Rongta Technology C1 Manuale utente
Rongta Technology (Xiamen) Group Co., Ltd.
www.rongtatech.com
V1.0
User Manual
C1 Pos Scale
1
Contents
Introduction ...................................................................................................................2
1. Specification of Pos scale register ....................................................................... 3
2. Standard configuration of Pos scale register ..................................................... 4
3. Pos scale installation steps ................................................................................... 4
4. Overall Appearance ................................................................................................ 5
4.1 Front view ...................................................................................................... 5
4.2 Bottom interface view ...................................................................................5
5. Common easy-to -use operations ........................................................................ 6
5.1 Switch on and off .......................................................................................... 6
5.2 Weight display............................................................................................... 6
6. Troubleshooting of Pos scale register ................................................................. 7
6.1 Crash or fail to start ...................................................................................... 7
6.2 The display screen does not display or the display screen is blurred ..7
6.3 Unable to weigh properly .............................................................................7
7. Appendix Comparison Table of Gravitational Acceleration Corrected Value .8
2
Introduction
Thank you for choosing our Pos Scale. In order to operate Pos Scale correctly, User
manual is detailed in function and operation method of Pos Scale, which help user with
doubt quickly when come up against mechanical fault .
Rongta research, develop, produce and sale the Pos Scale independently, which is
high-performance Pos Scale.
Pos Scale is the best choice for user, power function and high durable, which make
Pos scale more popular in store ,fresh food supermarket ,farmers market and so on.
Note : this product information are subject to change without prior notice.
This information is for reference only. In addition to China's existing laws and regulations,
the company does not undertake any due to the direct or indirect losses caused by use of
this information.
The company reserves the final interpretation.
3
1. Specification of Pos scale register
The Weighing range and accuracy：
Max weight: 15kg Max weight: 30kg
Min weight: 40g Min weight: 100g
0kg to 6kg * 0.002kg (e=2g) 0kg to 15kg * 0.005kg (e=5g)
6kg to 15kg * 0.005kg (e= 5g) 15kg to 30kg * 0.01kg (e= 10g)
The accuracy grade:
Resolution
Input sensitivity:greater than or equal to50μV/D
zero-point adjustment range: ±60mV
temperature coefficient: ±0.0012%CTYP
[Zero] ±(0.2μV+0.0008% of Dead Load)/℃TYP
Nonlinearity: 0.01%F.S.
A/D resolution: Max 30000 resolution
Display resolution: 1/3000
A/D conversion rate: 10 times/second
Regular：
Power supply: DC12V 5A
Power consumption：12W
operating temperature: 0℃-40℃
Physical appearance：245mm*350mm*68mm
4
2. Standard configuration of Pos scale register
3. Pos scale installation steps
Take out the scale pan and install it according to the following instructions.
Align the fixing feet of the pan with the limit holes of the main body group
and put them into.
Scale pan
Quick installation guide
Main body
Power cable
5
4. Overall Appearance
4.1 Front view
4.2 Bottom interface view
6
5. Common easy-to -use operations
5.1 Switch on and off
Hard disk switch：
After connecting power supply,long press the black POWER button on the
bottom of Pos Scale register for 2 seconds until the display is turned on. After
entering the normal operation screen, the program will automatically run and
perform self-test counting to verify whether the CRC is correct. If verification
fails, the scale cannot work normally.
Attention: Under self-test situation, please do not press any button
and make sure nothing is on the scale, otherwise it can’t
work normally Soft disk switch on/off：
Turn off: Short press the power switch at the bottom for 2 seconds.
5.2 Weight display
Key Description
Tare: This operation is only for products need to be packaged, such as eggs,
beans, etc.There are two methods which are suitable for package and goods
separated & package and goods non-separated.
Zero: Press the Zero key to zero the scale. (Note: more than 300g can not be
reset to zero)
Reset: Used to restart the weighing module.
7
6. Troubleshooting of Pos scale register
6.1 Crash or fail to start
Reasons：a. Power line and interface error;
b.Adapter error;
c. Main board error.
Solutions：a. Re-plug the power line;
b. After power on，if the adapter indicator is off，it means
the adapter is abnormal；
c.The board is abnormal.
6.2 The display screen does not display or the display screen
is blurred
Reasons：a. Poor contact of screen line connector;
b. The display screen is damaged, or the main board is damaged;
Solutions：a. Re-plug the screen line connector
b. If it still fails, it may be caused by screen damage or
main board damage
6.3 Unable to weigh properly
Reasons：The main board or AD board fails, sensor fails, or CRC check fails；
Solutions：Please contact with us, we will provide you new version AD
boardprogram or weighing software；
8
7. Appendix Comparison Table of Gravitational
Acceleration Corrected Value
COUNTRY
CITY
G(m/sec2)
COUNTRY
CITY
G(m/sec2)
Greece
Athens
9.800
Scotland
Glasgow
9.816
South
Cape town
9.796
Spain
Madrid
9.800
Netherland
Amsterdam
9.813
Singapore
Singapore
9.781
Norway
Oslo
9.815
Argentina
Buenos Aires
9.797
New
Auckland,NZ
9.799
United
London,Greenw
9.812
New
Wellington,NZ
9.801
Australia
Melbourne
9.800
Taiwan
Taichung
9.789
Australia
Sydney
9.797
Taiwan
Taiwan
9.788
Italy
Milano
9.806
Taiwan
Taipei
9.790
Italy
Rome
9.803
Denmark
Copenhagen
9.815
India
Calcutta
9.788
Germany
Fankfurt
9.810
Japan
Tokyo
9.798
Mexico
Mexico City
9.779
Canada
Ottawa
9.806
U.S.A
Birmingham
9.813
Canada
Vancouver,BC
9.809
U.S.A
Chicago
9.803
Cuba
Havana
9.788
U.S.A
Los Angles
9.796
Kuwait
Kuwait
9.795
U.S.A
New York
9.802
Cyprus
Nicosia
9.797
U.S.A
San Francisco
9.800
Thailand
Bangkok
9.783
U.S.A
Washington,DC
9.784
Portugal
Lisbon
9.801
Belgium
Brussels
9.811
France
Paris
9.809
Brazil
Rio de Janeiro
9.786
Finland
Helsinki
9.819
Sweden
Stockholm
9.818
Philippines
Manila
9.784
Switzerlan
Zurich
9.807
COUNTRY
CITY
G(m/sec2)
COUNTRY
CITY
G(m/sec2)
Greece
Athens
9.800
Scotland
Glasgow
9.816
South
Africa
Cape town
9.796
Spain
Madrid
9.800
Netherland
Amsterdam
9.813
Singapore
Singapore
9.781
Norway
Oslo
9.815
Argentina
Buenos Aires
9.797
New
Auckland,NZ
9.799
United
London,Greenw
9.812
New
Wellington,NZ
9.801
Australia
Melbourne
9.800
Taiwan
Taichung
9.789
Australia
Sydney
9.797
Taiwan
Taiwan
9.788
Italy
Milano
9.806
Taiwan
Taipei
9.790
Italy
Rome
9.803
Denmark
Copenhagen
9.815
India
Calcutta
9.788
Germany
Frankfurt
9.810
Japan
Tokyo
9.798
Mexico
Mexico City
9.779
Canada
Ottawa
9.806
U.S.A
Birmingham
9.813
Canada
Vancouver,BC
9.809
U.S.A
Chicago
9.803
Cuba
Havana
9.788
It should be handled by person in our company or dealers if want to adjust
acceleration of gravity
