Rocsecure ROCBIT 2A Manuale utente

secure your future

ROCBIT 2

USB

FIREWIRE 400 & USB

FIREWIRE 800 & USB

ENCRYPTED MOBILE HARD DRIVES

division of www.ROCSTOR.com

ROCBIT 2

INTRODUCTION:

The Rocsecure Rocbit 2 external pocket mobile hard

drives are industry’s most versatile, real-time hardware

encrypted storage solution available. Rocbit 2 USB2.0

and FireWire Combo interface drives offer security-

sensitive users a wide range of NIST certified DES (Data

Encryption Standard) and TDES (Triple DES) encrypted

algorithms. Rocbit 2.5” ultra-slim drives are designed

with DES/TDES 40/64/128 or 192-bit real-time hardware

data encryption security performance which effectively

intercept, interpret, translate and relay IDE data

commands to and from disk drives in “real-time”.

Rocsecure drives offer the technologies you need to keep

you data secure and safe.

KEY FEATUES:

•Delivers “Real-Time” performance over software

encryption

•Secured with DES/TDES, 40/64/128 or 192 bit

HARDWARE encryption

•Keeps data-at-rest confidential by preventing

unauthorized access

•Anti-shock protection enclosures

•Delivers significant performance improvement over

software encryption

•Eliminates platform dependency

•Minimizes total cost of ownership (TCO)

•Requires no additional training

FEATURES:

•Supports Hi-Speed USB data transfer speed of up to

480Mbps, and IEEE 1394a data transfer speed of

up to 400Mbps.

•USB Mass Storage Class offers driverless in Windows

XP, 2000, and ME.

•Easy to connect by plug-n-play.

•Combines enclosure and 1394 repeater functionality.

•Maximizes thermal protection with Aluminum

construction.

•Provides robust HDD fixing mechanism to reduce risk

of HDD damage during movement.

•Prevents drop damage to HDD with anti-shock design.

•Supports DES/TDES 40-bit*hardware encryption

security

*The standard shipment is with encryption of DES/TDES 40-bit key strength.

The designs with 64/128/192-bit encryptions are available by request.

What is Encryption?

Data encryption is a process used to hide the true

meaning of data. The word "encryption' has been coined

from the word "cryptography" which was derived from the

ancient Greek words "kryptos" (hidden) and "graphia"

(writing). Encryption is the sophisticated mathematical

calculation (or algorithm) process of transforming text or

data into an unintelligible form called cipher. Reversing

the process of encryption and transforming the cipher

back into its original form is called decryption.

Encryption and decryption comprise the science of

cryptography as it is applied to the modern computer.

What is an Encrypted Hard Drive Enclosure?

Rocbit Encrypted HD enclosures provide Enova X-Wall®

real-time hardware-based encryption. Every bit and byte

on the hard drive is strongly encrypted by DES (Data

Encryption Standard) or TDES (Triple DES) algorithms.

There is no possibility that clear text will remain on the

hard drive.

What is the Secure Key and Why Use It?

The Secure Key is a physical digital key that contains the

“Secret Key” (number) necessary for encryption and

decryption operations. The hard drive must be partitioned

and formatted using the Secure Key, the first time the

hard drive is used. When complete the entire content of

the hard drive is associated with the unique Secure Key.

Only a Secure Key containing the identical “Secret Key”

can be used for authentication and decryption of the hard

drive at power up.

Will Encryption Degrade Performance?

Rocbit encrypted hard drives provide Real-Time and

automatic TRANSPARENT ENCRIPTION without

performance degradation through the built-in X-Wall®

microchip (encryption chipset), which operates at 1.6

Gbit/sec.

What about Compatibility Issues?

Rocbit encrypted hard drives are compatible with every

operating system found today. However, a host controller

with a USB/1394 mass storage driver typically provided

by the OS is required.

How do Rugged Rocbit Designs help protect your Hard

Drive?

In addition to strong real-time encryption and the Secure

Key, the safety-centric mechanical designs of Rocbit

external hard drives provide critical hardware protection.

