Rosemount 1420 Manuale utente
Quick Start Guide
00825-0200-4420, Rev GB
June 2017
Emerson™Smart Wireless Gateway 1420
00825-0200-4420_RevGB.fm Page 1 Wednesday, June 28, 2017 8:01 AM
June 2017
2
Quick Start Guide
NOTICE
This guide provides basic guidelines for the Smart Wireless Gateway. It does not provide instructions for
diagnostics, maintenance, service, or troubleshooting. Refer to the Smart Wireless Gateway Reference
Manual (document number 00809-0200-4420) for more information and instructions. This guide and the
manual are available electronically on www.emersonprocess.com.
Explosions could result in death or serious injury.
Installation of this device in an explosive environment must be in accordance with the appropriate local,
national, and international standards, codes, and practices. Review the Product Certifications section for
any restrictions associated with a safe installation.
Avoid contact with the leads and terminals. High voltage may be present on leads can cause electrical
shock.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired
operation.
This device must be installed to ensure a minimum antenna separation distance of 20 cm from all
persons.
Contents
Wireless considerations . . . . . . . . . . . . . . . . . . . 3
General considerations . . . . . . . . . . . . . . . . . . . . 3
Initial connection and configuration . . . . . . . . 4
Physical installation . . . . . . . . . . . . . . . . . . . . . . 10
Connect to the host system . . . . . . . . . . . . . . . 15
Software installation (optional) . . . . . . . . . . . 16
Verify operations . . . . . . . . . . . . . . . . . . . . . . . . 16
Product specifications . . . . . . . . . . . . . . . . . . . 17
Product Certifications . . . . . . . . . . . . . . . . . . . . 21
00825-0200-4420_RevGB.fm Page 2 Wednesday, June 28, 2017 8:01 AM
Quick Start Guide
3
June 2017
1.0 Wireless considerations
1.1 Power up sequence
The Smart Wireless Gateway (Gateway) should be installed and functioning
properly before power modules are installed in any wireless field devices. Wireless
field devices should also be powered up in order of proximity from the Smart
Wireless Gateway beginning with the closest. This will result in a simpler and
faster network installation.
1.2 Antenna position
The antenna should be positioned vertically, and be approximately 3 ft. (1 m)
from large structures or buildings to allow for clear communication to other
devices.
1.3 Mounting height
For optimal wireless coverage, the Gateway or remote antenna is ideally mounted
15 to 25 ft. (4,6 to 7,6 m) above ground or 6 ft. (2 m) above obstructions or major
infrastructure.
1.4 Gateway redundancy
If the wireless Gateway was ordered with redundancy (Gateway Redundancy
code RD), refer to Appendix D in the Smart Wireless Gateway Reference Manual
(document number 00809-0200-4420) for additional installation instructions.
2.0 General considerations
2.1 PC requirements
Operating system (optional software only)
Microsoft®Windows™XP Professional, Service Pack 3
Windows Server 2003 Service Pack 2
Windows Server 2003 R2 Service Pack 2
Windows Server 2008 (Standard Edition), Service Pack 2
Windows Server 2008 R2 Standard Edition, Service Pack 1
Windows 7 Professional, Service Pack 1
Windows 7 Enterprise, Service Pack 1
Applications
Internet Explorer®6.0 or higher
Mozilla Firefox®1.5 or higher
.Net Framework 2.0 (for OPC proxy only)
Hard disk space
AMS Wireless Configurator: 1.5 GB
Gateway Setup CD: 250 MB
00825-0200-4420_RevGB.fm Page 3 Wednesday, June 28, 2017 8:01 AM
June 2017
4
Quick Start Guide
3.0 Initial connection and configuration
3.1 DeltaV™ready
If the Gateway was ordered DeltaV Ready (Data Protocols Code 5), then skip to
4.0 Physical installation, and connect the Gateway to a DeltaV 10.3 or newer
control network.
3.2 Initial connection and configuration
To configure the Smart Wireless Gateway, a local connection between a
PC/laptop and the Gateway needs to be established.
Powering the Gateway
Bench top power will be needed to power the Gateway by wiring a 24 VDC
(nominal) power source, with at least 250 mA, to the power terminals.
Figure 1. Legacy Gateway Terminal Block Diagram
Figure 2. Power over Ethernet (PoE) Terminal Block Diagram
+
+
+
+
+
-
-
-
-
-
AB
S
S
S
S
24 VDC
(nominal)
Power Input
Serial
Modbus
N
ot Used Not Use
d
N
ot Use
d
Not Use
d
Case
(Covered)
S
Ethernet 2
with Power
Ethernet 2 Ethernet 1
(Secondary) (Primary)
®
+-AB
24 VDC
(nominal)
Power Input
Serial
Modbus
Case
SEthernet 2 Ethernet 1
(Secondary) (Primary)
00825-0200-4420_RevGB.fm Page 4 Wednesday, June 28, 2017 8:01 AM
Quick Start Guide
5
June 2017
Note
Figure 1 depicts the terminal block of legacy Gateways prior to the introduction of PoE
capabilities. Figure 2 shows the terminal block arrangement of a PoE version of the Gateway.
If the Gateway will be powered via the standard 24 volt power input terminals, and no PSE is
desired, it is not necessary to change the default settings of the PoE jumper matrix.
Note
The Gateway enclosure case should always grounded in accordance with national and local
electrical codes. The most effective grounding method is a direct connection to earth
ground with minimal impedance.
