Front Panel Features
INPUT JACK 1 - (CH1) using a standard 1/4” cable, plug your guitar or bass in here. This Jack pro-
videstheoutputtoOUTPUTJACK1onthebackpanel.SeetheOUTPUTJACK1descriptioninthe
“Rear Panel Features” on the following pages for more details.
INPUT JACK 2- (CH2) using a standard 1/4” cable, plug your guitar or bass in here. This Jack pro-
videstheoutputtoOUTPUTJACK2onthebackpanel.SeetheOUTPUTJACK2descriptioninthe
“Rear Panel Features” on the following pages for more details.
NOTE: The VersaTune has two inputs and outputs so that you can plug two different
instrumentsintoitatthesametime,yetgototwodifferentampliers.
INPUT SELECTOR BUTTON & LEDS - use this selector switch to determine which input will be
“active.” Note that when you select Input 1 (CH1 LED will be “lit”) Output Jack 1 on the back panel
will be active as well thus sending the signal to whatever is plugged into Output Jack 1. When you
select Input 2 (CH2 LED will be “lit”) Output Jack 2 on the back panel will be active as well thus send-
ing the signal to whatever is plugged into Output Jack 2. Note that it is not possible to send the Input 1
to Output 2 or the Input 2 to Output 1.
PRECISION BUTTON & LED - For Ultra Fine tuning use the Precision Button. This button in-
creases the sensitivity of the tuner to allow you to “FINE” tune your instrument. To enter “PRECI-
SION MODEL” press the Precision Button. In “PRECISION MODE” the LED colors change so now
the “IN TUNE” or (0) LED will now be RED and the out of tune LEDs will be GREEN. Please see the
section “USING THE VERSATUNE” for more details on this function.
STROBE BUTTON - To turn ON or OFF “strobe” tuning press this button. To learn how to use the
“strobe” function, see section called “STROBE TUNING” later in this manual.
NOTE BUTTON-Thisbuttonallowsyoutoselectaspecicnotetotune.Thisisanidealfunction
when using the tuner to intonate an instrument. Press the button once and the NOTE DISPLAY WIN-
DOWwillshow“0”(Zero).ThiswillshowthattheVersaTuneisinstandardtuningmode.Totune
onlyaspecicnotepresstheNOTEbuttonagain,theNOTEDISPLAYWINDOWwillshow“A”.
Pressing the button several more times will scroll through the notes A#, B, C, C#, D, D#, E, F, F#, G,
G# and then back to “0”. At any time you can “PRESS AND HOLD” the NOTE Button to return to
“0” which is the standard tuning mode.
CALIBRATION BUTTON - This button is used to calibrate the tuner to match a relative pitch of any
instrument or audio source (like an old piano or tape player). For details on this function - see section
titled “Calibration.”
