RSA Lighting ACCURUS Housing ACT950 Manuale utente

DESCRIPTION Catalog # Type

Project

Comments Date

Prepared by

www.cooperlighting.com

SPECIFICATION FEATURES

7.25”

12.00”

13.00”

8.18”

4.63”

0.5” - 1.0”

Ceiling

Cut-Out

4.50”dia.

A...Housing

Housing and plaster frame: 18 gauge CRS

with ﬂat black powder coated internal

ﬁnish. Adjustable plaster frame can

accommodate up to 1” ceiling thickness.

B ...System Protection:

Thermal protection provided to guard

against overheating and misuse of

insulation over and around ﬁxture.

Vent holes in housing provide cooler

operation.

C ...Electrical

Integral j-box and electronic or magnetic

low voltage transformer . 120V or 277V

input, 12V output. Junction box is

U.L. listed for through branch wiring.

Includes ﬁve 1/2 trade size knockouts

(six knockouts when magnetic xfmr. is

speciﬁed)

D...Lamp

12V MR16 71 watts max. (not included)

Internal rotation ring with locking

adjustment. Provides 360º rotation of

trim and secures original trim position

after relamping. “POSI-GRIP” bi-pin

lamp socket for ﬁrm, mechanical lamp

connection.

E ...Mounting

Hanger Bars and Butterﬂy Brackets

included for residential and commercial

applications respectively.

Ceiling Cut-Out: 4.50” dia.

ACCURUS

HOUSING

ACT950

New Construction

Housing

for Round Trim

FOR 12V MR16 71 watts max.

ORDERING INFORMATION

Housing

ACT950 =

Accurus New Construction

Housing for Round Trim

w/Integral Transformer

Voltage

120 =120 volts primary

277 =277 volts primary

New construction housing for 5” Accurus round trim. For 12V MR16 71

watts max.

For new construction applications. Insulation must be kept 3” from all

sides and at least 1” above the housing.

Speciﬁcations and Dimensions subject to change without notice.

RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031

Transformer

ELC =Electronic

MAG =Magnetic

ACT950

rev 122007
