SUPER ELF S3 –Dornier
1. GENERAL INFORMATION
Super Elf S3 description
SUPER ELF S3 is a Weft Feeder with yarn separation and direct CAN-bus communication
with the Loom Control. The new Permanent Magnet motor and the Reserve sensor allow very
fast reaction and accurate yarn storage control on the spool body. The new Reflective type
optical sensors guarantee robustness and best performances in dust environments and with
very fine yarns.
Super Elf S3 - Technical Data
Power supply by means of the specific Roj Control Box: 100 V dc –24 V dc
Weft feeding speed (pattern in advance info): max 2400 m/min
Threading channel: 4.5 mm
Yarn count range: 6 Nm - 10 dTex
Noise level: < 70 dB A
Weight: 8 kg
Working temperature: from 10 ° to 40 °C
Storage temperature: from –25 ° to +65 °C
Relative humidity: max 95% (not condensed)
Pulsar HP brake description
The Pulsar HP device, performs the following two functions:
Breaking function: to reduce the tension pick to the weft when the same is stopped by the
Electromagnet pin. This is to avoid the following problems:
a. weft breakage at the end of the insertion
b. weft loops or slack picks in the fabric.
Pull back function: after the yarn cutting, yarn is pulled back into the nozzle.
This is to avoid that the weft gets tangled in the next weft to be inserted by the
contiguous nozzle.
Technical data of Pulsar HP
Cycles per minute: 1.200
Reaction time: 7 ms
Max torque: 11.5 Ncm
Weft pull back length: max 35 mm
Eyelet's diameter: 6 mm
Other information about Super Elf S3
The Part Number (P/N) and the Serial Number (S/N) are printed on the CE label.