Features including:

•Secure Fixing Mechanism of hard drive

•Anti-Shock Protection

•Enhanced Durability

•Thermal Protection and Loan-Bearing rugged

aluminum Case

•Error-proof Secure Key Design

SPECIFICATIONS:

Transfer Rate: (FireWire uses Oxford Chipset)

FireWire 800 Up to 800 Mbps

FireWire 400 (Std) Up to 400 Mbps

USB 2 (1.1) Up to 480 Mbps

Data Speeds

•USB 2.0 port: 12Mb/480Mbps

•IEEE 1394 (FireWire) ports: 100/200/400 Mbps

Connector

Rocbit 2B:

•9-pin FireWire, IEEE 1394b connector x 2

•6-pin USB 2 (1.1) x 1

•One Secure key receptacle in 6-pin 1394a form

Rocbit 2A:

•6-pin FireWire, IEEE 1394a connector x 2

•6-pin USB 2 (1.1) x 1

•One Secure key receptacle in 6-pin 1394a form

Rocbit 2U:

•6-pin USB 2 (1.1) x 1

•One Secure key receptacle in 6-pin 1394a form.

Power Supply

•AC Adapter 5V/2A or 1394 Bus Power

AC Input

•110V ~240V full range

Dimension of Enclosure

5” (L) x 3” (W) x 0.8” (H)

12.9 cm (L) x 8 cm (W) x 2.1 cm (H)

Weight

0.6 Lb, 9.2 Oz

Certification

FCC/CE

PLEASE READ THOROUGHLY AND FOLLOW

THE INSTRUCTIONS PROVIDED IN THIS

MANUAL.FAILURE TO DO SO MAY RESULT IN

DAMAGE TO THE HARD DRIVE ENCLOUSURE

AND ANY OR ALL OF THE CONNECTED

DEVICES.

ROCBIT 3 CONTAINS ONLY TWO DIGITAL

SECURITY KEYS; ROCSTOR/ROCSECURE DOES

NOT KEEP ANY RECORD OF SUCH KEYS OR

PASSWORDS. AT YOUR DISCRETION YOU MAY

KEEP ONE KEY IN A SAFE PLACE.

PLEASE BE SURE TO REMEMBER AND/OR

RECORD YOUR PASSWORD IN A SAFE PLACE.

UNFORTUNATLY ROCSTOR/ROCSECURE CAN

NOT REPLCE OR REPAIR PRODUCT OR REPAIR

PRODUCTS WHICH HAVE BECOME

INOPERABLE OR INACCESSABLE DUE TO LOSS

OF PASSWORD OR THE SECURITY KEYS.

THANK YOU.

Before Installation

You will be required to partition and format the new hard

drive before use. Always perform partition and format

functions with the secure key plugged in; otherwise the

hard drive cannot be encrypted. After formatting the hard

drive the secure key can be safely removed and the

enclosure will operate normally. Performing partition and

format operations will erase all the data on the disk.

ROCSTOR (ROCSECURE) IS NOT RESPONSIBLE FOR

ANY LOST DATA.

After Installation

1) Since the IEEE 1394 bus powers the IEEE 1394(b)/

USB 2.0 enclosure; the secure key must be inserted

before the IEEE 1394(b) connector. If the secure key is

not inserted first, the host computer may not recognize

the enclosure.

Similarly, the secure key must first be inserted in the

encrypted USB 2.0 enclosure with USB Y-cable.

2) Plug in the secure key every time you connect the

HDD enclosure to the host.

You may remove the secure key after the host computer

has detected the Rocbit 2.

3) Always keep the secure key with you. You will be

required to insert the secure key when you power on your

Rocbit encrypted Hard Drive enclosure. Without the same

secure key, the host is not able to detect the Rocbit hard

drive when powered on. Once you have accessed your

hard drive the secure key may be removed. The hard

drive can then be accessed without the secure key as

long as the Rocbit encrypted hard drive is powered on.

4) The host cannot access the HDD when the enclosure

LED indicator is red. A red LED indicator means no key is

inserted. If the LED indicator is red you must completely

power off the encrypted enclosure, insert the secure key,

then power on the enclosure again.

