Ronda Startech 5030.D Manuale utente

Cal. 5030.D

User’s Manual

– Brief specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

– Description of the display and control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

– Setting the time / date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18–21

– Operation of the chronograph . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22–27

In case your watch needs to be repaired or to raise claims

under a guarantee, please contact the point of sales

Description of the display and control buttons

Display elements

Second hand

Minute hand

Hour hand

Centre stop-second

Minute counter

Hour counter

Date

Control buttons

Push button A

Crown

Push button B

Cal. 5030.D

Brief specifications

Time/Date

• Hour hand

• Minute hand

• Small second hand (position 3h)

• Date (position 4h)

Chronograph

• Hour counter up to 12 hours (position 6h)

• Minute counter up to 30 minutes (position 9h)

• Centre stop-second

General

• Battery type: 395 (diameter 9.5mm x 2.6mm / SR 927 SW)

• Accuracy: +20 / -10 seconds per month

III

Setting the date (quick mode)



Pull out the crown to position

(the watch

continues to run).



Turn the crown until the correct

date appears.



Push the crown back into position

Please note:

During the date changing phase between

9 PM and 12 PM; the date must be set to the

date of the following day.





I II III

Setting the time



*Pull out the crown to position

III

(the watch stops).



Turn the crown until you reach the correct

time

8:45



*Push the crown back into position

Please note:

* In order to set the time to the exact second,



must be pulled out when the second hand

is in position «60» (I).

Once the hour and minute hands have been

set,



must be pushed back into position I at

the exact second.

Second hand





I II III



**Pull out the crown to position

III

(the watch stops).



**Turn the crown until the correct date

appears.



**Continue to turn the crown until the

correct time 8:30 PM appears.



**Push the crown back into position

Please note:

**To set your watch to the exact second,

please refer to the chapter entitled «setting

the time».

**Please observe the AM/PM clock rhythm.

Second hand











III

Setting the date/time

following a battery change

Example:

– Date / time on the watch: / 1:25 AM

– Present date / time: / 8:30 PM



Pull out the crown to position

(the watch continues to run).



Turn the crown until yesterday’s date

appears .

Crown

Date





Chronograph: Basic function

(Start / Stop / Reset)

Example:

Start:

Press push-button

Stop:

to stop the timing, press push-

button A once more and read the three

chronograph hands:

20min

10 sec.

Zero positioning:

Press push-button

(The three chronograph hands will be reset

to their zero positions).



Push-button A

Push-button B



Chronograph:

• The chronograph’s hour counter measures times up to 12 hours.

• The minute counter measures 30 minutes per rotation.

• The center stop-second measures 60 seconds per rotation..

Display elements

Centre stop-second

Minute counter

Hour counter

Control buttons

Push-button A

(Start / Stop)

Push-button B

(Reset)

Please note:

Before using the chronograph functions, please ensure that:



the crown is in

position I

(= normal position).



the 3 chronograph hands are precisely at zero position following activation of

push-button B

Should this not be the case, the positions of the hands must be adjusted (see the chapter enti-

tled «adjusting the chronograph hands to zero position»).

Minute counter

Hour counter

Chronograph:

Intermediate or interval timing

Example:

Start:

(start timing)

Display interval:

e.g.

10 minutes 10 seconds

(timing

continues in the background)

Making up the measured time:

(the 3 chronograph hands are quickly

advanced to the ongoing measured time).

Stop:

(Final time is displayed)

Reset:

The 3 chronograph displays are returned

to their zero position

Push-button A

Push-button B







Please note:

* Following



, further intervals or inter-

mediates can be displayed by pressing

push-button B

(display interval / make up

measured time, ...)



Chronograph:

Accumulated timing

Example:

Start:

(start timing)

Stop:

(e.g.

min

sec following



)

Restart:

(timing is resumed)



Stop:

(e.g.

min

sec following



)

=28 min 10 sec

(

The accumulated measured time is shown

)

Reset:

The three chronograph hands are returned

to their zero positions.









Push-button A

Push-button B



Please note:

* Following



, the accumulation of the

timing can be continued by pressing

push-

button A

(Restart / Stop, Restart / Stop, …)

Minute counter

Hour counter

Minute counter

Hour counter

Adjusting the centre stop second

1 x short

long

Single step

Continuous

Adjusting the next hand B



Returning the crown to position

Termination of the chronograph hands adjustment

(can be carried out at any time).

III

1 x short

long

Single step

Continuous

1 x short

long

Single step

Continuous





Adjusting the hour counter hand (position 6h)

Adjusting the minute counter hand (position 9h)



I II III

III

Adjusting the chronograph

hands to zero position

Example:

One or several chronograph hands are not in

their correct zero positions and have to be

adjusted (e.g. following a battery change).



Pull out the crown to position

III

(all 3

chronograph hands are in their correct or

incorrect zero position).



Keep push-buttons

A and B

depressed

simultaneously

for at least 2 seconds

(the centre stop-second rotates by

360°



corrective mode is activated).

Center

stop-second

Push-button A

Push-button B







Minute counter

Hour counter
