RTS KrimpVark Manuale utente
RTS Help Line
Dear client should you experience any
difficulties or problems on your RTS Product
(s) please feel free to contact our office at
086100 2525
Weekdays between 08H00 and 17H00
We will gladly assist you with your purchased
RTS Product (s)
This radio have been programed
with the following factory defaults:
Channel 1-8 with CTCSS 94.8 Hz
Channel 9-16 with CTCSS 131.8Hz
CONTENTS
Introduction………………………………………1
Unpacking and check devices……………………2
Accessory List……………………………………2
Main Features……………………………………3
Technical information……………………………4
Identification………………………………………6
Preparation for Using……………………………7
PC Software Programming Setting………………12
Operation Guide…………………………………13
Maintenance………………………………………17
Troubleshooting…………………………………19
Appendix: CTCSS QT and DCS DQT Chart ……22
Introduction
Thanks for purchasing RTS Krimpvark radio.
Please read this manual carefully to learn its
functions and operations before using.
With mini compact size, stable performance,
and easy-to-use feature, transceiver Krimpvark is
developed for wide using. It offers you a normal
communication when you are in the rural area, forest
zone, pasturing area or sea area. The fine appearance
of Krimpvark meets your needs of personality.
- 1 -
Unpacking and check the devices
Please take the radio out carefully from the
package, and check again before disposing of the
packing to make sure that all the following items are
contained in the packaging. If any of them are
missing or damaged during transportation, please
contact with the vendor for service.
Accessories list
Description Unit Quantity
Antenna pc 1
Belt clip pc 1
Lithium
battery pack pc 1
Charger pc 1
Wrist string pc 1
Warranty card pc 1
QC passed
card pc 1
User Manual book 1
- 2 -
Main Feature
1、400--470MHz full frequency
2、Chinese and English channel report
3、High and low power optional
4、wide and narrow band optional
5、CTCSS/50 and DCS/83 squelch system to
avoid the disturbance from other radio station.
6、VOX function ,free your hands ，easy
operation
7、BCL（busy channel lock）function to know
the busy state
8、SCAN function, scan all the channels
9、Built-in FM-radio to know the latest new at
anytime.
10、power-save function to make the standby
time longer.
All the above functions are edited by PC
programming software. And the transceiver has the
following functions itself：
- 3 -
1．Emergency alarm function gives you more
peace.
2．Rime elimination function will eliminate
the noise when stop talking.
Technical Information
GENERAL
Frequency range
400MHz-470MHz
Number of channel 16
Channel spacing 12.5kHz / 25kHz
Modulation method FM
Operating temperature range －10℃--- ＋
55℃
Voltage 3.7V---4.2V
Standby Current about 10mA（Save Power
State）
Size 95(H)×53(W)×30(D)mm
Weight about135g
- 4 -
TRANSMITTER
Frequencystabilization ≤5ppm
Output power ≤3.5W
Emission current ≤1.3A
Maximum frequency deviation ±5kHz
Audio distortion <10%
Adjacent channel power <70dB
Residualradiation <-60dB
RECEIVER
Reference sensitivity <-122dBm
(12dB SINAD)
Sensitivitylock <-126dBm
Audio Power ≥500mW
Receiving current ≤300mA
Audio distortion <10%
Adjacent channel selection ≥60dB
Intermodulation rejection ≥60dB
- 5 -
Identification
- 6 -
1. Pendent hole 2.Belt Clip Stator
3. Indicated Light 4. Antenna
5 .Volume Knob 6. Channel Knob;
7.BeltClip; 8.PTT
9. Earphone Jack
10. FM Radio/Monitor/Reception+
11. Speaker 12. Call/Reception-
13.MIC 14.ChargingContactPlate
15. USB Charging Jack 16.Antenna Terminal
- 7 -