Getting Started

The installation instructions in this manual apply to the

following models. Please review the package contents for

each model:

Rocbit 2, USB 2.0 Mobile Hard Drive w/Security

Package Contents

• Enclosure x 1

• USB Y-cable x 1

• Quick Start Guide

• Secure key x 2

• AC Power Adapter x1

(Optional)

Rocbit 2, FireWire 400 and USB 2.0 HD w/Security

Package Contents

• Enclosure x

• USB-A to mini B cable x 1

• IEEE 1394 cable x 1

• Quick Start Guide

• Secure key x 2 (or 3)

• AC Power Adapter x 1

Rocbit 2, FireWire 800 and USB 2.0 HD w/Security

Package Contents

• Enclosure x 1

• USB-A to mini B cable x 1

• IEEE 1394b cable x 1

• Quick Start Guide

• Secure key x 2

• AC Power Adapter x 1

SYSTEM REQUIREMENTS:

•266MHz or faster CPU

•64MB of RAM

•Microsoft Windows 98SE, ME, 2000, XP

•One available USB port and/or IEEE 1394(b) port

depending on the model

Macintosh

•Macintosh PowerPC processor

•Mac OS** 9.4 or newer

•One available USB port and/or IEEE 1394(b) port

** Mac OS:

•Installation of the Rocbit 2 via USB 2.0 requires

Mac OS X 10.1.5/10.2.X with USB 2.0 driver

installed, or Mac OS 10.2.8 or newer. Mac OS 9.X

supports full speed USB only. Operation of the

Rocbit 2 via FireWire 800 (1394b) requires Mac

OS X 10.2.4 or newer.

•Operation of Rocbit 2 via FireWire 800 (1394b)

requires Mac OS X 10.2.4 or newer to support

FireWire 800 speed.

Encrypted Models

1) Insert the secure key into the security key port

indicated by the secure key icon “ “ on the rear

panel of the Enclosure Kit. As the shape of the security

key port is very similar to the shape of the IEEE 1394

port, ensure that the secure key is inserted only into the

security key port. Incorrect insertion into a port other

than the designated security key port may result in

damage to the secure key or other ports/equipment.

2) Connect the AC/DC power adapter; ensure that the

green LED indicator is active. The orange LED indicator

will blink during data transfer.

3) Insert one end of the USB or IEEE 1394(b) connector

into a corresponding port on the enclosure.

4) Insert the USB or IEEE 1394(b) connector into an

available port on the computer.

Note: If the LED indicator is red, security is not enabled.

Ensure that the secure key is inserted before power on,

and the enclosure is properly connected.

Using the USB Y-cable:

The USB Y-cable provides 2 USB type-A connectors and

1 USB mini-B connector. The 2 USB type-A connectors

are inserted into two available USB ports on the

computer. The USB Y-cable serves as both power supply

and data transfer cable. The cable with square type-A

connector supplies power and transfers data between the

enclosure and the host computer. The remaining type-A

connector provides additional power from the host

computer to the enclosure. The remaining USB mini-B

connector is inserted into the port on the rear panel of

the enclosure.

square type-A connector of the USB Y-cable into the host.

This will enable data transfer between the enclosure and

the computer. The remaining USB type-A connector will

be idle.

Do NOT insert the remaining type-A connector into the

host.

Notices and Classifications

FCC-B Radio Frequency Interference Statement

This device complies with part 15 of the FCC rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received,

including interference that may cause undesired

operation.

Note: This equipment has been tested and found to

comply with the limits for a class B digital device,

pursuant to part 15 of the FCC rules. These limits are

designed to provide reasonable protection against

harmful interference when the equipment is operated in

a commercial environment. This equipment generates

uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction

manual, may cause harmful interference to radio

communications.

