INTRODUCTION
To get the most out of your power inverter, proper installation is critical. Please read the installation and
operating instructions in this manual carefully before installing and using your power inverter. Pay special
attention to the CAUTION: statements in this manual. CAUTION: statements identify conditions or practices
which could result in damage to your power inverter or to other Equipment.
The power source must provide between 11(20) and 15(30) volts DC and must be able to supply sufficient current to
operate the load. As a rough guide line, divide the power consumption of the load (in watts) by 10(20) to obtain the
current (in amperes) in the power source must deliver.
Example: Load is rated at 300 watts. Power source must be able to deliver: 300 divided by 10=30 amperes.
CAUTION: Rechargeable batteries and devices with rechargeable batteries may not be suitable for use with the power
inverter. The rechargeable batteries, recharging transformer and/or the power inverter may be damaged when trying to
recharge devices of 24 volts and higher. The power inverter will not operate from a 6 volt battery.Refer to the
manufacturers specifications when using these devices.
PLACEMENT OF THE INVERTER
For best operating results, the inverter should be placed on a flat surface, such as the floor or seat of the vehicle. The
inverter should only be used in locations that meet the following requirements:
DRY — Keep away from water. Do not allow water to drip or splash on power inverter.
COOL — Ambient air temperature should be between 50 degrees and 80 degrees F. Do not place the inverter on or near a
heating vent or any piece of equipment which is generating heat above room temperature. If avoidable, do not place the
inverter in direct sunlight.
VENTILATED — Allow at least one inch of clearance around the power inverter for air flow. Do not place anything on
or over the inverter during operation.
Make sure that the air is allowed to circulate freely around the unit.
SAFETY — Do not use the power inverter near flammable materials or in any location which
may accumulate flammable fumes or gases, such as the battery compartment of your car,
truck, RV, or boat. This product is not suitable for use while traveling using battery clamps.
The length of the wire cables and battery clamps are not designed for this operation. If you wish to
operate the inverter while moving, the power inverter May be permanently mounted and wired.
CONNECTING TO THE POWER SOURCE
Your power inverter does not come equipped with battery cables which must be purchased
separately. The proper gauge of the battery cables can only be properly determined when
Calculating the length of the cables from the inverter to the battery. These cables may be
purchased from any automotive, marine or home center. (See Fig. 1 and Fig. 2)
CAUTION: DO NOT USE WITH POSITIVE GROUND
ELECTRONICAL SYSTEMS.
C A U T I O N : M A K E S U R E T H E P O W E R INVERTER IS OFF.
