Rosewill RCW604 Manuale utente

USB 2.0 To IDE Cable For 2.5"/3.5"/5.25" Drive

With Power Adapter

RCW604

User Manual

USB 2.0 To IDE Cable For 2.5"/3.5"/5.25" Drive With Power Adapter RCW604

USB 2.0 To IDE Cable For 2.5"/3.5"/5.25" Drive

With Power Adapter

Feature

The USB 2.0 to IDE Drive Adapter implements a bridge between one USB port and one ATA or

ATAPI based mass storage device port. The USB 2.0 to IDE Drive Adapter turns any IDE drive

into a convenient external drive. Easily transfer ﬁles from computer or notebook, back up ﬁles, or

store large ﬁle archives on hard drives. The Hi-Speed USB interface provides for easy installation

with its Plug and Play design. The adapter supports all existing IDE/ATAPI devices such as

Iomega Zip, CD-ROM, CD-RW, DVD-ROM and IDE hard drives.

Speciﬁcations

• USB 2.0 to IDE Cable

• Connect any device with an IDE Interface to a PC with USB interface

• Transfer rate Approx. 480 Mbps

• Complies with USB 2.0 standards

• Backwards compatible to USB 1.1 standards

• Complies with ATA/ATAPI-66 Spe. V1.0

• Easy to Install

• Supports IDE and enhanced IDE hard drives

• Supports ATA/ATAPI CD-ROM/R/RW DVD-ROM and more

• External power adapter for IDE/ATAPI devices

• Linux compatible

System Requirements

Microsoft Windows 98/98SE/ME/2000/XP

Mac OS 9.2 or higher

Linux 2.4.X

User Manual

USB 2.0 To IDE Cable For 2.5"/3.5"/5.25" Drive With Power Adapter RCW604

Package Contents

RCW-604 X 1

User manual X 1

Power adapter X 1

Installation

1. Plug the 2.5” or 3.5” ATA/ATAPI device to RCW-604

(Please notice the direction of IDE port)

SATA

2.5"

3.5"

5.25"

ATAPI device

2.5" HD 3.5" HD

(only available in RCW605)

User Manual

USB 2.0 To IDE Cable For 2.5"/3.5"/5.25" Drive With Power Adapter RCW604

2. Connect the power adapter set.

3. Plug the 4 pin power adapter to your ATA/ATAPI device

(There is no additional power needed for 2.5” HD)

4. Plug the power adapter to power source and turn on the power .

(Please make sure the voltage is between 100~240V)

5. Plug the USB2.0 cable to PC and wait for PC auto-detection.

Driver is needed only in old system such as Windows 98.

Please inset the driver disk when your system can’t complete

the installation process. Windows will auto-install after it detects

the driver disk and choose the most suitable driver for your system.

(Please notice the direction of USB port)

User Manual

USB 2.0 To IDE Cable For 2.5"/3.5"/5.25" Drive With Power Adapter RCW604

Notiﬁcation

1. RCW-604 can only support one ATA/ATAPI device of 2.5” or 3.5” one time. This means that if

you connect a 2.5” HD to 2.5” port, 3.5” port will be no function during the operation of 2.5”

HD.

2. There is no different between the jumper setting of “Master” or “Slave” on your ATA/ATAPI

device working with RCW-604.

3. Please take off the ATA/ATAPI device from RCW-604 only after you turn off the power to avoid

any damage.

4. If you plug RCW-604 and HD to PC, PC might freeze during the beginning of booting. In this

case, you may unplug RCW-604 at the start of booting and re-plug it after PC enters windows.

5. If PC can’t detect RCW-604 and HD in windows, please try the following. Unplug RCW-604

nd try to reboot the PC. Re-plug it after system enters windows. If all above still can’t help, it

might be caused by the incompatibility between HD, system or controller chipset.

Please contact us for more support.

Thank you for purchasing a quality Rosewill Product.

Please register your product at : www.rosewill.com/

for complete warranty information and future support for your product.

If you have any question while using our products, please feel free to contact us at

[email protected] .