ROCSTOR ”ROCSECURE” PRODUCTS

WARRANTY AND TECHNICAL SUPPORT

INFORMATION

General Terms

EXCEPT AS EXPRESSLY SET FORTH IN THIS LIMITED WARRANTY,

ROCSTOR MAKES NO OTHER WARRANTIES OR CONDITIONS, EXPRESS

OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

ROCSTOR EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS

NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED WARRANTIES

THAT MAY BE IMPOSED BY LAW ARE LIMITED IN DURATION TO THE

LIMITED WARRANTY PERIOD. SOME STATES OR COUNTRIES DO NOT

ALLOW A LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS OR

THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL

DAMAGES FOR CONSUMER PRODUCTS. IN SUCH STATES OR

COUNTRIES, SOME EXCLUSIONS OR LIMITATIONS OF THIS LIMITED

WARRANTY MAY NOT APPLY TO YOU.

This Limited Warranty applies to the Rocstor branded hardware products

sold by or leased from Rocstor Storage, Inc., its worldwide subsidiaries,

affiliates, authorized resellers, or country distributors (collectively referred to

in this Limited Warranty as "Rocstor") with this Limited Warranty. This

Limited Warranty is applicable in all countries and may be enforced in any

country where Rocstor or its authorized service providers offer warranty

service subject to the terms and conditions set forth in this Limited Warranty.

However, warranty service availability and response times may vary from

country to country and may also be subject to registration requirements in

the country of purchase.

Rocstor warrants that the Rocstor hardware product and all the internal

components of the product that you have purchased or leased from Rocstor

are free from defects in materials or workmanship under normal use during

the Limited Warranty Period. The Limited Warranty Period starts on the date

of purchase or lease from Rocstor. Your dated sales or delivery receipt,

showing the date of purchase or lease of the product, is your proof of the

purchase or lease date. You may be required to provide proof of purchase or

lease as a condition of receiving warranty service. You are entitled to

warranty service according to the terms and conditions of this document if a

repair to your Rocstor branded hardware is required within the Limited

Warranty Period. This Limited Warranty extends only to the original

purchaser or lessee of this Rocstor branded product and is not transferable

to anyone who obtains ownership of the Rocstor branded product from the

original purchaser or lessee.

Rocstor products are manufactured using new materials or new and used

materials equivalent to new in performance and reliability. Spare parts may

be new or equivalent to new. Spare parts are warranted to be free from

defects in material or workmanship for thirty (30) days or for the remainder

of the Limited Warranty Period of the Rocstor hardware product in which

they are installed, whichever is longer.

During the Limited Warranty Period, Rocstor will repair or replace the

defective component parts or the hardware product. All component parts or

hardware products removed under this Limited Warranty become the

property of Rocstor. The replacement part or product takes on either the

Limited Warranty status of the removed part or product or the thirty (30) day

limited warranty of the spare part. In the unlikely event that your Rocstor

product has a recurring failure, Rocstor, at its discretion, may elect to

provide you with a replacement unit of Rocstor's choosing that is at least

equivalent to your Rocstor branded product in hardware performance.

Rocstor reserves the right to elect, at its sole discretion, to give you a refund

of your purchase price or lease payments (less interest) instead of a

replacement. This is your exclusive remedy for defective products.

YOU SHOULD MAKE PERIODIC BACKUP COPIES OF THE DATA

STORED ON YOUR HARD DRIVE OR OTHER STORAGE DEVICES AS A

PRECAUTION AGAINST POSSIBLE FAILURES, ALTERATION, OR

LOSS OF THE DATA. BEFORE RETURNING ANY UNIT FOR SERVICE,

BE SURE TO BACK UP DATA AND REMOVE ANY CONFIDENTIAL,

PROPRIETARY, OR PERSONAL INFORMATION. ROCSTOR IS NOT

RESPONSIBLE FOR DAMAGE TO OR LOSS OF ANY PROGRAMS, DATA,

OR REMOVABLE STORAGE MEDIA. ROCSTOR IS NOT RESPONSIBLE

FOR THE RESTORATION OR REINSTALLATION OF ANY PROGRAMS

OR DATA OTHER THAN SOFTWARE INSTALLED BY ROCSTOR WHEN

THE PRODUCT IS MANUFACTURED.