Figure 3. 1420 PoE Jumpering Matrix (Located on 1420 Board)
Legend:
ETH1: Ethernet port 1 selected for PD or PSE
ETH2: Ethernet port 2 selected for PD or PSE
PD: Gateway derived its power off the Ethernet port selected
PSE: The Gateway is powered via the standard 24 volt power input terminals and provides power
via the selected Ethernet port to another device with a compatible PD port.
EN: Enabled; this enables the PSE operation
DIS: Disabled; this disables the PSE operation
PoE PD on port 1
(Default jumpering for
production. Used for no
PoE also)
PoE PD on port 2
PoE PSE on port 1
PoE PSE on port 2
Black fill below indicates jumper.
00825-0200-4420_RevGB.fm Page 5 Wednesday, June 28, 2017 8:01 AM
June 2017
6
Quick Start Guide
Note
Electrostatic discharge (ESD) protection required when swapping PoE jumpers.
Note
Only one port and one mode of operation (PD or PSE) can be selected at a time; any other
combination of jumpers is invalid.
Note
IEEE 802.3af-2003 PoE standard provides up to 15.4 W of DC power (minimum 44 V DC and
350 mA) to each device. Only 12.95 W is assured to be available at the powered device as
some power is dissipated in the cable.
IEEE 802.3at-2009 PoE standard also known as “PoE+” or “PoE plus”, provides up to 25.5 W
of power. The 2009 standard prohibits a powered device from using all four pairs for power.
For more information on PoE and frequently asked questions, reference
document number 00870-0500-4420.
3.3 Establishing a connection
Note
For information on connecting a Windows 7 PC, see Technical Note (document number
00840-0900-4420).
1. Connect the PC/laptop to the Ethernet 1 (Primary) receptacle on the Gateway.
Figure 4. Gateway PC/Laptop Connection
A. PC/laptop
B. Ethernet 1 receptacle
Do not connect to the Ethernet 2 with power (covered) port. This port supplies power and could damage the
PC/laptop.
+ +
+
+
+
-
--
-
-A B S S
SS
S
24V DC
24V DC
PowerInput
PowerInput
Modbus
Modbus
Not Used
Not Used
Not Used
Not Used
Not Used
Not Used
Not Used
Not Used
Case
Case
S
POE
POE
P2
P2
P1
P1
A
B
00825-0200-4420_RevGB.fm Page 6 Wednesday, June 28, 2017 8:01 AM
Quick Start Guide
7
June 2017
2. To establish the PC/laptop settings, navigate to Start>Settings>Network
Connections.
a. Select Local Area Connection.
b. Right click to select Properties.
c. Select Internet Protocol (TCP/IP), then select the Properties button.
Note
If the PC/laptop is from another network, record the current IP address and other settings so
the PC/laptop can be returned to the original network after the Gateway has been
configured.
d. Select the Use the following IP address button.
e. In the IP address field, enter 192.168.1.12.
f. In the Subnet mask field, enter 255.255.255.0.
g. In the Internet Protocol (TCP/IP) Properties window, select OK.
h. In the Local Area Connection Properties window, select OK.
00825-0200-4420_RevGB.fm Page 7 Wednesday, June 28, 2017 8:01 AM
June 2017
8
Quick Start Guide
Note
Connecting to the Gateway's secondary Ethernet port requires different network settings.
Refer to Table 1 for additional network settings.
Table 1. Default IP Addresses
Table 2. Subnet Settings
3. Disable proxies.
a. Open a standard web browser (Internet Explorer, Mozilla Firefox, or other).
b. Navigate to Tools>Internet Options>Connections>LAN Settings.
c. Uncheck the box under Proxy Server.
Gateway PC/laptop
Ethernet 1 192.168.1.10 192.168.1.12
Ethernet 2 192.168.2.10 192.168.2.12
Ethernet 1 (DeltaV Ready) 10.5.255.254 10.5.255.200
Ethernet 2 (DeltaV Ready) 10.9.255.254 10.9.255.200
Subnet mask
Default 255.255.255.0
DeltaV 255.254.0.0
00825-0200-4420_RevGB.fm Page 8 Wednesday, June 28, 2017 8:01 AM
Quick Start Guide
9
June 2017
3.4 Configure the Smart Wireless Gateway
To complete initial configuration for the Gateway:
1. Access the default web page for the Gateway at https://192.168.1.10.
a. In the User name field, enter admin.
b. In the Password field, enter default.
Figure 5. Gateway Log In Screen
2. Navigate to System Settings>Gateway>Ethernet Communication to enter the
Network Settings.
a. Configure a static IP Address or set for DHCP and enter a Hostname.
b. Restart application at System Settings>Gateway>Backup And Restore>Restart
App.
3. Disconnect the power and Ethernet from the Gateway.
00825-0200-4420_RevGB.fm Page 9 Wednesday, June 28, 2017 8:01 AM
June 2017
10
Quick Start Guide
4.0 Physical installation
4.1 Pipe mount
Tools needed:
2-in. (51 mm) mounting pipe or mast
Two 5/16-in. (7,9 mm) u-bolts supplied with Gateway
1/2-in. socket-head wrench
For installing the Gateway with a pipe mount:
1. Insert one u-bolt around the pipe, through the top mounting holes of the
Gateway enclosure, and through the washer plate.
2. Use a 1/2-in. socket-head wrench to fasten the nuts to the u-bolt.
3. Repeat steps 1 and 2for the second u-bolt and lower mounting holes.
Best practice
If the Gateway was ordered with output code 2, run a secondary Ethernet cable
when installing cable conduit from the Gateway to a convenient indoor location
to simplify future configuration changes.
