RugGear RG100 Manuale di istruzioni

Quick Start Manual_En

ScHnEllStartanlEitunG_DE

TITEL DES KAPITELS

contEnt

SAFETY INSTRUCTIONS

1_Introduction 5

2_Faults and damages 6

3_Further safety advises 7

QUICK START

4_Keys 9

5_First steps 10

5.1_Battery 10

5.1.1_Installing and extracting the battery 10

5.1.2_Charging the battery 11

5.1.3_Battery use 11

5.2_Installation of the SIM card 12

5.3_Installation of the microSD card 12

6_Status icons 13

MENU NAVIGATION

7_Menu navigation 14

7.1_Call center 14

7.2_Multimedia 14

7.3_Phonebook 15

TITEL DES KAPITELS

7.4_Messages 16

7.5_Tools 17

7.6_Charger PAL 17

7.7_USB mode 17

7.8_Bluetooth® 18

7.9_Settings 18

INFORMATION

8_Specications 19

9_Troubleshooting 20

10_Maintenance 22

11_ SAR 23

Service Center 25

rESErvation

Technical Data is subject to change without notice.

Changes, errors and misprints may not be used as a

basis for any claim for damages.

RugGear Europe GmbH cannot be held responsible

for any data or other loss and direct or indirect

damages caused by any improper use of this phone.

This document contains a quick start guide and the

safety instructions necessary for the safe use of the

mobile phone RG100.

More detailed instructions on the use of the phone

can be found at www.ruggear-europe.com or directly

at our Service Centre.

C 2014 RUGGEAR EUROPE GMBH

DW3140819

SafEty inStructionS

1_introDuction

This document contains information and safety regulations

which are to be observed without fail for safe operation of the

mobile phone RG100 under the described conditions.

The current EC declaration of conformity, EC certicate of

conformity, safety instructions and manual can be found

at www.ruggear-europe.com, or requested from

RugGear Europe GmbH.

NOTE

This document contains only the instructions necessary for setting

up and safe use of your phone. A complete Quick Start Manual can

be found at www.ruggear-europe.com.

To ensure the IP protection of the phone please make sure that the

seals of the battery, the USB port cover and all the screw covers are

in their correct place.

6SafEty inStructionS

2_faultS anD DaMaGES

If there is any reason to suspect that the safety of the phone has

been compromised, it must be withdrawn from use immediately.

Measures must be taken to prevent any accidental restarting

of the phone.

The safety of the phone may be compromised if, for example:

malfunctions occur.

the housing of the phone or the battery shows damage.

the phone has been subjected to excessive loads.

the phone has been stored improperly.

SafEty inStructionS

3_furtHEr SafEty aDviSES

Do not touch the screen of the phone with sharp objects.

Dust particles and dirt may scratch the screen. Please maintain

the screen clean. Remove dust on the screen with a soft cloth

gently and do not scratch the screen.

Charge the phone under indoor conditions only.

Please do not put the phone in environments with excessive

temperatures as this could lead to heating of the battery,

resulting in re or explosion.

Do not charge the phone near any ammable or explosive

substances.

Do not charge the phone in environments with much

dust, humidity, or excessively high or low temperatures

(the permitted charging temperature range is 0 °C – 45 °C).

Do not use the phone in areas where regulations or legislatives

prohibit the use of a mobile phone.

Do not expose the phone, the battery or the charger to strong

magnetic elds, such as are emitted from induction ovens or

micro-waves.

Do not attempt to open or repair the phone. Improper repair

or opening can lead to the destruction of the phone, re or

explosion. Only authorized personnel are allowed to repair

the phone.

Only use accessories approved by RugGear Europe GmbH.

Please do not connect the poles of the battery directly, to avoid

short-circuiting the battery.

Power o the phone in hospitals or other places where the use

of mobile phones is prohibited. This phone may aect proper

work of medical equipment, like pacemakers, so always keep a

distance of at least 15 cm between the phone and these devices.

8SafEty inStructionS

Observe all corresponding laws that are in force in the

respective countries regarding the use of mobile phones

while operating a vehicle.

Please power o the phone and disconnect the charging cable

before cleaning the phone.

Do not use any chemical cleaning agents to clean the phone or

the charger. Use a damp and anti-static soft cloth for cleaning.

Do not discard old and abandoned lithium batteries into

the trash, send them to designated waste disposal locations

or return them to RugGear Europe GmbH.

The user alone is responsible for any and all damages and

liabilities caused by malware downloaded when using the

network or other data-exchange functions of the phone.

RugGear Europe GmbH cannot be held responsible for any

of these claims.

WARNING

RugGear Europe GmbH will not assume any liability for damages

caused by disregarding any of these advices or by any inapprop-

riate use of the phone.

4_kEyS

1_Power

Lock the phone. Long

press to power on and

o the phone.

2_Send

Bring up the call log

or answer a call when

the phone is ringing.

3_Contacts

4_Menu

While on the homescreen:

enter settings.

5_Navigation

4-way navigation

through menus.

6_OK

Conrm the selected

item or function.

7_Keypad

Use for text or number entry.

8_Volume

Adjust the volume.

9_Torch on/o

Quick Start

4 3

10 Quick Start

5_firSt StEpS

5.1_BATTERY

The battery is inserted into the back of the mobile phone. The

battery is not fully charged when the mobile phone is purchased,

but it contains enough energy to power on the phone.

To obtain best battery performance and battery life, let the battery

discharge completely before charging it completely for the rst

three charging cycles.

5.1.1_INSTALLING AND EXTRACTING THE BATTERY

When installing the battery, insert the teeth at the top of the battery

into the corresponding notches of the mobile phone, then press

the battery down and secure it by turning the two screws with the

delivered screw driver. Ensure that the battery is safely in place

before powering on the phone.