Rocstor does not warrant that the operation of this product will be

uninterrupted or error-free. Rocstor is not responsible for damage that occurs

as a result of your failure to follow the instructions that came with the

Rocstor branded product.

This Limited Warranty does not apply to expendable parts. This Limited

Warranty does not extend to any product from which the serial number

has been removed or that has been damaged or rendered defective (a)

as a result of accident, misuse, abuse, or other external causes; (b) by

operation outside the usage parameters stated in the user

documentation that shipped with the product; (c) by the use of parts

not manufactured or sold by Rocstor; or (d) by modification or service

by anyone other than (i) Rocstor, (ii) a Rocstor authorized service

provider, or (iii) your own installation of end-user replaceable Rocstor or

Rocstor approved parts if available for your product in the servicing

country.

These terms and conditions constitute the complete and exclusive warranty

agreement between you and Rocstor regarding the Rocstor branded product

you have purchased or leased. These terms and conditions supersede any

prior agreements or representations-including representations made in

Rocstor sales literature or advice given to you by Rocstor or an agent or

employee of Rocstor-that may have been made in connection with your

purchase or lease of the Rocstor branded product. No change to the

conditions of this Limited Warranty is valid unless it is made in writing and

signed by an authorized representative of Rocstor.

Limitation of Liability

IF YOUR ROCSTOR BRANDED HARDWARE PRODUCT FAILS TO WORK AS

WARRANTED ABOVE, YOUR SOLE AND EXCLUSIVE REMEDY SHALL BE

REPAIR OR REPLACEMENT. ROCSTOR'S MAXIMUM LIABILITY UNDER

THIS LIMITED WARRANTY IS EXPRESSLY LIMITED TO THE LESSER OF

THE PRICE YOU HAVE PAID FOR THE PRODUCT OR THE COST OF

REPAIR OR REPLACEMENT OF ANY HARDWARE COMPONENTS THAT

MALFUNCTION IN CONDITIONS OF NORMAL USE.

ROCSTOR IS NOT LIABLE FOR ANY DAMAGES CAUSED BY THE PRODUCT

OR THE FAILURE OF THE PRODUCT TO PERFORM, INCLUDING ANY

LOST PROFITS OR SAVINGS OR SPECIAL, INCIDENTAL, OR

CONSEQUENTIAL DAMAGES. ROCSTOR IS NOT LIABLE FOR ANY CLAIM

MADE BY A THIRD PARTY OR MADE BY YOU FOR A THIRD PARTY.

THIS LIMITATION OF LIABILITY APPLIES WHETHER DAMAGES ARE

SOUGHT, OR A CLAIM MADE, UNDER THIS LIMITED WARRANTY OR AS A

TORT CLAIM (INCLUDING NEGLIGENCE AND STRICT PRODUCT

LIABILITY), A CONTRACT CLAIM, OR ANY OTHER CLAIM. THIS

LIMITATION OF LIABILITY CANNOT BE WAIVED OR AMENDED BY ANY

PERSON. THIS LIMITATION OF LIABILITY WILL BE EFFECTIVE EVEN IF

YOU HAVE ADVISED ROCSTOR OR AN AUTHORIZED REPRESENTATIVE

OF ROCSTOR OF THE POSSIBILITY OF ANY SUCH DAMAGES.

THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL

RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT

MAY VARY FROM STATE TO STATE OR FROM

COUNTRY TO COUNTRY. YOU ARE ADVISED TO

CONSULT APPLICABLE STATE OR COUNTRY LAWS

FOR A FULL DETERMINATION OF YOUR RIGHTS.

Options and Software

The Limited Warranty terms and conditions for Rocstor options are as

indicated in the Limited Warranty applicable to Rocstor options. ROCSTOR

DOES NOT WARRANT SOFTWARE PRODUCTS, INCLUDING ANY

SOFTWARE PRODUCTS OR THE OPERATING SYSTEM PREINSTALLED BY

ROCSTOR. Rocstor's only obligations with respect to software distributed by

Rocstor under the Rocstor brand name are set forth in the applicable end-

user license or program license agreement. Non-Rocstor hardware and

software products are provided "AS IS." However, non-Rocstor manufacturers,

suppliers, or publishers may provide their own warranties directly to you.

