale utente

Rocket Fish

Rocket Fish RF-QX3 Guida rapida

Rocket Fish

Rocket Fish RF-PH4101 Manuale elenco delle parti

Manuali Cuffia popolari di altre marche

Sena

Sena SMH10 Manuale utente

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manuale utente

Sennheiser

Sennheiser EPOS ADAPT 230 Manuale utente

Doro

Doro Flexus HS2005 Manuale utente

GE 98971 Manuale utente

Hama

Hama 00184070 Manuale utente

Plantronics

Plantronics Blackwire 3200 Series Manuale utente

Blue Tiger

Blue Tiger Advantage PLUS Manuale utente

Jawbone

Jawbone Icon Manuale utente

Jabra

Jabra FR 20 Manuale utente

Roxcore

Roxcore Flow A+ Manuale utente

Turtle Beach

Turtle Beach XP 510 Manuale utente

Philips

Philips SHB6101 Manuale utente

Jabra

Jabra PRO 9460 Duo Manuale utente

HyperX

HyperX HyperX Cloud Flight Manuale utente

Bose

Bose MIE2 Mobile Manuale utente

Jabra

Jabra Steel Manuale utente

HyperX

HyperX cloud ii Manuale utente
