Rtd CM17202 Manuale utente

CM17202

PC/104-Plus Fast Ethernet

Controller utilityModule

User’s Manual

BDM-610020025

Rev. A

CM17202

PC/104-Plus Fast Ethernet Controller

utilityModule

User’s Manual

RTD Embedded Technologies, INC.

103 Innovation Blvd.

State College, PA 16803-0906

Phone: +1-814-234-8087

FAX: +1-814-234-5218

E-mail

sales@rtd.com

techsu[email protected]

web site

http://www.rtd.com

Revision History

04/08/2002 Version 1.0 Initial Release

Rev. A New Manual Naming Method

Published by:

RTD Embedded Technologies, Inc.

103 Innovation Blvd.

State College, PA 16803-0906

Printed in U.S.A.

The RTD Logo is a registered trademark of RTD Embedded Technologies. cpuModule and utilityModule are

trademarks of RTD Embedded Technologies. PhoenixPICO and PheonixPICO BIOS are trademarks of Phoenix

Technologies Ltd. PS/2, PC/XT, PC/AT and IBM are trademarks of International Business Machines Inc. MS-

DOS, Windows, Windows 95, Windows 98 and Windows NT are trademarks of Microsoft Corp. PC/104 is a

registered trademark of PC/104 Consortium. All other trademarks appearing in this document are the property of

their respective owners.

Table of Contents

CHAPTER 1 INTRODUCTION .................................................................................................................1

ELECTRICAL SPECIFICATIONS ...................................................................................................................................1

MECHANICAL SPECIFICATIONS .................................................................................................................................1

ENVIRONMENTAL .....................................................................................................................................................2

SOFTWARE................................................................................................................................................................2

CHAPTER 2 CM17202 LAYOUT ..............................................................................................................3

FINDING PIN 1 OF CONNECTORS ...............................................................................................................................3

COMPONENT LOCATIONS..........................................................................................................................................3

LIST OF CONNECTORS AND SWITCHES ......................................................................................................................4

PC/104 BUS CONNECTORS, CN1 AND CN2 .............................................................................................................5

PC/104-PLUS PCI CONNECTOR, CN3.......................................................................................................................7

PC/104-Plus PCI Bus Signals..............................................................................................................................8

RJ45 TWISTED PAIR ETHERNET, CN4....................................................................................................................10

TWISTED PAIR ETHERNET, CN5 .............................................................................................................................11

MII CONNECTOR, CN6...........................................................................................................................................12

PCI BOARD SELECTOR ROTARY SWITCH, SW1......................................................................................................13

LED INDICATORS ...................................................................................................................................................13

CHAPTER 3 INSTALLING THE UTILITYMODULE......................................................................14

RECOMMENDED PROCEDURE:.................................................................................................................................14

JUMPER SETTINGS...................................................................................................................................................15

CHAPTER 4 RETURN POLICY AND WARRANTY............................................................................16

RETURN POLICY .....................................................................................................................................................16

LIMITED WARRANTY..............................................................................................................................................17

Table of Figures

FIGURE 1: COMPONENT LOCATIONS ............................................................................................................................3

FIGURE 2: RJ-45 JACK CONNECTOR..........................................................................................................................10

FIGURE 3: PCI SELECTOR ROTARY SWITCH ..............................................................................................................13

Table of Tables

TABLE 1: LIST OF CONNECTORS AND SWITCHES..........................................................................................................4

TABLE 2: PC/104 XT BUS CONNECTOR......................................................................................................................5

TABLE 3: PC/104 AT BUS CONNECTOR......................................................................................................................6

TABLE 4: PC/104-PLUS BUS SIGNAL ASSIGNMENTS....................................................................................................7

TABLE 5: RJ45 SIGNAL ASSIGNMENTS ......................................................................................................................10

TABLE 6: CN5 SIGNAL ASSIGNMENTS.......................................................................................................................11

TABLE 7: MII INTERFACE CONNECTOR LAYOUT.......................................................................................................12

TABLE 8: LED INDICATORS.......................................................................................................................................13

TABLE 9: CONNECTOR JUMPER SETTINGS .................................................................................................................15

CM17202 Fast Ethernet Controller utilityModule1 RTD Embedded Technologies, Inc.

Chapter 1 INTRODUCTION

• This manual gives information on the CM17202 PC/104-Plus Fast Ethernet Controller

utilityModule.

This module provides a twisted-pair 100 Mbit ethernet connection to support the Real Time

Devices’ PC/104-Plus cpuModulesand other PC/104-Plus processor modules.

Features

The following are major features of the CM17202 utilityModule.

Intel 21143-TD PCI Fast Ethernet Controller and ICS1892Y 10/100BaseTX integrated

physical transceiver

• MII Interface

Electrical Specifications

• Compatible with PCI Specification

• Compatible with PC/104-Plus Specification

Mechanical Specifications

• Compatible with PC/104-Plus Specification when using the 10 pin twisted pair connector,

CN5. This connector is not the default factory installed connector. The factory default

connector is the RJ45 connector, CN4. Please note that all RJ45 connectors (default

configuration), violate the height limit of all PC/104 Specifications. If height limit is required,

the RJ45 connector cannot be installed, and the optional 10 pin connector must be installed by

the factory.

• Dimensions: 3.8 x 3.9 x 0.6" (97 x 100 x 16 mm)

• Weight (mass): 3.0 ounces (85 grams)

CM17202 Fast Ethernet Controller utilityModule2 RTD Embedded Technologies, Inc.

Environmental

• Operating Temperature: -40°to 85°C

• Storage Temperature: -40°to +85°C

• Non-Condensing Relative Humidity: < 95% at 40°C

WARNING! Like all equipment using CMOS devices, the CM17202 must be protected from static

discharge. Never touch any of the parts except at static-free workstation. Use anti-

static bag shipped with the CM17202 to handle the board

Software

The 21143-TD is supported by DOS, Windows 3.1, Windows 95, Windows NT, Windows 2000,

VxWorks and QNX. For DOS and Windows 3.1, drivers can be downloaded from the Intel Developer web

site at the 21143 Drivers page. For Windows 95, Windows 98, Windows NT, and Windows 2000, the

drivers are supplied by Microsoft along with the operating system. The latest drivers for all of the above

mentioned operating systems can also be found at the Intel Developer web site at the 21143 Drivers page.

For VxWorks and QNX please contact them directly.

CM17202 Fast Ethernet Controller utilityModule3 RTD Embedded Technologies, Inc.

Chapter 2 CM17202 LAYOUT

Finding Pin 1 of Connectors

The three possible ways to determine pin 1 on the connectors are:

1. A square white area silk-screened on the PC board

2. A square solder pad visible on the bottom of the PC board

3. A numeral 1 silk-screened near pin 1 on the top of the PC board

Component Locations

The figure below shows switch and jumper locations.

Figure 1: Component Locations

CN4: RJ45 Connector

CN5

: 10 Pin Twisted Pair

Connector (Optional)

CN1: XT Bus

CN2: AT Bus

RSW1: PCI Rotary Switch

CN6

: MII Interface

Connector

U6: PLCC Socket

LEDs:

10/100 Mbit/s

Receive

Transmit

Link

Activity

Collision

Jumpers

CN3: PCI Connector