Software Technical Support

Software technical support is defined as assistance with questions and

issues about the software that was either preinstalled by Rocstor on the

Rocstor branded product or that was included with the Rocstor branded

product at the time of your purchase or lease of the product. Technical

support for software is available for the first ninety (90) days from date of

product purchase or lease. Your dated sales or delivery receipt, showing the

date of purchase or lease of the product, is your proof of the purchase or

lease date. You may be required to provide proof of purchase or lease as a

condition of receiving software technical support. After the first ninety (90)

days, technical support for software that was either preinstalled by Rocstor

on the Rocstor branded product or included with the Rocstor branded

product at the time of your purchase or lease of the product is available for a

fee.

Warranty Period

Warranty Period for Rocport FireWire/USB Hard Drives are 1 Year Parts

and Labor.

Types of Warranty Service

Your Rocstor Limited Warranty consists of repair or replacement of defective

parts, including hard drives identified by Rocstor Support Organization as

"pre-failure."

Carry-in Warranty Service Available Monday - Friday

Under the terms of carry-in service, you may be required to deliver your

Rocstor product to Rocstor Service Center or an authorized service location

for warranty repair. You must prepay any shipping charges, taxes, or duties

associated with transportation of the product. In addition, you are

responsible for insuring any product shipped or returned. You assume risk of

loss during shipping.

Rocstor Replaceable Parts Program

Where available, the Rocstor Replaceable Parts program ships approved

replacement parts directly to you to fulfill your warranty. This will save

considerable repair time. After you call the Rocstor Technical Support

Center at 1.818.449.2000, a replaceable part can be sent directly to you.

Once the part arrives, call the Rocstor Technical Support Center. A

technician will assist you over the phone to ensure that the installation is

quick and easy.

Service Upgrades

Rocstor offers extra coverage for your product. For information on service

upgrades, refer to www.rocstor.com.

Service upgrades purchased in one country are NOT

transferable to another country.

Notes:

Contacting Rocstor

In the United States, refer to the Rocstor website at

www.rocstor.com.

1.818.449.2000

Toll-free technical support in the United States and Canada,

5 days a week, 9:00 a.m. to 6:00 p.m. Pacific Standard Time

Be sure to have the following information available before

you call Rocstor:

- Product serial number, model name, and model number

- Applicable error messages

- Add-on options

- Operating system

- Third-party hardware or software

309D-v1

Rocstor is a registered trademark and Rocbit is a trademark of

Rocstorage, Inc. All other names are trademarks of their respective

companies.

Mac is a trademark of Apple Computer, Inc., registered in the U.S. and

other countries. Mac and Mac logo are trademarks of Apple Computers,

Inc. registered in the U.S. and other countries.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Rocsecure Magazzinaggio

Rocsecure

Rocsecure ROCSAFE Manuale utente

Manuali Magazzinaggio popolari di altre marche

QNAP

QNAP TS 32PXU Series Manuale utente

LaCie

LaCie RUGGED RAID Manuale utente

Freecom

Freecom CLS DOCK Manuale utente

PNY

PNY Attache P-FD64MBATT3 Manuale utente

HP StorageWorks MSL2024 Manuale utente

OLT

OLT 6x6 Maximizer Manuale utente

Transcend

Transcend JetFlash 160 Manuale utente

LaCie

LaCie RUGGED MINI Manuale utente

Thunderbolt

Thunderbolt 600 Manuale utente

Panasonic

Panasonic LB-DH8 series Manuale

Intel

Intel RAID High Availability Manuale utente

LaCie

LaCie 12big Thunderbolt 3 Manuale utente

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuale utente

Panasonic

Panasonic LKM-F931-1 Manuale utente

Tabernus

Tabernus Enterprise Erase E2400 Manuale utente

Rocstor

Rocstor COMMANDER 3F series Manuale utente

HP P9000 Manuale utente

Western Digital

Western Digital Ultrastar Data60 Manuale utente
